Fuses and relays Cadillac Catera (1996-2001)

This article provides detailed fuse block diagrams for the first-generation Cadillac Catera, covering model years 1996, 1997, 1998, 1999, 2000, and 2001.

Fuses #14 and #16 in the passenger compartment fuse block protect the cigar lighter circuits.

Engine Compartment


The engine compartment fuse block is located on the driver’s side of the engine bay, adjacent to the battery.


Remove the cover to access the fuses and relays.


General overview.

Type 1

Engine compartment fuse block layout (Version 1).

Diagram
No. Description
1 Secondary Air Injection Pump (Relay K12)
2 Cooling Fan Control (Relay K67)
3 Auxiliary Coolant Pump (Relay K22)
4 Windshield Wiper Motor (Relay K8)
5 A/C Compressor Relay (K60)
6 Cooling Fan Control Relay (K87)
7 Cooling Fan Control Relay (K26)
8 Fuse #50
9 Cooling Fan Control Relay (K28)
10 Engine Controls Power Relay (K43)
15 Fuse #40 (A)
Fuse #52 (B)
16 Connector C110
17 Cooling Fan Test Connector
18 Fuse #42 (A)
Fuse #49 (B)
19 Cooling Fan Control Relay (K52)
20 Fuel Pump Relay (K44)
25 Fuse #43

Type 2

Engine compartment fuse block layout (Version 2).

Diagram
No. Description
1 Secondary Air Injection Pump (Relay K12)
2 Cooling Fan Control Relay
3 Auxiliary Coolant Pump (Relay K22)
4 Windshield Wiper Motor (Relay K8)
5 A/C Compressor Relay (K60)
6 Cooling Fan Control Relay (K87)
7 Cooling Fan Control Relay (K26)
8 Cooling Fan Control (Fuse #42)
9 Secondary Air Injection Pump (Fuse #49)
10 Engine Controls Power Relay (K43)
12 Cooling Fan Control (Fuse #40)
15 Cooling Fan Control (Fuse #52)
16 Connector C110
17 Cooling Fan Control Relay (#K52)
18 Cooling Fan Control Relay (#K28)
19 Cooling Fan Control Relay
Engine Control Module (ECM) Relay (Fuse #50)
20 Fuel Pump Relay (K44)
27 Heated Oxygen Sensors (Fuse 43)
28 Engine Control Module (ECM) (Fuse #60)
29 Engine Control Module Relay (K48)
39 Cooling Fan Test Connector

Passenger Compartment


The interior fuse block and relay panel are located behind the lower dash trim panel, below the steering column.


Access procedure. Relay Panel #2 is located to the right of the main fuse block.

Fuse Block #1


General overview.

Diagram
No. Description
1 Left and Right Front Power Window Motors,
Left Front Power Window Switch
2 Cruise Control Release Switch / Brake Light Switch
3 Automatic Transmission: Transmission Range (TR) Switch, Shift Indicator, Winter Mode Switch
Hazard Warning Switch and Power Steering Control Module
Transmission Control Module (TCM)
4 Power Rear Sunshade Motor / Left and Right Rear Heated Seat Cushion Relays
Accessory 12V Power Outlet
5 Transmission Control Module (TCM)
6 Audio Amplifier
7 Left and Right Rear Power Window Motors
8 Headlight and Turn Signal Switch, Horn Relay, CD Changer, Multi-Function Relay
9 Windshield Wiper and Windshield Washer Switch / Windshield Wiper Motor and Relay
10 Body Control Module (BCM)
Auxiliary Heater Coolant Pump and Relay
Cooling Fan Relays
11 HVAC Control Module
Left and Right Power Outside Mirrors
12 Hazard Warning Switch,
Instrument Panel Cluster (IPC),
Data Link Connector (DLC),
Brake Light Switch,
Instrument Panel Cluster (IPC),
HVAC Control Module.
13 Power Mirror Switch,
A/C Compressor Relay,
Cooling Fan Test Connector,
A/C Load Switch
14 Cellular Telephone Module,
Cigar Lighter Fuse (1996–1998)
Heated Windshield Washer Nozzles
Driver and Passenger Heated Seat Switches
HVAC Control Module
Heated Outside Mirror and Rear Defogger Relay
15 Electronic Level Control (ELC) Air Compressor Relay
Instrument Panel Cluster (IPC)
Instrument Panel Cluster (IPC) / Multi-Function Relay
Cruise Control Switch
Headlight Switch
Heated Seat Relay (Passenger and Driver)
Body Control Module (BCM)
Power Sunroof / Moonroof Actuator
Electronic Level Control (ELC) Sensor,
Heated Rear Seat Switch and Cushion Relay (Left and Right)
Driver Seat Adjuster Memory Module,
Left Front Power Window Switch,
Interior Rearview Mirror
16 Front and Console Cigar/Cigarette Lighter Fuse (1999–2001)
17 Dual Horns (#1 and #2)
18 Fuel Pump Fuse
19 Electronic Brake Control Module (EBCM) / Traction Control System (TCS)
20 Heated Seat Relay (Passenger and Driver)
21 Daytime Running Lamp (DRL) Relay
Left High-Beam Headlight Relay
22 Headlight Switch
Left Low-Beam Headlight
23 Left Parking and Turn Signal Lights
Left Rear Side Marker Light
Multi-Function Relay
Left Brake and Tail Light
24 Shift Interlock Solenoid,
Body Control Module (BCM)
Instrument Panel Cluster (IPC)
25 Power Sunroof / Moonroof Actuator
26 Headlight Switch,
Left and Right Front Side Marker Lights,
Center High-Mounted Stop Light (CHMSL),
Left and Right Rear License Plate Lights,
Radio Module
Automatic Transmission Shift Indicator
HVAC Control Module
27 Electronic Level Control (ELC) Sensor,
Electronic Level Control (ELC) Air Compressor and Relay
28 Door Lock Relay
29 Multi-Function Relay
OnStar System Module
30 Right Parking and Turn Signal Lights
Right Rear Side Marker Light
Right Brake and Tail Light
31 Right Low-Beam Headlight / Turn Signal Switch
32 Right High-Beam Headlight Relay
33 HVAC Blower Motor Controller
A/C Compressor Relay
34 Heated Rear Defogger Relay
35 Passenger Seat Adjuster Switch,
Driver Seat Adjuster Memory Module

Relay Panel #2


General overview.

Diagram
No. Description
I Daytime Running Lamps (DRL)
II Electronic Level Control (ELC) System
III Rear Defogger,
Heated Outside Mirrors
IV Hazard Warning Flashers
V High-Beam Headlights II (Right Side)
VI Horn
VII Parking Lights and Turn Signal Lights
VIII Low-Beam Headlights
IX Empty
X Empty
XI High-Beam Headlights I (Left Side)
