This article provides a detailed overview of the fuse diagrams for the third-generation Cadillac Escalade (GMT900), covering the 2007, 2008, 2009, 2010, 2011, 2012, 2013, and 2014 model years.
Fuses #2 and #16 (AUX PWR) in the passenger compartment, along with fuse #53 in the engine compartment, supply power to the cigarette lighter and 12V accessory power outlets.
Engine Compartment
The primary fuse block is located in the engine compartment. Hybrid models feature an additional auxiliary fuse block.
Main Fuse Block
Located on the driver’s side, beneath the plastic cover.
Cover removal illustration.
Component overview.
2008–2014 Model Years
Fuse assignments for vehicles manufactured between 2008 and 2014.
| Diagram |
|
| No. |
Assignment |
| Relays |
| FAN HI |
High-Speed Cooling Fan |
| FAN LO |
Low-Speed Cooling Fan |
| FAN CNTRL |
Cooling Fan Control |
| HDLP LO/HID |
Headlamp High-Intensity Discharge (HID) |
| FOG LAMP |
Front Fog Lamps |
| A/C CMPRSR |
A/C Compressor |
| STRTR |
Starter |
| PWR/TRN |
Powertrain |
| FUEL PMP |
Fuel Pump Relay |
| PRK LAMP |
Parking Lamps |
| REAR DEFOG |
Rear Defogger |
| RUN/CRANK |
Run/Crank (Switched Power) |
| J-Case |
| 57 |
Cooling Fan 1 |
| 58 |
Automatic Level Control Compressor |
| 59 |
Heavy-Duty Antilock Brake System (ABS) |
| 60 |
Cooling Fan 2 |
| 61 |
Antilock Brake System (ABS) 1 |
| 62 |
Starter Relay |
| 63 |
Stud 2 (Trailer Brakes) |
| 64 |
Left Bussed Electrical Center 1 |
| 65 |
Electric Running Boards |
| 66 |
Heated Windshield Washer |
| 67 |
- 2011–2014: Transfer Case
- 2008–2010: Four-Wheel Drive
|
| 68 |
Stud 1 (Battery Power Trailer Connector) |
| 69 |
Mid-Bussed Electrical Center 1 |
| 70 |
Climate Control Blower Motor |
| 71 |
Power Liftgate Module |
| 72 |
Left Bussed Electrical Center 2 |
| Fuses |
| 1 |
Right Trailer Stop/Turn Signal |
| 2 |
Electronic Stability Suspension Control, Automatic Level Control Exhaust |
| 3 |
Left Trailer Stop/Turn Signal |
| 4 |
Engine Controls |
| 5 |
Engine Control Module (ECM), Electronic Throttle Control (ETC) |
| 6 |
Trailer Brake Controller |
| 7 |
Front Washer |
| 8 |
Oxygen Sensors |
| 9 |
Antilock Brake System (ABS) 2 |
| 10 |
Trailer Reverse Lamps |
| 11 |
Driver’s Side Low-Beam Headlamp |
| 12 |
Engine Control Module (Battery) |
| 13 |
Right Bank Fuel Injectors and Ignition Coils |
| 14 |
Transmission Control Module (Battery) |
| 15 |
Vehicle Reverse Lamps |
| 16 |
Passenger’s Side Low-Beam Headlamp |
| 17 |
A/C Compressor |
| 18 |
Oxygen Sensors |
| 19 |
Transmission Controls (Ignition) |
| 20 |
Fuel Pump Fuse |
| 21 |
Fuel System Control Module |
| 22 |
Headlamp Washers |
| 23 |
Rear Windshield Washer |
| 24 |
Left Bank Fuel Injectors and Ignition Coils |
| 25 |
Trailer Park Lamps |
| 26 |
Driver’s Side Park Lamps |
| 27 |
