This article provides a detailed overview of the fuse block diagrams for the first-generation Buick Rendezvous: 2002, 2003, 2004, 2005, 2006, and 2007 model years.
Fuse #32 in the engine compartment fuse block protects the front 12V auxiliary power outlet and the front cigar lighter.
Engine Compartment Fuse Block
Located on the passenger side, beneath the plastic access panel.
Accessing the fuse block.
General overview.
3.6L V6 Engine
Underhood fuse block assignment for Buick Rendezvous models equipped with the 3.6L V6 engine.
| Diagram | |
|---|---|
|
|
| No. | Description |
| R49 | Horn Relay |
| R50 | Fuel Pump Relay |
| R51 | Air Conditioning (A/C) Clutch Relay |
| R52 | Daytime Running Lamps (DRL) Relay |
| R53 | Low-Beam Headlamps Relay |
| R54 | Parking Lamps Relay |
| R55 | High-Beam Headlamps Relay |
| R56 | Fog Lamps Relay |
| R57 | Starter Relay |
| R58 | Cooling Fan Series/Parallel (S/P) Relay |
| R59 | Powertrain Relay |
| R60 | Cooling Fan 2 Relay |
| R61 | Cooling Fan 1 Relay |
| R62 | Ignition Relay |
| 1 | Fuel Pump |
| 2 | Air Conditioning (A/C) Compressor Clutch |
| 3 | Horn |
| 4 | Anti-lock Brake System (ABS) |
| 5 | Engine Control Module (ECM) |
| 6 | Powertrain Relay |
| 7 | Powertrain Sensors |
| 8 | Transmission Control Module (TCM) |
| 9 | Anti-lock Brake System (ABS) Solenoid Valves |
| 10 | Oxygen Sensor / Mass Air Flow (MAF) Sensor |
| 11 | Fuel Injectors (Even) |
| 13 | Fuel Injectors (Odd) |
| 14 | Daytime Running Lamps (DRL) |
| 15 | Low-Beam Headlamp, Passenger Side |
| 16 | Transmission |
| 17 | Low-Beam Headlamp, Driver Side |
| 18 | High-Beam Headlamp, Driver Side |
| 19 | Ignition Switch Battery Power |
| 20 | Parking Lamps |
| 21 | Engine Control Module (ECM) |
| 23 | High-Beam Headlamp, Passenger Side |
| 24 | Vent Solenoids |
| 25 | DVD System |
| 26 | Front Fog Lamps |
| 27 | Ignition Relay |
| 28 | Body Control Module (BCM) |
| 29 | S-Band |
| 30 | All-Wheel Drive (AWD) Control Module |
| 31 | Cruise Control |
| 32 | Front Power Outlets/Lights, OnStar® System, Cigar Lighter |
| 33 | Automatic Transaxle Shift Lock Control Module |
| 34 | Starter Solenoid Battery Power |
| 35 | Anti-lock Brake System (ABS) Motor |
| 38 | Engine Cooling Fan 2 |
| 39 | Engine Cooling Fan 1 |
| 40 | Retained Accessory Power (RAP) Relay and Accessory Relay (Main) |
| 41 | Heated Seats, Air Conditioning, Defogger (Main) |
| 44 | Power Outlets, Level Control, Power Seats, Power Mirrors, and Body Control Module (Main) |
| 46 | Climate Control Blower and Ignition 3 Relay (Main) |
| 47 | Ignition Switch, Radio, Head-Up Display (HUD), Remote Keyless Entry (RKE), Instrument Panel Cluster (IPC), Air Conditioning, and Body Control Module (Main) |
| 70 | Air Conditioning (A/C) Compressor Clutch Diode |
| 71 | Ignition Diode |
3.4L V6 Engine
Underhood fuse block assignment for Buick Rendezvous models equipped with the 3.4L V6 engine.
