This article provides detailed fuse box diagrams and assignments for the first-generation Jeep Renegade (BU chassis) for the 2014, 2015, 2016, 2017, 2018, 2019, and 2020 model years.
Fuses F18 and F30 in the engine compartment and F94 in the passenger compartment power the cigarette lighter and 12V auxiliary power outlets.
Passenger Compartment
Located on the left side of the dashboard, near the steering column.
General view of the fuse box.
| Fuse Box Diagram | ||
|---|---|---|
|
||
| No. | Description | Rating |
| F31 | Turn Signals / HVAC Blower Fan Control / Power Front Seats | 7.5 A |
| F33 | Front Left (Driver-Side) Power Window | 25 A |
| F34 | Front Right (Passenger-Side) Power Window | 25 A |
| F36 | Uconnect® System Power, Climate Control, Security Alarm, Power-Folding Exterior Mirrors, USB Port | 20 A |
| F37 | Forward Collision Warning Plus System Power, All-Wheel Drive (AWD), Instrument Panel Cluster (IPC) | 10 A |
| F38 | Safelock Mechanism (Driver-Side Unlocking – where equipped) / Door Unlocking / Central Locking / Power Tailgate Release | 20 A |
| F42 | Switched Ignition Power (+15 / ACC) | 7.5 A |
| F43 | Windshield / Rear Window Washer Pump Control Module | 20 A |
| F47 | Rear Left Power Window | 25 A |
| F48 | Rear Right Power Window | 25 A |
| F49 | ParkSense Power, Dome Light, Rearview Mirror, Power Retractable Sunroof Motor, Front Map Lights, Heated Front Seats, ESC System, Battery Stabilizer, Electronic Steering Lock (ESL) | 7.5 A |
| F50 | Airbag Control Module Power Supply | 7.5 A |
| F51 | Security Alarm Power, Front Courtesy Lights, A/C Compressor, Brake Pedal Switch (N.C.), Automatic Transmission Gear Selector, Compass Module, Rearview Camera, Headlight Leveling, Climate Control | 7.5 A |
| F53 | Instrument Panel Cluster (IPC) Power Supply / Keyless Enter-N-Go™ System / Ignition Starter Switch | 7.5 A |
| F94 | Front Cigarette Lighter / 12V Auxiliary Power Outlet | 15 A |
Engine Compartment
Located in the engine bay near the battery, behind a protective plastic cover.
Accessing the fuse box panel.
Engine compartment fuse box overview.
| Fuse Box Diagram | ||
|---|---|---|
|
||
| No. | Description | Rating |
| “Maxi” Fuse Type | ||
| F01 | Body Control Module (BCM) | 70 A |
| F02 | Body Control Module (BCM), Rear Power Distribution Units | 70 A |
| F05 | Electric Power Steering (EPS) | 70 A |
| F06 | Engine Cooling Fan | 20 / 40 A |
| F07 | Engine Cooling Fan | 30 / 40 A |
| F15 | Brake Control Module Pump (ABS / ESC) | 40 A |
| “Mini” Fuse Type | ||
| F03 | Body Control Module (BCM) Main Power Supply | 20 A |
| F04 | Brake Control Electronics Module (ABS / ESC) | 30 A |
| F08 | Automatic Transmission, Gear Shift Module (GSM) | 30 A |
| F83 | HVAC Blower Fan | 40 A |
| “Micro” Fuse Type | ||
| F18 | Cargo Area 12V Power Outlet / Rear Cigarette Lighter Supply | 20 A |
| F19 | A/C Compressor Clutch | 7.5 A |
| F09 | Engine Control Module (ECM) | 5 A |
| F20 | Electronic Four-Wheel Drive (4WD) Power Supply | 5 A |
| F24 | Transmission Control Module (TCM) Power Supply | 15 A |
| F16 | Engine Control Module (ECM) and Automatic Transmission Power Supply | 5 A |
| F21 | Fuel Pump Fuse | 15 A |
| F88 | Heated Exterior Mirrors | 7.5 A |
| F89 | Heated Rear Window (Rear Defroster) | 30 A |
| F23 | Heated Windshield (where equipped) | 30 A |
| F14 | Blow-By Heater (“Blow-By”) | 7.5 A |
| F10 | Horn | 10 A |
| F30 | Cargo Area Cigarette Lighter / Rear 12V Power Outlet Fuse | 20 A |
| F90 | Intelligent Battery Sensor (IBS – Battery State of Charge) | 5 A |
| F22 | Powertrain Control Module (PCM) | 7.5 A |
| F84 | All-Wheel Drive (AWD) System Power Supply | 30 A |
| F14 | After-Run Coolant Pump Power Supply | 5 A |
| F87 | Automatic Transmission Shift Lever Unit | 5 A |
| F17 | Primary Loads Power Supply | 10 A |
| F11 | Secondary Loads Power Supply | 10 A |
Cargo Area
Located on the left rear side panel, behind the access cover. Depending on vehicle equipment, there may be one or two fuse panels present.
Accessing the panel.
| Fuse Box Diagram | ||
|---|---|---|
| No. | Description | Rating |
| Panel #1 | ||
|
||
| F2 | Audio System / Amplifier | 20 A |
| F3 | Power Sunroof / Moonroof Control Module | 20 A |
| F4 | Driver-Side Power Lumbar Support | 7.5 A |
| F5 | Driver-Side Power Seat | 30 A |
| F6 | Driver and Front Passenger Power Seats | 7.5 A |
| F7 | Driver and Front Passenger Power Lumbar Support | 30 A |
| F8 | Heated Front Seats | 20 A |
| Panel #2 | ||
|
||
| F1 | Trailer Towing / Exterior Lighting Controller | 10 A |
| F5 | Driver-Side Exterior Lighting | 15 A |
| F6 | Passenger-Side Exterior Lighting | 15 A |