Passenger’s Side Park Lamps |
| 28 |
Fog Lamps |
| 29 |
Horn |
| 30 |
Passenger’s Side High-Beam Headlamp |
| 31 |
Daytime Running Lamps (DRL) (If Equipped) |
| 32 |
Driver’s Side High-Beam Headlamp |
| 33 |
Daytime Running Lamps (DRL) 2 (If Equipped) |
| 34 |
Moonroof |
| 35 |
Ignition Switch and Theft-Deterrent System |
| 36 |
Windshield Wiper |
| 37 |
SEO B2 Upfitter Usage (Battery) |
| 38 |
Power Adjustable Pedals |
| 39 |
Climate Controls (Battery) |
| 40 |
Airbag (Ignition) |
| 41 |
Audio Amplifier |
| 42 |
Audio System / Radio |
| 43 |
Miscellaneous (Ignition), Cruise Control Module |
| 44 |
Liftgate Release |
| 45 |
Airbag (Battery) |
| 46 |
Instrument Panel Cluster (IPC) |
| 47 |
- 2011–2014: Empty
- 2008–2010: Power Take-Off (PTO)
|
| 48 |
- 2011–2014: Auxiliary Climate Control (Ignition)
- 2008–2010: Auxiliary Climate Control (Ignition), Compass-Temperature Mirror
|
| 49 |
Center High-Mounted Stoplamp (CHMSL) |
| 50 |
Rear Defogger |
| 51 |
Mirror Heater |
| 52 |
SEO B1 Upfitter Usage (Battery) |
| 53 |
Cigarette Lighter, Auxiliary 12V Power Outlet |
| 54 |
- 2011–2014: Automatic Level Control Compressor Relay
- 2008–2010: Automatic Level Control Compressor Relay, SEO Upfitter Usage
|
| 55 |
Climate Controls (Ignition) |
| 56 |
ECM, Secondary Fuel Pump (Ignition) |
2007 Model Year
Fuse assignments for vehicles manufactured in 2007.
| Diagram |
|
| No. |
Assignment |
| Relays |
| A/C CMPRSR |
A/C Compressor |
| ENG EXH VLV |
Empty |
| FAN CNTRL |
Cooling Fan Control |
| FAN HI |
High-Speed Cooling Fan |
| FAN LO |
Low-Speed Cooling Fan |
| FOG LAMP |
Front Fog Lamps |
| FUEL PMP |
Fuel Pump Relay |
| HDLP LO/HID |
Headlamp - High-Intensity Discharge (HID) |
| PRK LAMP |
Parking Lamps |
| PWR/TRN |
Powertrain |
| REAR DEFOG |
Rear Defogger |
| RUN/CRANK |
Run/Crank (Switched Power) |
| STRTR |
Starter Relay |
| J-Case |
| 75 |
Left Bussed Electrical Center 2 |
| 74 |
Power Liftgate Module |
| 73 |
Climate Control Blower Motor |
| 72 |
Mid-Bussed Electrical Center 1 |
| 71 |
Stud 1 (Trailer Connector Battery Power) |
| 70 |
Empty |
| 69 |
Heated Windshield Washer System |
| 68 |
Electric Running Boards |
| 67 |
Left Bussed Electrical Center 1 |
| 66 |
Stud 2 (Trailer Brakes) |
| 65 |
Starter |
| 64 |
Antilock Brake System (ABS) 1 |
| 63 |
Cooling Fan 2 |
| 62 |
Empty |
| 61 |
Automatic Level Control Compressor |
| 60 |
Cooling Fan 1 |
| Fuses |
| 1 |
Empty |
| 2 |
Electronic Stability Suspension Control, Automatic Level Control Exhaust |
| 3 |
Left Trailer Stop/Turn Signal |
| 4 |
Engine Controls |
| 5 |
Engine Control Module (ECM), Electronic Throttle Control (ETC) |
| 6 |
Right Trailer Stop/Turn Signal |
| 7 |
Front Washer |
| 8 |
Oxygen Sensors |
| 9 |
Antilock Brake System (ABS) 2 |
| 10 |
Trailer Reverse Lamps |
| 11 |