| Diagram | |
|---|---|
|
|
| No. | Description |
| R50 | Horn Relay |
| R51 | Fuel Pump Relay |
| R52 | Air Conditioning (A/C) Clutch Relay |
| R53 | Daytime Running Lamps (DRL) Relay |
| R54 | Low-Beam Headlamps Relay |
| R55 | Parking Lamps Relay |
| R56 | High-Beam Headlamps Relay |
| R57 | Fog Lamps Relay |
| R58 | Starter Relay |
| R59 | Cooling Fan Relay |
| R60 | Ignition 1 Relay |
| R61 | Cooling Fan Relay |
| R62 | |
| R63 | Air Pump Relay |
| 1 | Fuel Pump |
| 2 | Air Conditioning (A/C) Compressor Clutch |
| 3 | Horn |
| 4 | Engine Controls — Emissions and Sensors |
| 5 | Powertrain Control Module (PCM) |
| 6 | Anti-lock Brake System (ABS) Control Module |
| 7 | Transaxle Solenoids |
| 8 | Not Used |
| 9 | Anti-lock Brake System (ABS) Solenoid Valves |
| 10 | Oxygen Sensors — Emissions Control Module |
| 11 | Fuel Injectors (Even) |
| 12 | Not Used |
| 13 | Engine Controls |
| 14 | Daytime Running Lamps (DRL) |
| 15 | Low-Beam Headlamp, Passenger Side |
| 16 | Not Used |
| 17 | Low-Beam Headlamp, Driver Side |
| 18 | High-Beam Headlamp, Driver Side |
| 19 | Ignition Switch Battery Power |
| 20 | Front and Rear Parking Lamps |
| 21 | Air Pump — Emissions Controls |
| 22 | Not Used |
| 23 | High-Beam Headlamp, Passenger Side |
| 24 | Vent Solenoids |
| 25 | Not Used |
| 26 | Front Fog Lamps |
| 27 | Ignition Relay, Neutral Start Switch, Powertrain Control Module (PCM) |
| 28 | Body Control Module (BCM) — Battery Power |
| 29 | L-Band, Remote Digital Radio Receiver |
| 30 | All-Wheel Drive (AWD) Control Module |
| 31 | Cruise Control System |
| 32 | Front 12V Power Outlets/Lights, OnStar® System, Cigar Lighter |
| 33 | Automatic Transaxle Shift Lock Control System |
| 34 | Not Used |
| 35 | Starter Solenoid Battery Power |
| 36 | Anti-lock Brake System (ABS) Motor |
| 37 | Not Used |
| 38 | Not Used |
| 39 | Engine Cooling Fan 2 |
| 40 | Engine Cooling Fan 1 |
| 41 | Retained Accessory Power (RAP) Relay and Accessory Relay (Main) |
| 42 | Heated Seats, Air Conditioning (Main) |
| 43 | Not Used |
| 44 | Not Used |
| 45 | Power Outlets, Level Control, Power Seats, Power Mirrors, and Body Control Module (Main) |
| 46 | Not Used |
| 47 | Climate Control Blower and Ignition 3 Relay (Main) |
| 48 | Ignition Switch, Radio, Head-Up Display (HUD), Remote Keyless Entry (RKE), Instrument Panel Cluster (IPC), Air Conditioning, and Body Control Module (Main) |
| 49 | Not Used (Circuit Breaker) |
| 64-69 | Not Used |
| 70 | Fuse Puller |
| Diode | Air Conditioning (A/C) Compressor Clutch Diode |
Passenger Compartment Fuse Block
Located in the center console near the floor on the passenger side, behind the plastic access panel.
General overview of the fuse block.
| Diagram | |
|---|---|
|
|
| No. | Description |
| Relays | |
| R20 | Rear Defogger |
| R23 | Ignition |
| R27 | Accessory |
| R33 | Retained Accessory Power (RAP) |
| R43 | Accessory Diode |
| R45 | 2005-2007: Back-Up Lamps |
| Fuses | |
| 1 | 2002-2003: Fuse Puller |
| 2004-2007: Not Used | |
| 2 | Steering Wheel Radio Controls |
| 3 | Power Door Locks |
| 4 | Not Used |
| 5 | Not Used |
| 6 | Not Used |
| 7 | Not Used |
| 8 | Not Used |
| 9 | Not Used |
| 10 | Turn Signal and Hazard Lamp Flashers |
| 11 | Power Seats |
| 12 | Electronic Level Control (ELC) Compressor |
| 13 | Liftgate and Endgate |
| 14 |
|
| 15 | Electronic Level Control (ELC) Compressor Relay and Height Sensor |
| 16 | Heated Mirrors Control Module |
| 17 | Power Mirror Control Module |
| 18 | Ignition 1 |
| 19 | 2002-2003: Turn Signal Switch / Neutral Safety Backup (NSBU) Switch |
| 2003-2007: Turn Signal Switch | |
| 21 | Rear Defogger |
| 22 | Airbag Control Module |
| 24 | 2002-2003: Canister Vent Solenoid and Torque Converter Clutch (TCC) Switch |
| 2004-2007: Torque Converter Clutch (TCC) Switch | |
| 25 | HVAC Blower Motor |
| 26 | HVAC Mode and Temperature Motors, and Head-Up Display (HUD) |
| 28 | Accessory Power |
| 29 | Windshield Wipers and Washer |
| 30 | Instrument Panel Cluster (IPC), Body Control Module (BCM), PASS-Key® III System |
| 31 | Park Lock Ignition Key Solenoid |
| 32 | Rear Window Wiper/Washer |
| 34 | Power Moonroof |
| 35 | Power Windows |
| 36 | Map Lamps, Courtesy Lamps, and Instrument Panel Lights |
| 37 | Radio |
| 38 | UQ3 Premium Audio Amplifier |
| 39 | Head-Up Display (HUD) |
| 40 | Hazard Flashers |
| 41 | Instrument Panel Cluster (IPC), Climate Control System, Security LED, and Remote Keyless Entry (RKE) Mode |
| 42 | PASS-Key® III System |
| 44 | Body Control Module (BCM) |
| 46 | Automatic Occupant Sensing Module |
