In this article, we provide a detailed overview of the fuse box diagrams for the first-generation Buick Enclave (facelift models): 2013, 2014, 2015, 2016, and 2017 model years.
The fuses designated as "PWR OUTLET", "AUX POWER", "CIGAR LIGHTER", and "RR APO" in the engine compartment fuse block protect the cigarette lighter and 12-volt power receptacles.
Engine Compartment Fuse Block
Located on the left side of the engine compartment, beneath the plastic cover.
Accessing the fuse block.
General overview.
| Diagram | |
|---|---|
2013 model year. |
|
2014–2017 model years. |
|
| Name | Description |
| Relays | |
| A/C CMPRSR CLTCH | Air Conditioning Compressor Clutch |
| AUX VAC PUMP | Auxiliary Vacuum Pump |
| CRNK | Switched Power |
| FAN 1 | Cooling Fan 1 |
| FAN 2 | Cooling Fan 2 |
| FAN 3 | Cooling Fan 3 |
| FOG LAMP (GMC) | Headlamp Washer (China) / Fog Lamps (GMC) |
| HDLP WASH (CHINA) | Headlamp Washer (China) / Fog Lamps (GMC) |
| HI BEAM | High-Beam Headlamps |
| HID/LO BEAM | High-Intensity Discharge (HID) Low-Beam Headlamps |
| HORN | Horn |
| IGN | Ignition Main |
| LT TRLR STOP/TRN | Trailer Left Stoplamp and Turn Signal Lamp |
| PRK LAMP | Parking Lamp |
| PWR/TRN | Powertrain |
| RR DEFOG | Rear Window Defogger |
| RT TRLR STOP/TRN | Trailer Right Stoplamp and Turn Signal Lamp |
| Stop Lamps (China Only) | Stoplamps (China Only) |
| TRLR BCK/UP | Trailer Backup Lamps |
| WPR | Windshield Wiper |
| WPR HI | Windshield Wiper High Speed |
| Fuses | |
| * | Headlamp Washer (China) / Fog Lamps (GMC) |
| A/C CLUTCH | Air Conditioning Compressor Clutch |
| ABS MTR | Antilock Braking System (ABS) Motor |
| AFS | Adaptive Forward Lighting System |
| AIRBAG | Airbag System |
| AUX POWER | Auxiliary Power Receptacle |
| AUX VAC PUMP | Auxiliary Vacuum Pump |
| AWD | All-Wheel Drive Module |
| BATT 1 | Battery Power 1 |
| BATT 2 | Battery Power 2 |
| BATT 3 | Battery Power 3 |
| CIGAR LIGHTER | Cigarette Lighter |
| ECM 1 | Engine Control Module 1 |
| ECM/ FPM IGN |
|
| EMISSION 1 | Emissions 1 |
| EMISSION 2 | Emissions 2 |
| EVEN COILS | Even Ignition Coils |
| FAN 1 | Cooling Fan 1 |
| FAN 2 | Cooling Fan 2 |
| FOG LAMP (GMC) | Fog Lamps (GMC) |
| FPM | Fuel Pump Module |
| FSCM | Fuel System Control Module |
| HORN | Horn |
| HTD MIR | Heated Outside Rearview Mirrors |
| HTD STR WHL | Heated Steering Wheel |
| HUMIDITY/MAF |
|
| HVAC BLWR | Heating, Ventilation, and Air Conditioning Blower Motor |
| LT HI BEAM | Left High-Beam Headlamp |
| LT LO BEAM | Left Low-Beam Headlamp |
| LT PRK | Left Parking Lamp |
| LT TRLR STOP/TRN | Trailer Left Stoplamp and Turn Signal |
| ODD COILS | Odd Ignition Coils |
| PCM IGN | Powertrain Control Module Ignition |
| PWR L/GATE | Power Liftgate |
| PWR OUTLET | 12-Volt Power Receptacle |
| RR APO | Rear Accessory 12-Volt Power Receptacle |
| RR DEFOG | Rear Window Defogger |
| RR HVAC | Rear Climate Control System |
| RT HI BEAM | Right High-Beam Headlamp |
| RT LO BEAM | Right Low-Beam Headlamp |
| RT PRK | Right Parking Lamp |
| RT TRLR STOP/TRN | Trailer Right Stoplamp and Turn Signal |
| RVC SNSR | Regulated Voltage Control Sensor |
| S/ROOF/SUNSHADE | Sunroof / Sunshade |
| SERVICE | Service / Diagnostic Link |
| SPARE | Spare |
| Stop Lamps | Stoplamps (China Only) |
| STRTR | Starter Motor |
| TCM | Transmission Control Module |
| TRANS | Transmission |
| TRLR BCK/UP | Trailer Backup Lamps |
| TRLR BRK | Trailer Brake Controller |
| TRLR PWR | Trailer Power |
| TRLR PRK LAMP | Trailer Parking Lamps |
| WPR/WSW | Windshield Wiper / Washer |
Passenger Compartment Fuse Block
Located beneath the glove box.
To access the fuses, open the cover situated on the right side beneath the glove box.
| Diagram | |
|---|---|
2013 model year. |
|
2014–2017 model years. |
|
| Name | Description |
| Relays | |
| DRL/ LO BEAM | Daytime Running Lamps Relay |
| DRL/LO BEAM | Daytime Running Lamps Relay / Low-Beam Headlamps Relay |
| FOG LAMPS | Fog Lamps Relay |
| FRT/WSW | Windshield Washer Relay (Front) |
| L/GATE | Power Liftgate Relay |
| LCK | Power Door Lock Relay |
| LT/PWR/SEAT | Driver Power Seat Relay |
| LT/UNLCK | Driver Door Unlock Relay |
| PWR/COLUMN | Power Steering Column Relay |
| PWR/WNDW | Power Window Relay |
| REAR FOG LAMPS (CHINA) | Rear Fog Lamp Relay (China) / Fog Lamp Relay (Chevrolet) |
| REAR/WSW | Rear Window Washer Relay |
| RT/PWR/SEAT | Passenger Power Seat Relay |
| UNLCK | Power Door Unlock Relay |
| Fuses | |
| # | GMC Non-HID: Low-Beam Headlamps |
| * | GMC Non-HID: High-Beam Shutter |
| ** | Chevrolet: Fog Lamps |
| *** | Buick (China): Rear Fog Lamp |
| AIRBAG | Airbag System |
| AMP | Audio Amplifier |
| BCK/UP/STOP | Backup Lamp / Stoplamp |
| BCM | Body Control Module |
| CNSTR VENT | EVAP Canister Vent |
| CTSY | Courtesy Lamps |
| DRL LC | Door Lock Control |
| DRL /LO BEAM | Daytime Running Lamps Relay / Low-Beam Headlamps Relay |
| DSPLY | Multimedia Display |
| EMPTY | Spare |
| FRT WSW | Front Windshield Washer |
| HTD/COOL SEAT | Heated / Ventilated Seats |
| HVAC | Heating, Ventilation, and Air Conditioning |
| INADV PWR INT LAMPS |
|
| INFOTMNT/MSM |
|
| LT TRN SIG | Left Turn Signal |
| OBS DET /URS |
|
| PDM | Power Mirrors, Power Liftgate Release |
| PWR MIR | Power Mirrors |
| PWR MODE | Power Mode |
| RDO | Radio / Audio System |
| REAR WPR | Rear Window Wiper |
| RPA/SBZA/UGDO |
|
| RT TRN SIG | Right Turn Signal |
| STR WHL ILLUM | Steering Wheel Illumination |
| USB CHRG | USB Charging Ports |
