The Saab 9-3 is a compact executive car produced from 1998 to 2014. A key defining feature was the standard use of turbocharged engines across most trim levels and its premium market positioning relative to its donor platform (the Opel Vectra A). This article provides detailed fuse box and relay diagrams for the first-generation Saab 9-3 (chassis code 9400; GM2900 platform; model years 1998, 1999, 2000, 2001, 2002, and 2003).
Below, you will find fuse panel locations, diagrams, and photos of the power distribution centers. Fuses for the “Cigarette Lighter” and “Fuel Pump” are highlighted in bold for quick identification.
Engine Compartment
Component locations:
1. Main fuse box;
2. High-current fusible links.
Main Fuse Box (1)
Fuse box access location.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Rating |
| A | Low beam relay | |
| B | High beam relay | |
| C1 | Auxiliary heater relay | |
| C2 | Vacuum pump relay (Turbo) | |
| D | Engine cooling fan relay (low speed) | |
| E | Bulb check system relay | |
| F1 | Unused | |
| F2 | Unused | |
| G1 | Horn relay | |
| G2 | Front fog light relay | |
| H | Unused | |
| I | Engine cooling fan relay (high speed) | |
| J | A/C compressor relay | |
| 1 | Horn | 10 A |
| 2 | Front fog lights | 15 A |
| 3 | Engine cooling fan (low speed) | 40 A |
| 4 | Vacuum pump | 10 A |
| 5 | A/C compressor | 15 A |
| 6 | Low beam (Left headlight) | 10 A |
| 7 | Low beam (Right headlight) | 10 A |
| 8 | High beam (Left headlight) | 10 A |
| 9 | High beam (Right headlight) | 10 A |
| 10 | Headlight wipers / washers | 7.5 A |
| 11 | Headlight range adjustment | 10 A |
| 12 | Auxiliary lighting (Rear fog lights) | - |
| 13 | Automatic Performance Control (APC) | 7.5 A |
| 14 | Auxiliary heater coolant pump | 10 A |
| 15 | Auxiliary heater | 15 A |
| 1M | Engine cooling fan (high speed) | 30 A |
| 2M | Anti-lock Braking System (ABS) | 50 A |
Fusible Links (2)
Located near the positive battery terminal.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Rating |
| 1 | Passenger compartment fuses 1, 4, 13, 23, 25, 33, and 34 | 60 A |
| 2 | Engine Control Module (ECM) relay, starter relay, light switch, passenger compartment fuses 2, 5, 12, 16, 27, 28, 35, 37, 39, and relay C | 60 A |
| 3 | Ignition switch | 60 A |
| 4 | 60 A | |
| 5 | Power soft top (Convertible) | 60 A |
Passenger Compartment
There are four electrical distribution units located in the passenger compartment.
Dashboard Fuse Box
Located on the driver's side end of the dashboard, accessible by removing the side access panel.
Fuse box access detail.
| Diagram | ||
|---|---|---|
|
||
| No. | Protected Circuit / Component | Rating |
| A | Trailer connector | - |
| B | Trailer brake lights | 10 A |
| C | Blower motor, Automatic Climate Control (ACC) | 30 A |
| 1 | Heated rear window, heated power mirrors | 30 A |
| 2 | Turn signals, Dashboard Integrated Control Electronics (DICE) | 20 A |
| 3 | Blower motor, HVAC control module | 30 A |
| 4 | Interior lighting, luggage compartment light, instrument panel illumination, power antenna | 15 A |
| 5 | Power passenger seat (right) | 30 A |
| 6 | Cigarette lighter (Saab 9-3) | 30 A |
| 6B | Transmission Control Module (TCM) | 7.5 A |
| 7 | Power rear windows, sunroof, power mirrors | 30 A |
| 8 | Heated rear window | 15 A |
| 9 | Automatic Climate Control (ACC) panel | 7.5 A |
| 10 | Horn | 10 A |
| 11 | Body Electronics Control Modules (DICE/TWICE) | 7.5 A |
| 12 | Brake lights, front fog lights | 20 A |
| 13 | Audio system, Data Link Connector (DLC / OBD-II) | 15 A |
| 14 | Front power windows, power soft top (Convertible) | 30 A |
| 15 | Daytime Running Lights (DRL) | 20 A |
| 16 | Power driver seat (left) | 30 A |
| 16B | Engine Control Module (ECM) | 30 A |
| 17 | Engine Control Module (ECM), DICE/TWICE modules, Main Instrument Unit (MIU), driver seat memory, telephone, cruise control, Saab Information Display (SID) | 15 A |
| 18 | Supplemental Restraint System (SRS / Airbags) | 10 A |
