The Saab 9-3 is a compact executive car produced from 1998 to 2014. A key feature of the model line is the extensive use of turbocharged engines across most production variants, along with a more premium market positioning compared to its platform donor. The second generation shared GM's Epsilon platform with the Opel Vectra and Cadillac BLS. Below is a detailed reference guide for the fuse box diagrams and relay assignments for second-generation Saab 9-3 (chassis code YS3F; GM Epsilon platform) models covering the 2003–2012 model years.
This guide provides the layout diagrams and photos for each power distribution center. Fuses controlling the “Cigarette Lighter” and “Fuel Pump” circuits are highlighted in bold.
In the Engine Compartment
Two fuse boxes are located in the engine compartment.
Fuse Box No. 1
Located between the front bumper and the battery.
Access example.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Rating (A) |
| R1 | Secondary air pump relay (1.8L, 2.0L B207, and 2.8L B284 engines) | |
| R2 | A/C compressor clutch relay (1.8L, 2.0L B207, and 2.8L B284 engines) | |
| R3 | Heated oxygen sensor (HO2S) relay (1.8L, 2.0L B207, and 2.8L B284 engines) | |
| R4 | Engine Control Module (ECM) relay (1.8L, 2.0L B207, and 2.8L B284 engines) | |
| 1 | Secondary air pump relay (1.8L, 2.0L B207, and 2.8L B284 engines) | 60 A |
| 2 | Fuel pump relay, heated oxygen sensor relay, fuel pump control module, heated oxygen sensors (1.8L and 2.0L B207 engines) | 20 A |
| Fuel pump relay, fuel pump control module (2.8L B284 engine) | 20 A | |
| 3 | A/C compressor clutch (1.8L, 2.0L B207, and 2.8L B284 engines) | 10 A |
| 4 | Engine Control Module relay, Trionic Engine Control Module (ECM), fuel injectors, ignition coils, evaporative emission (EVAP) system, turbocharger bypass valve, Mass Air Flow (MAF) sensor, ionization detection module, boost control solenoid valve (1.8L and 2.0L B207 engines) | 30 A |
| Engine Control Module relays, fuel injectors, ignition coils, fuel pump control module, Motronic Engine Control Module (ECM), evaporative emission (EVAP) system, turbocharger bypass valve, intake camshaft actuator valve, heated oxygen sensors (2.8L B284 engine) | 30 A | |
Fuse Box No. 2
Located adjacent to the battery beneath the protective cover.
Overview of the Saab 9-3 underhood fuse box (Underhood Electrical Center).
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Rating (A) |
| R1 | Windshield washer pump relay | |
| R2 | 1.8L (Z18XE), 1.9L (Z19), and 2.2L (D223L) engines: A/C compressor clutch relay | |
| R3 | Not used | |
| R4 | 1.9L engine (Z19): Fuel preheater relay (diesel) | |
| R5 | Headlamp flash-to-pass relay | |
| R6 | Horn relay | |
| R7 | 1.8L (Z18XE), 1.9L (Z19), and 2.2L (D223L) engines: Engine Control Module (ECM) relay | |
| R8 | Starter relay | |
| R9 | Windshield wiper on/off relay | |
| R10 | Rear window washer pump relay | |
| R11 | Underhood Electrical Center (UEC) ignition (+15) relay | |
| R12 | Windshield wiper high/low speed relay | |
| R13 | Not used | |
| R14 | Headlamp washer pump relay | |
| R15 | Not used | |
| R16 | Not used | |
| 1 | 1.8L engine (Z18XE): Engine Control Module (ECM) relay, Simtec Engine Control Module, fuel injectors, heated oxygen sensors, Mass Air Flow (MAF) sensor, Variable Intake Manifold (VIM) control valve | 30 A |
| 2.2L diesel engine (D223L): Engine Control Module (ECM) relay, Bosch PSG16 engine control module, glow plug control module, Exhaust Gas Recirculation (EGR) valve solenoid, turbocharger control valve, intake shut-off valve | 30 A | |
| 2 | 1.8L engine (Z18XE): Horn relay, Engine Control Module (ECM); 2.8L engine (B284): Motronic Engine Control Module (ECM); 1.8L and 2.0L engines (B207): Trionic Engine Control Module (ECM); 1.9L (Z19), 1.8L/2.0L (B207), 2.8L (B284), 2.2L (D223L) engines: Transmission Control Module (TCM) |
