GMC Acadia is a crossover SUV produced by General Motors under the GMC brand since December 2006. Built on the GM Lambda platform, it replaced the Envoy mid-size SUV in the model lineup. Below is a detailed technical reference for the fuse box diagrams and electrical distribution centers for the first-generation GMC Acadia (Lambda platform; chassis code GMT968) production years 2006–2012.
This guide provides locations, diagrams, and circuit assignments for the power distribution boxes. Fuse locations responsible for the “Cigarette Lighter” and “Fuel Pump” circuits are highlighted in bold.
Passenger Compartment Fuse Box
The instrument panel fuse block is located on the passenger side under the dashboard.
Front view of the fuse block.
2011–2012 Model Years
Circuit assignments for the passenger compartment fuse box (2011–2012 model years).
| Diagram | |
|---|---|
| Name | Description |
| Front Side | |
|
|
| AIRBAG | Supplemental Inflatable Restraint (Airbag) System |
| AMP | Audio Amplifier |
| BCK/UP/STOP | Backup Lamps / Stoplamps |
| BCM | Body Control Module (BCM) |
| CNSTR/VENT | EVAP Canister Vent Solenoid |
| CTSY | Courtesy Lamps |
| DR/LCK | Door Lock Control Module |
| DRL | Daytime Running Lamps (DRL) |
| DRL 2 | Daytime Running Lamps (HID Headlamps) / Rear Fog Lamps (China) |
| DSPLY | Instrument Cluster Display |
| FRT/WSW | Front Windshield Washer |
| HTD/COOL SEAT | Heated/Cooled Seats |
| HVAC | Heating, Ventilation, and Air Conditioning (HVAC) |
| IADV/PWR/LED | Inadvertent Power / Interior Lamp LED |
| INFOTMNT | Infotainment System |
| LT/TRN/SIG | Driver Side Turn Signal |
| MSM | Memory Seat Module |
| PDM | Passenger Door Module (Power Mirrors, Liftgate Release) |
| PWR MODE | Power Mode Relay Control |
| PWR/MIR | Power Mirrors |
| RDO | Audio System / Radio |
| REAR WPR | Rear Window Wiper |
| RT/TRN/SIG | Passenger Side Turn Signal |
| SPARE | Spare |
| STR/WHL/ILLUM | Steering Wheel Controls Illumination |
| Back Side | |
|
|
| LT/PWR/SEAT | Driver Power Seat Relay |
| RT/PWR/SEAT | Passenger Power Seat Relay |
| PWR/WNDW | Power Windows Relay |
| PWR/COLUMN | Power Steering Column Relay |
| L/GATE | Power Liftgate Relay |
| LCK | Power Door Lock Relay |
| REAR/WSW | Rear Window Washer Relay |
| UNLCK | Power Door Unlock Relay |
| DRL2 | Daytime Running Lamps 2 Relay |
| LT/UNLCK | Driver Door Unlock Relay |
| DRL | Daytime Running Lamps Relay |
| SPARE | Spare |
| FRT/WSW | Front Windshield Washer Relay |
2009–2010 Model Years
Circuit assignments for the passenger compartment fuse box (2009–2010 model years).
| Diagram | |
|---|---|
| Name | Assignment |
| Front Side | |
|
|
| AIRBAG | Airbag Control Module |
| AMP | Audio Amplifier |
| BCK/UP/STOP | Backup Lamps / Stoplamps |
| BCM | Body Control Module (BCM) |
| CNSTR/VENT | EVAP Canister Vent Solenoid |
| CTSY | Courtesy Lamps |
| DR/LCK | Door Locks |
| DRL | Daytime Running Lamps |
| DRL 2 | Daytime Running Lamps (HID) / Rear Fog Lamps (China) |
| DSPLY | Instrument Cluster Display |
| FRT/WSW | Front Windshield Washer |
| HTD/COOL SEAT | Heated/Cooled Seats |
| HVAC | Heating, Ventilation, and Air Conditioning (HVAC) |
| IADV/PWR/LED | Inadvertent Power / Interior Lamp LED |
| INFOTMNT | Infotainment System |
| LT/TRN/SIG | Driver Side Turn Signal |
| MSM | Memory Seat Module |
| PDM | Passenger Door Module (Power Mirrors, Liftgate) |
| PWR MODE | Power Mode Relay Control |
| PWR/MIR | Power Mirrors |
| RDO | Radio Module |
| REAR WPR | Rear Window Wiper |
| RT/TRN/SIG | Passenger Side Turn Signal |
| SPARE | Spare |
| STR/WHL/ILLUM | Steering Wheel Controls Illumination |
| Back Side | |
|
|
| DRL | Daytime Running Lamps Relay |
| DRL2 | |
| FRT/WSW | Front Windshield Washer Relay |
| L/GATE | Power Liftgate Relay |
| LCK | Power Door Lock Relay |
| LT/PWR/SEAT | Driver Power Seat Relay |
| LT/UNLCK | Driver Door Unlock Relay |
| PWR/COLUMN | Power Steering Column Relay |
| PWR/WNDW | Power Windows Relay |
| REAR/WSW | Rear Window Washer Relay |
| RT/PWR/SEAT | Passenger Power Seat Relay |
| UNLCK | Power Door Unlock Relay |
2007–2008 Model Years
Circuit assignments for the passenger compartment fuse box (2007–2008 model years).