Driver’s Side High-Intensity Discharge (HID) Headlamp |
| 12 |
Engine Control Module (Battery) |
| 13 |
Right Bank Fuel Injectors and Ignition Coils |
| 14 |
Transmission Control Module (TCM) (Battery) |
| 15 |
Vehicle Reverse Lamps |
| 16 |
Passenger’s Side High-Intensity Discharge (HID) Headlamp |
| 17 |
A/C Compressor |
| 18 |
Oxygen Sensors |
| 19 |
Transmission Controls (Ignition) |
| 20 |
Fuel Pump Fuse |
| 21 |
Empty |
| 22 |
Rear Windshield Washer |
| 23 |
Left Bank Fuel Injectors and Ignition Coils |
| 24 |
Trailer Park Lamps |
| 25 |
Driver’s Side Park Lamps |
| 26 |
Passenger’s Side Park Lamps |
| 27 |
Fog Lamps |
| 28 |
Horn |
| 29 |
Passenger’s Side High-Beam Headlamp Solenoid |
| 30 |
Daytime Running Lamps (DRL) Module |
| 31 |
Driver’s Side High-Beam Headlamp Solenoid |
| 32 |
Empty |
| 33 |
Moonroof |
| 34 |
Ignition Switch and Theft-Deterrent System |
| 35 |
Windshield Wiper |
| 36 |
SEO B2 Upfitter Usage (Battery) |
| 37 |
Power Adjustable Pedals |
| 38 |
Climate Controls (Battery) |
| 39 |
Airbag (Ignition) |
| 40 |
Audio Amplifier |
| 41 |
Audio System / Radio |
| 42 |
Empty |
| 43 |
Miscellaneous (Ignition), Rear Vision Camera (If Equipped), Cooled Seats, Cruise Control |
| 44 |
Liftgate Release |
| 45 |
OnStar® System, Rear Seat Entertainment Display |
| 46 |
Instrument Panel Cluster (IPC) |
| 47 |
Empty |
| 48 |
Steering Wheel Heater |
| 49 |
Auxiliary Climate Control (Ignition), Compass-Temperature Mirror |
| 50 |
Rear Defogger |
| 51 |
Airbag (Battery) |
| 52 |
SEO B1 Upfitter Usage (Battery) |
| 53 |
Cigarette Lighter, Auxiliary 12V Power Outlet |
| 54 |
Automatic Level Control Compressor Relay, SEO Upfitter Usage |
| 55 |
Climate Controls (Ignition) |
| 56 |
ECM, Secondary Fuel Pump (Ignition) |
Auxiliary Fuse Block (Hybrid Models Only)
This unit is equipped on vehicles featuring the LZ1 hybrid powertrain.
| Diagram |
|
| No. |
Description |
CAB HTR
PUMP |
Cabin Heater Pump |
| COOL PUMP |
Coolant Pump Relay |
| FAN CNTRL |
Cooling Fan Control |
| FAN HI |
High-Speed Cooling Fan Relay |
| FAN LO |
Low-Speed Cooling Fan Relay |
| FAN MID 1 |
Cooling Fan Mid 1 |
| FAN MID 2 |
Cooling Fan Mid 2 |
| FAN 1 |
Cooling Fan 1 (J-Case) |
| FAN 2 |
Cooling Fan 2 (J-Case) |
| TRANS PUMP |
Auxiliary Transmission Fluid Pump (J-Case) |
| 1 |
ACPO (SUV Only) |
| 2 |
BECM Fan |
| 3 |
ACCM |
| 4 |
Cabin Heater Pump |
| 5 |
Not Used |
| 6 |
Coolant Pump |
| 7 |
Electronic Power Steering (EPS) System |
| 8 |
Drive Motor/Generator Control Module |
| 9 |
| 10 |
BECM |
Passenger Compartment
There are two fuse blocks located within the cabin: a primary and a secondary block.
Primary Fuse Block
Located on the driver’s side edge of the instrument panel, beneath the plastic cover.
Cover removal illustration.
Component overview.