10 A |
| 3 | Horn relay | 20 A |
| 4 | 1.8L engine (Z18XE): Simtec Engine Control Module (ECM), ignition coil module, Electro-Hydraulic Power Steering (EHPS) control module | 10 A |
| 1.9L diesel engine (Z19): Electro-Hydraulic Power Steering (EHPS) control module, Mass Air Flow (MAF) sensor, Bosch EDC16 Engine Control Module (ECM), Transmission Control Module (TCM) | 10 A | |
| 1.8L and 2.0L engines (B207): Trionic Engine Control Module (ECM) | 10 A | |
| 2.8L engine (B284): Fuel pump relay, Motronic Engine Control Module (ECM), Mass Air Flow (MAF) sensor, Transmission Control Module (TCM) | 10 A | |
| 2.2L diesel engine (D223L): Bosch PSG16 Engine Control Module (ECM), Mass Air Flow (MAF) sensor, Exhaust Gas Recirculation (EGR) system | 10 A | |
| 5 | Not used | - |
| 6 | Transmission Control Module (TCM), automatic transmission range switch, manual transmission clutch pedal starter interlock switch | 10 A |
| 7 | Through 2011 models: Left headlamp control module, left headlamp leveling actuator | 7.5 A |
| Left headlamp leveling actuator (Xenon/HID headlamps) | 10 A | |
| 8 | Brake vacuum pump control module, vacuum pressure sensor | 5 A |
| 2.2L diesel engine (D223L): Fuel filter heater | 20 A | |
| 9 | Adaptive Forward Lighting (AFL) module (Xenon/HID headlamps) | 10 A |
| 10 | Not used | - |
| 11 | Not used | - |
| 12 | Rear window washer pump relay | 10 A |
| 13 | 1.8L (Z18XE), 1.9L (Z19), and 2.2L (D223L) engines: A/C compressor clutch relay | 10 A |
| 14 | Not used | - |
| 15 | Windshield washer pump relay | 30 A |
| 16 | Right headlamp (high beam), left headlamp (low beam), front right parking lamp, front right turn signal, front left fog lamp, side turn signal repeaters | 30 A |
| 17 | Windshield wiper motor (low speed) | 30 A |
| 18 | Windshield wiper motor (high speed) | 30 A |
| 19 | Auxiliary cabin heater / parking heater | 20 A |
| 20 | Manual headlamp leveling switch | 10 A |
| Automatic Headlamp Leveling (AHL): Left and right headlamp control modules | 10 A | |
| Adaptive Forward Lighting (AFL): Left and right headlamp control modules, right headlamp leveling actuator (Xenon/HID headlamps) | 10 A | |
| 21 | Not used | - |
| 22 | Windshield washer pump relay | 30 A |
| 23 | Not used | - |
| 24 | Daytime Running Lights (DRL), high/low beam switching relay | 20 A |
| 25 | 2011 models: Audio system amplifier | 30 A |
| 2010 models: Audio system amplifier | 20 A | |
| 26 | Left headlamp (high beam), right headlamp (low beam), front left parking lamp, front left turn signal, front right fog lamp | 30 A |
| 27 | 1.8L engine (Z18XE): Fuel pump relay, fuel pump control module | 20 A |
| 1.9L (Z19) and 2.2L (D223L) diesel engines: Glow plug control module | 60 A | |
| 1.8L and 2.0L engines (B207): Main underhood power feed | 60 A | |
| 28 | Electronic Stability Program (ESP) / Traction Control System (TCS) module | 40 A |
| 29 | Rear Electrical Center (REC) fuse box 2 in luggage compartment | 60 A |
| 30 | Dashboard Electrical Center (IPEC) fuse box 2 in passenger compartment | 60 A |
| 31 | Starter motor relay | 40 A |
| 32 | Dashboard Electrical Center (IPEC) fuse box 1 in passenger compartment | 60 A |
| 33 | Electronic Stability Program (ESP) / Traction Control System (TCS) module | 40 A |
| 34 | Rear Electrical Center (REC) fuse box 2 in luggage compartment | 60 A |
| 35 | Radiator cooling fan relay, brake vacuum pump control module | 30 A |
| 36 | 1.8L (Z18XE) and 1.9L (Z19) engines: Radiator cooling fan relay, preheating relay, fuel filter heater | 20 A |
| 37 | Transport mode lock, Rear Electrical Center (REC) fuse box 3 in luggage compartment | 60 A |
In the Luggage Compartment
The fuse box (Rear Electrical Center) is located behind the trim panel on the left side of the luggage compartment.