| 19 | Anti-lock Braking System (ABS), rear fog light, air conditioning | 10 A |
| 20 | Heated front seats | 20 A |
| 21 | Manual Climate Control (MCC), power soft top (Convertible) | 10 A |
| 22 | Cruise control, turn signals, DICE module | 15 A |
| 23 | Telephone system, power soft top (Convertible) | 20 A |
| 24 | Audio system | 7.5 A |
| 25 | Central locking, fuel filler flap lock, audio system amplifier | 30 A |
| 26 | Engine Control Module (ECM), ignition cassette | 30 A |
| 27 | Automatic Climate Control (ACC), main beam switch | 15 A |
| 28 | Engine Control Module (ECM) | 10 A |
| 29 | Right parking lights, license plate lights | 10 A |
| 30 | Left parking lights | 10 A |
| 31 | Windshield wipers, reverse lights, headlight range adjustment | 20 A |
| 32 | Fuel pump | 15 A |
| 33 | Heated rear seat | 15 A |
| 34 | Saab Information Display (SID), Transmission Control Module (TCM) | 10 A |
| 35 | Main Instrument Unit (MIU), interior lighting, DICE/TWICE modules | 15 A |
| 36 | Starter relay | 10 A |
| 37 | Fuel filter heater (Diesel) | 15 A |
| 38 | Oxygen sensor (O2 sensor) | 25 A |
| Oxygen sensor (O2 sensor), diesel fuel pump | 15 A | |
| 39 | Immobilizer transponder | 5 A |
Main Relay Panel
Located under the dashboard on the driver's side.
| Diagram | |
|---|---|
|
|
| No. | Description |
| A | Heated rear seat |
| B | Reverse lights (Automatic transmission) |
| C1 | Diesel: Glow plug pre-heater |
| Limp-home mode valve | |
| C2 | Trunk lid release actuator |
| D1 | Rear window wiper |
| D2 | Windshield washer pump |
| E | Ignition switch |
| F | Unused |
| G | Windshield wipers |
| H | Heated rear window |
| I | Fuel pump relay |
| J | Unused |
| K | Starter motor |
| L | Engine Control Module (ECM) |
Auxiliary Relay Panels
Located behind the rear quarter trim panels.
| Relay Panel 1 | |
|
|
| R1 | Right rear power window |
| R2 | Fifth bow motor (Convertible) |
| R3 | Right front power window |
| Relay Panel 2 | |
|
|
| R1 | Left rear power window |
| R2 | Power soft top hydraulic pump (Convertible) |
| R3 | Left front power window |
Electrical Component Overview
General location of electronic control modules and components.
1. Air conditioning (A/C) control module;
2. Blower motor control module — on heater housing;
3. Supplemental Restraint System (SRS) control module — rear center console;
4. Driver side impact sensor (SRS) — door;
5. Passenger side impact sensor (SRS) — door;
6. Glass breakage sensor (Anti-theft system) — Convertible interior light unit;
7. Glass breakage sensor (Anti-theft system) — 3-/5-Door interior light unit;
8. Vehicle inclination sensor (Anti-theft system) — rear center console;
9. Anti-theft alarm siren — under left front fender;
10. Central locking / alarm receiver — rear center console;
11. Audio system amplifier — center console;
12. Battery;
13. Convertible soft top control module (TSAS);
14. Cruise control module;
15. Data Link Connector (DLC / OBD-II) — under steering column;
16. Engine compartment fuse box;
17. High-current fusible links;
18. Dashboard fuse box (passenger compartment);
19. Main relay panel (passenger compartment);
20. Rear auxiliary relay panel 1 — beneath left rear quarter window;
21. Rear auxiliary relay panel 2 — beneath right rear quarter window;
22. Horns;
23. Multifunction Control Module 1 (DICE) — functions: Air conditioning system, radiator cooling fan, headlights, fog lights, heated power mirrors, turn signals / hazard lights, heated rear window, interior lights, rear fog lights, rear window wiper, switch backlighting, windshield wipers;
24. Multifunction Control Module 2 (TWICE) — under left front seat — functions: Central locking, seat heaters, immobilizer, bulb check system, anti-theft system, seatbelt warning system;
25. Ambient air temperature sensor — behind front bumper;
26. Power seat memory control module — under driver seat;
27. Transmission Control Module (TCM) — behind glove box.