2008–2014 Model Years
Fuse assignments for vehicles manufactured between 2008 and 2014.
| Diagram |
|
| No. |
Description |
| 1 |
Rear Seats |
| 2 |
Rear Cargo Area 12V Power Outlets |
| 3 |
Steering Wheel Controls Backlight |
| 4 |
Driver Door Module (DDM) |
| 5 |
Driver’s Side Turn Signal / Dome Lamps |
| 6 |
Stoplamp / Driver’s Side Turn Signal |
| 7 |
Instrument Panel Backlighting |
| 8 |
Passenger’s Side Turn Signal, Stoplamp |
| 9 |
- 2011–2014: Passenger Door Module, Driver Unlock
- 2008–2010: Passenger Door Module
|
| 10 |
Power Door Lock 2 (Unlock Feature) |
| 11 |
Power Door Lock 2 (Lock Feature) |
| 12 |
Stoplamps, Center High-Mounted Stoplamp (CHMSL) |
| 13 |
Rear Climate Controls |
| 14 |
- 2011–2014: Power Mirror
- 2008–2010: Not Used
|
| 15 |
Body Control Module (BCM) |
| 16 |
12V Accessory Power Outlets |
| 17 |
Interior Lamps |
| 18 |
Power Door Lock 1 (Unlock Feature) |
| 17 |
Rear Seat Entertainment |
| 20 |
Ultrasonic Rear Parking Assist (URPA), Power Liftgate |
| 21 |
Power Door Lock 1 (Lock Feature) |
| 22 |
Driver Information Center (DIC) |
| 23 |
Rear Wiper |
| 24 |
- 2011–2014: Cooled Seats
- 2008–2010: Not Used
|
| 25 |
Driver Seat Module, Remote Keyless Entry System |
| 26 |
- 2011–2014: Driver Power Door Lock (Unlock Feature)
- 2008–2010: Not Used
|
| LT DR |
2011–2014: Driver’s Side Power Window Circuit Breaker |
| Driver’s Door Harness Connection |
| BODY |
Harness Connector |
2007 Model Year
Fuse assignments for vehicles manufactured in 2007.
| Diagram |
|
| No. |
Assignment |
| AUX PWR |
12V Accessory Power Outlets |
| AUX PWR2 |
Rear Cargo Area 12V Power Outlets |
| BCM |
Body Control Module |
| BODY |
Harness Connector |
| COOLED SEATS |
Cooled Seats |
| CTSY |
Dome Lamps, Driver’s Side Turn Signal |
| DDM |
Driver Door Module |
| DIM |
Instrument Panel Backlighting |
| DSM |
- Remote Keyless Entry System
- Driver Seat Module
|
| IS LPS |
Interior Lamps |
| LCK1 |
Power Door Lock 1/2 (Lock Feature) |
| LCK2 |
| LT DR |
Driver’s Side Power Window Circuit Breaker |
| LT DR |
Driver’s Door Harness Connection |
| LT STOP TRN |
Stoplamp / Driver’s Side Turn Signal |
| OBS DET |
Power Liftgate / Ultrasonic Rear Parking Assist (URPA) |
| PDM |
Universal Home Remote System / Passenger Door Module |
| REAR HVAC |
Rear Climate Controls |
| REAR SEAT |
Rear Seats |
| REAR WPR |
Rear Wiper |
| RT STOP TRN |
Stoplamp / Passenger’s Side Turn Signal |
| STOP LAMPS |
Center High-Mounted Stoplamp (CHMSL) / Stoplamps |
| SWC BKLT |
Steering Wheel Controls Backlight |
| UNLCK1 |
Power Door Lock 1 / 2 (Unlock Feature) |
| UNLCK2 |
Secondary Fuse Block
Located beneath the instrument panel, to the left of the steering column.
| Diagram |
|
| HEADLINER |
Headliner Harness Connector 1/2/3 |
| BRAKE CLUTCH |
Brake Clutch Harness Connector |
| SEO/UPFITTER |
Special Equipment Option (SEO) Upfitter Harness Connector |
| CB1 |
Passenger’s Side Power Window Circuit Breaker |
| CB2 |
Passenger’s Seat Circuit Breaker |
| CB3 |
Driver’s Seat Circuit Breaker |
| CB4 |
Empty |
| BODY |
Body Harness Connector 1/2/3 |