Rear Electrical Center layout example.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Rating (A) |
| 1 | Not used | - |
| 2 | Not used | - |
| 3 | Not used | - |
| 4 | Power seat module | 40 A |
| 5 | Heated rear window relay, radio antenna amplifier, soft-top control module (STC, Convertible) | 40 A |
| 6 | Left rear power window regulator, Rear Left Door Module (RLDM) | 30 A |
| 7 | Right rear power window regulator, Rear Right Door Module (RRDM) | 30 A |
| 8 | Trailer wiring connector module | 20 A |
| 9 | Not used | - |
| 10 | Left brake lamp, right rear lamp cluster (turn signal, parking lamp, reverse lamp), center high-mounted stop lamp (CHMSL), trailer lighting module, luggage compartment lamp | 30 A |
| 11 | All-Wheel Drive (AWD) control module | 10 A |
| 12 | Not used | - |
| 13 | Not used | - |
| 14 | Rear window wiper motor | 15 A |
| 15 | Left front heated seat | 15 A |
| 16 | Right front heated seat | 15 A |
| 17 | Rain sensor, All-Wheel Drive (AWD) control module, Tire Pressure Monitoring System (TPMS), auto-dimming interior rearview mirror (garage door opener system, compass, ADM) | 7.5 A |
| 18 | Power sunroof module | 15 A |
| 19 | Telematics module (OnStar system) | 7.5 A |
| 20 | DVD navigation module, satellite radio (SDARS), Traffic Message Channel (TMC) | 7.5 A |
| 21 | Interior lighting, front lighting control module, Saab Parking Assist (SPA), rear door control module, rear window control module | 7.5 A |
| 22 | Audio system, navigation head unit, Bose audio amplifier | 30 A |
| 23 | Tire Pressure Monitoring System (TPMS) control module | 7.5 A |
| 24 | Interior lighting (Convertible), trunk-mounted CD changer, anti-theft alarm siren, telematics module (OnStar), anti-theft inclination and glass-breakage sensors | 10 A |
| 25 | Power driver's seat adjustment module | 30 A |
| 26 | Right brake lamp, left rear lamp cluster (turn signal, parking lamp, reverse lamp), rear fog lamp, license plate lamps, luggage compartment lamp, trailer lighting module | 30 A |
| 27 | Power seat lumbar support adjustment | 10 A |
| 28 | Telematics module, rear heated seats (Convertible) | 15 A |
| 29 | Not used | - |
| Relays on the back of the module | ||
|
||
| No. | Description | |
| R1 | Power seats relay | |
| R2 | Rear Electrical Center (REC) ignition (+15) relay | |
| R3 | Not used | |
| R4 | Heated rear window relay | |
| R5 | Rear window wiper relay | |
| R6 | Not used | |
| R7 | Luggage compartment lid release relay | |
| R8 | Not used | |
| R9 | Not used | |
| R10 | Not used | |
| R11 | Not used | |
In the Passenger Compartment
The fuse box is located behind the panel on the end of the dashboard.
Instrument Panel Electrical Center location example.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Rating (A) |
| 1 | Electronic Steering Column Lock (SCL) | 15 A |
| 2 | Ignition Switch Module (ISM), Electronic Steering Column Lock (SCL) | 5 A |
| 3 | CD player/changer, Bluetooth phone module (UHP), Saab Information Display (SID), integrated telephone, hands-free system | 10 A |
| 4 | Instrument panel cluster (IPC), Manual Climate Control (MCC), Automatic Climate Control (ACC), Body Control Module (BCM) | 10 A |
| 5 | Driver and front passenger door control modules, automatic transmission selector lever | 7.5 A |
| 6 | Brake pedal position sensor, ESP/TCS module, Trionic Engine Control Module (1.8L and 2.0L B207), Bosch EDC16 Engine Control Module (1.9L Z19), Rear Electrical Center (REC) | 7.5 A |
| 7 | Fuel filler flap actuator, Body Control Module (BCM) | 20 A |
| 8 | Passenger Door Module (PDM) | 30 A |
| 9 | Body Control Module (BCM) | 10 A |
| 10 | Cigarette lighter, 12V accessory power socket, luggage compartment power outlet, trailer wiring connector | 30 A |
| 11 | Diagnostic link connector (OBD-II / DLC) | 10 A / 15 A |
| 12 | Interior courtesy lighting, glove box lamp | 15 A |
| 13 | Auxiliary accessory circuits | 10 A / 30 A |
| 14 | Audio system unit, subwoofer amplifier, Infotainment Control Module (ICM) | 20 A |
| 15 | Driver Door Module (DDM) | 30 A |
| 16 | Front Passenger Sensing System (PPS / seat occupancy detection) | 5 A / 7.5 A |
| 17 | Electronic toll collection transponder / accessories | 7.5 A |
| 18 | Manual Climate Control (MCC) panel, blower fan switch | 7.5 A |
| 19 | Not used | - |
| 20 | Manual headlamp leveling switch | 7.5 A |
| 21 | Hands-free system module, Manual Climate Control (MCC), clutch pedal position sensor, cruise control switch, telephone | 7.5 A |
| 22 | Cigarette lighter / 12V auxiliary power outlet (Saab 9-3) | 30 A |
| 23 | HVAC blower motor module, climate control unit | 40 A |
| 24 | Airbag Control Module (SDM) | 7.5 A |
| 25 | Not used | - |
| 26 | Yaw rate sensor (models with ESP) | 5 A |
| 27 | Not used | - |
| Relays on the back of the module | ||
|
||
| 27 | Not used | |
| R1 | Ignition (+54) relay | |
| R2 | Instrument Panel Electrical Center (IPEC) ignition (+15) relay | |
| R3 | Not used | |
| R4 | Not used | |
| R5 | Not used | |
| R6 | Auxiliary relay | |
| R7 | Not used | |
