This material discusses in detail the fuse diagrams of the Porsche Macan (first generation / body brand 95B): 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023 of release.
Fuses numbered 10 and 11 (panel D) in the trunk block are responsible for protecting the electrical circuit of the cigarette lighter.
In the trunk
The mounting block is located on the right side behind the luggage compartment trim.
Access example.
| Diagram | ||
|---|---|---|
|
||
| No. | Amps | Description |
| Panel A | ||
| 1 | 40A | Compressor relay for Porsche Active Suspension Management (PASM) |
| 2 | 50A | plug socket |
| 3 | 40A | Ignition |
| 4 | - | Not involved |
| 5 | - | Not involved |
| 6 | - | Crash CAN |
| Panel B | ||
| 1 | 5A | Gateway, Ignition Relay |
| 2 | 20A | trailer control module |
| 3 | 20A | trailer control module |
| 4 | 20A | trailer control module |
| 5 | 20A | Passenger seat control module |
| 6 | - | Not involved |
| 7 | 30A | Electric parking brake (Electric Parking Brake (EPB)) |
| 8 | 20A | Rear Body Control Module (BCM) |
| 9 | 20A | Rear Body Control Module (BCM) |
| 10 | 25A | Rear Body Control Module (BCM) |
| 11 | 25A | Rear Body Control Module (BCM) |
| 12 | 5A | Tire Pressure Monitoring System (TPMS) |
| Panel C | ||
| 1 | 30A | trailer connector |
| 2 | - | Not involved |
| 3 | 30A | DC/DC converter for start-stop system |
| 4 | 30A | DC/DC Converter for Start-Stop System, Amplifier Power Supply, Overhead Console |
| 5 | 25A | Subwoofer |
| 6 | 5A | TV tuner |
| 7 | 30A | Electric parking brake (Electric Parking Brake (EPB)) |
| 8 | 30A | Rear control box |
| 9 | 20A | Control unit in front passenger door |
| 10 | 5A | Telestar receiver |
| 11 | 20A | Control unit in rear right door |
| 12 | 5A | Luggage compartment lighting, Wireless phone charger |
| Panel D | ||
| 1 | - | Not involved |
| 2 | 5A |
|
| 3 | 15A | Rear wiper |
| 4 | 15A | Terminal 15, instrument panel |
| 5 | - | Not involved |
| 6 | - | Not involved |
| 7 | - | Not involved |
| 8 | 7.5A | ceiling console |
| 9 | 5A | Adaptive Cruise Control (ACC) |
| 10 | 20A | Cigarette lighter fuse Porsche Macan, socket in the armrest |
| 11 | 20A | Cigarette lighter sockets in the rear of the center console and in the luggage compartment |
| 12 | 7.5A | Multimedia system for rear passengers |
| Panel E | ||
| 1 | 15A | Rear passenger climate control unit |
| 2 | 10A | Central information and communication system (Porsche Communication Management (PCM)) / CAN adapter |
| 3 | - | Not involved |
| 4 | - | Not involved |
| 5 | - | Not involved |
| 6 | 5A |
|
| 7 | 25A | Heated rear window (relay) |
| 8 | 30A | Air conditioner |
| 9 | 20A | tailgate control unit |
| 10 | 15A | Porsche Active Suspension Management (PASM) control unit |
| 11 | 10A | Rear differential lock |
| 12 | 30A | |
In the passenger compartment
There are two blocks responsible for protecting the electrical circuits of the car.
Passenger side
The first fuse box is located behind the lining of the left end of the dashboard.
Photo is an example.
| Diagram | ||
|---|---|---|
|
||
| No. | Amps | Description |
| Panel A | ||
| 1 | 5A | Diagnostic connector |
| 2 | 5A | Ignition lock |
| 3 | 5A | Egnition lock |
| 4 | 5A | Steering column lock |
| 5 | 5A | before 2016: Steering column adjustment |
| 15A | from 2017: Steering column adjustment | |
| 6 | - | Reserve |
| 7 | 5A | Steering column |
| 8 | 5A | Diagnostic connector |
| 9 | 5A | PTC |
| 10 | - | - |
| 11 | 5 | Not involved |
| 12 | 10 | Not involved |
| Panel B | ||
| 1 | - | Reserve |
| 2 | 5A | Compass |
| 3 | 10A | Heated steering column and steering wheel |
| 4 | 5A | instrument cluster |
| 5 | 20A | Not involved |
| 6 | 30A | Not involved |
| 7 | - | Reserve |
| 8 | 30A | fan motor |
| 9 | 30A | Wiper |
| 10 | 20A | Driver's seat back adjustment |
| 11 | 20A | Passenger seat back adjustment |
| 12 | - | Reserve |
From the driver's side
The second fuse block is located behind the facing of the right end of the dashboard.
General form.
| Diagram | ||
|---|---|---|
|
||
| No. | Amps | Purpose |
| Panel A | ||
| 1 | 7.5A | Front Camera, Parking Assist Before 2016: Adaptive Cruise Control (ACC) (2014-2016) |
| 2 | 10A | Airbags, Seat Occupancy Detection |
| 3 | 5A |
|
| 4 | 5A | Front seat ventilation |
| 5 | 5A | Headlight control unit, Left headlight (halogen lamps), Headlight range control, Right headlight (halogen lamps) |
| 6 | 7.5A | Right headlight (Bi-Xenon) |
| 7 | 7.5A | before 2016: Left headlight (Bi-Xenon) |
| 5A | from 2017: Left headlight (Bi-Xenon) | |
| 8 | 5A | Engine control unit, Anti-theft system (Porsche Vehicle Tracking System (PVTS)), Rear body electronics (BCM) |
| 9 | - | Not occupied |
| 10 | 5A | Refrigerant pressure sensor |
| 11 | 5A | Lane Change Assist (LCA) |
| 12 | 15A | Engine electronics |
| Panel B | ||
| 1 | - | Not occupied |
| 2 | - | Not occupied |
| 3 | - | Not occupied |
| 4 | - | Not occupied |
| 5 | 30A | Instrument Cluster, Heated Steering Column and Steering Wheel, Compass, Diagnostic Connector |
| 6 | 30A | Brake booster (trailer) |
| 7 | 15A | Horn |
| 8 | 20A | Control unit in the driver's door |
| 9 | - | Not used |
| 10 | 30A | Porsche Stability Management (PSM) |
| 11 | 20A | Control unit in rear left door |
| 12 | 5A | Anti-theft system (Porsche Vehicle Tracking System (PVTS)), Electric parking brake (Electric Parking Brake (EPB)), Rain sensor |
| Panel C | ||
| 1 | - | Not occupied |
| 2 | - | Not occupied |
| 3 | - | Not occupied |
| 4 | 20A | driver's seat control unit |
| 5 | 5A | Fuel System Diagnostic Pump |
| 6 | 30A | Front Body Control Module (BCM) |
| 7 | 30A | Front Body Control Module (BCM) |
| 8 | 30A | Front Body Control Module (BCM) |
| 9 | 20A | A roof with a panoramic view |
| 10 | 30A | Front Body Control Module (BCM) |
| 11 | 20A | A roof with a panoramic view |
| 12 | 5A | Alarm siren |
