This comprehensive guide details the fuse block diagrams for the first-generation Buick Encore GX: 2019, 2020, 2021, 2022, and 2023 model years.
Fuse #10 in the instrument panel fuse block protects the radio and infotainment system circuit.
Rear Compartment Fuse Block
Located on the driver's side of the cargo area, behind a plastic trim panel. Remove the panel to access the fuse block.
| Diagram | |
|---|---|
|
|
| Circuit Breakers | |
| CB1 | Not Used |
| Relays | |
| K01 | Not Used |
| K02 | Not Used |
| K03 | Not Used |
| K04 | Not Used |
| K05 | Not Used |
| Fuses | |
| F01 | Not Used |
| F02 | RDCM ELEC |
| F03 | Not Used |
| F04 | Not Used |
| F05 | DC/AC Inverter |
| F06 | Not Used |
| F07 | RDCM |
| F08 | Rear Seat Heater PWR 1 |
| F09 | Not Used |
| F10 | Rear Seat Heater PWR 2 |
| F11 | Not Used |
| F12 | Not Used |
| F13 | Not Used |
| F14 | Not Used |
| F15 | Not Used |
| F16 | Not Used |
| F17 | Not Used |
| F18 | Not Used |
| F19 | Not Used |
| F20 | Not Used |
| F21 | Not Used |
Instrument Panel Fuse Block
Located on the underside of the instrument panel on the driver's side. To access the fuses, pull the plastic trim cover outward to remove it.
General view of the instrument panel fuse block.
| Diagram | |
|---|---|
|
|
| No. | Description |
| Circuit Breakers | |
| CB1 | Empty |
| CB2 | Auxiliary Power Outlet (APO) |
| Relays | |
| K01 | i-RAP_ACC |
| K02 | RUN |
| K03 | Logistics |
| K04 | Empty |
| K05 | Empty |
| K06 | Empty |
| Fuses | |
| F01 | Lumbar Support |
| F02 | Moonroof |
| F03 | VBAT_3 |
| F04 | VBAT_7 |
| F05 | VBAT_6 |
| F06 | Auto HVAC |
| F07 | Central Gateway Module |
| F08 | Steering Wheel Heater (ST_WHL_HTR) |
| F09 | Display |
| F10 | Radio / Infotainment System |
| F11 | OnStar System (ERA) |
| F12 | Parking Assist |
| F13 | Manual HVAC |
| F14 | Wireless Charger |
| F15 | VBAT_2 |
| F16 | VBATJ |
| F17 | Steering Wheel Controls Backlight (SWC BKLT) |
| F18 | N/A |
| F19 | N/A |
| F20 | Clock Spring |
| F21 | Occupant Sensor (OCC SEN) |
| F22 | Data Link Connector (DLC) |
| F23 | Sensing and Diagnostic Module (SDM) |
| F24 | Ignition Switch / Electronic Steering Column Lock (IGNSW/ESCL) |
| F25 | Power Liftgate Module |
| F26 | SEC FUSE-2 |
| F27 | Passenger Power Seat |
| F28 | VBAT_8 |
| F29 | DC-DC AT |
| F30 | Power Liftgate Middle |
| F31 | Outside Rearview Mirror (OSRVM) |
| F32 | Front Heated Seats Power 1 |
| F33 | VBAT_4 |
| F34 | Front Heated Seats Power 2 |
| F35 | Audio Amplifier |
| F36 | OnStar System (TCP) |
| F37 | Driver Power Seat |
| F38 | DC-DC 400W Inverter |
| F39 | SEC FUSE-1 |
| F40 | HVAC Blower Motor |
Engine Compartment Fuse Block
Located on the driver's side of the engine compartment. To access, squeeze the retaining clip on the fuse block cover and lift upward.
General view of the engine compartment fuse block.
| Diagram | |
|---|---|
|
|
| No. | Description |
| Relays | |
| K01 | Not Used |
| K02 | Not Used |
| K03 | Run/Crank Relay |
| K04 | Rear Defogger |
| K05 | Starter Solenoid |
| K06 | Starter Pinion |
| K07 | A/C Control Relay |
| K08 | Powertrain (PT) Relay |
| K09 | Diesel Fuel Heater |
| K10 | Not Used |
| K11 | Not Used |
| “Micro” Type | |
| F02 | Instrument Cluster |
| F03 | Not Used |
| F06 | Outside Rearview Mirror Defogger |
| F07 | Liftgate Release |
| F08 | AHL / AFL Motor 1 |
| F09 | Ventilated Seats |
| F10 | Not Used |
| F11 | AHL / AFL Motor 2 |
| F12 | Not Used |
| F14 | Inside Rearview Mirror (ISRVM) / Rear Vision Camera |
| F15 | DEFC Module Run/Crank |
| F16 | Headlamp Leveling |
| F17 | Not Used (Diesel) |
| F18 | Fuel Tank Zone Module |
| F19 | Not Used |
| F20 | Not Used |
| F22 | Trailer Stop/Turn Lamp Left |
| F24 | Electronic Steering Column Lock (ESCL) Emulator |
| F25 |
|
| F26 | Front and Rear Washer Pump |
| F27 | Ignition Coil (Gas) |
| ECM PT3 (Diesel) | |
| F28 | Aerodynamic Shutter |
| F29 | AHL / AFL Module |
| F31 | ECM PT2 |
| F32 | Engine Component 2 |
| F33 | Rear Vision Camera (RVC) |
| F34 | Front Fog Lamps |
| F35 | Engine Component 1 |
| F36 | ECM PT1 |
| F38 | Trailer Park Lamp |
| F40 | Auxiliary Water Pump |
| F41 | Rear Wiper |
| F42 | Horn |
| F44 | Rear Wiper Park |
| F45 | A/C Clutch |
| F46 | Not Used |
| F47 | ECM Battery (Gas) |
| ECM Battery (Diesel) | |
| F49 | Headlamp High Beam Left |
| F50 | Not Used |
| F51 | Headlamp High Beam Right |
| F52 | NOx / Soot Sensor (Diesel) |
| Trailer Stop/Turn Lamp Right | |
| F53 | Not Used |
| F54 | Passive Entry / Passive Start (PEPS) |
| F56 | Canister Vent Solenoid (Gas) / DEFC |
| Module (Diesel) | |
| F57 | DEFC Module (Diesel) |
| F58 | Transmission Control Module (TCM) Battery |
| SF01-SF06 | Spare |
| ET Type | |
| F48 | Glow Plug |
| J-Case Type | |
| F01 | Not Used |
| F05 | Not Used |
| F13 | Rear Window Defogger |
| F21 | E-Boost Power 1 |
| F23 | Starter Pinion |
| F59 | Not Used |
| F62 | Diesel Fuel Heater |
| F63 | Not Used |
| M-Case Type | |
| F04 | Front Wiper |
| F30 | Starter Solenoid |
| F37 | Auxiliary Oil Pump |
| F39 | Not Used |
| F43 | Power Window Right |
| F55 | Power Window Left |
| F60 | Defogger Heater |
| F61 | Not Used |