| Diagram | |
|---|---|
| Name | Assignment |
| Front Side | |
|
|
| AIRBAG | Supplemental Inflatable Restraint (Airbag) System |
| AMP | Audio Amplifier |
| BCK/UP/STOP | Backup Lamps, Stoplamps |
| BCM | Body Control Module (BCM) |
| CTSY | Dome / Courtesy Lamps |
| DISPLAY | Instrument Cluster Display |
| DR/LCK | Door Locks |
| DRL 2 | Infotainment System |
| DRL | Daytime Running Lamps Module |
| FRT/WSW | Front Windshield Wiper |
| HTD/SEAT | Front Heated Seats |
| HVAC | Climate Control Module |
| INADV/PWR/LED | Interior Lamps / Inadvertent Power |
| INFOTAINMENT | Infotainment System |
| LT/TRN/SIG | Driver Side Turn Signal |
| MSM | Memory Seat Module |
| ONSTR/VENT | OnStar / EVAP Canister Vent Solenoid |
| PDM | Passenger Door Module (Power Mirrors, Liftgate) |
| PWR MOD | Power Mode Relay (PassKey Module, Body Control Module) |
| PWR/MIRRORS | Power Mirrors |
| RADIO | Radio Module |
| REAR WIPER | Rear Window Wiper |
| RT/TRN/SIG | Passenger Side Turn Signal |
| SPARE | Spare |
| STR/WHL/ILLUM | Steering Wheel Controls Illumination |
| Back Side Relays | |
|
|
| DRL | Daytime Running Lamps Relay |
| DRL2 | |
| FRT/WSW | Front Windshield Washer Relay |
| L/GATE | Power Liftgate Relay |
| LCK | Power Door Lock Relay |
| LT/PWR/SEAT | Driver Power Seat Relay |
| LT/UNLCK | Driver Door Unlock Relay |
| PWR/COLUMN | Power Steering Column Relay |
| PWR/WNDW | Power Windows Relay |
| REAR/WSW | Rear Window Washer Relay |
| RT/PWR/SEAT | Passenger Power Seat Relay |
| SPARE | Spare |
| UNLCK | Power Door Unlock Relay |
Engine Compartment Fuse Box
Located in the engine compartment on the passenger side, under a protective cover.
Accessing the fuse block.
Overview of the GMC Acadia underhood fuse block.
2011–2012 Model Years
Engine compartment fuse box layout and component assignments (2011–2012 model years).
| Diagram | |
|---|---|
|
|
| Name | Assignment |
| Relays | |
| A/C CMPRSR CLTCH | Air Conditioning Compressor Clutch Relay |
| AUX VAC PUMP | Auxiliary Vacuum Pump Relay |
| CRNK | Starter / Crank Relay |
| FAN 1 | Cooling Fan Relays |
| FAN 2 | |
| FAN 3 | |
| FOG LAMP | Fog Lamps Relay |
| HI BEAM | High-Beam Headlamps Relay |
| HID/LO BEAM | HID Low-Beam Headlamps Relay |
| HORN | Horn Relay |
| IGN | Ignition Main Relay |
| LT TRLR STOP/TRN | Trailer Left Stop and Turn Signal Relay |
| PRK LAMP | Parking Lamps Relay |
| PWR/TRN | Powertrain Relay |
| RR DEFOG | Rear Window Defogger Relay |
| RT TRLR STOP/TRN | Trailer Right Stop and Turn Signal Relay |
| Stop Lamps (China Only) | Stop Lamps Relay (China) |
| TRLR BCK/UP | Trailer Backup Lamps Relay |
| WPR | Windshield Wiper Relay |
| WPR HI | Windshield Wiper High Speed Relay |
| Fuses | |
| A/C CLUTCH | Air Conditioning Clutch |
| ABS MTR | Antilock Braking System (ABS) Pump Motor |
| AFS | Adaptive Forward Lighting (AFL) System |
| AIRBAG | Supplemental Inflatable Restraint (Airbag) System |
| AUX VAC PUMP | Auxiliary Vacuum Pump |
| AUX POWER | Auxiliary 12V Power Outlet, Cigarette Lighter |
| AWD | All-Wheel-Drive (AWD) Module |
| BATT 1 | Battery Main Power Feed |
| BATT 2 | |
| BATT 3 | |
| CIGAR LIGHTER | GMC Acadia Cigarette Lighter Fuse |
| ECM | Engine Control Module (ECM) |
| ECM 1 | Engine Control Module (ECM) 1 |
| EMISSION | Emissions Control System |
| EVEN COILS | Even Cylinder Ignition Coils |
| FAN 1 | Cooling Fans |
| FAN 2 | |
| FOG LAMP | Fog Lamps |
| FSCM | Fuel System Control Module (FSCM) |
| HORN | Horn |
| HTD MIR | Heated Outside Rearview Mirrors |
| HVAC BLWR | HVAC Blower Motor |
| LT HI BEAM | Left High-Beam Headlamp |
| LT LO BEAM | Left Low-Beam Headlamp |
| LT PRK | Left Parking Lamp |
| LT TRLR STOP/TRN | Trailer Left Stop/Turn Signal |
| ODD COILS | Odd Cylinder Ignition Coils |
| PCM IGN | Powertrain Control Module Ignition Supply |
| PWR L/GATE | Power Liftgate |
| PWR OUTLET | 12V Auxiliary Power Outlet |
| REAR CAMERA | Rearview Camera Module |
| RR APO | Rear Auxiliary Power Outlet, Rear Cigarette Lighter |
| RR DEFOG | Rear Window Defogger |
| RR HVAC | Rear Climate Control System |
| RT HI BEAM | Right High-Beam Headlamp |
| RT LO BEAM | Right Low-Beam Headlamp |
| RT PRK | Right Parking Lamp |
| RT TRLR STOP/TRN | Trailer Right Stop/Turn Signal |
| RVC SNSR | Regulated Voltage Control Sensor |
| S/ROOF/SUNSHADE | Sunroof / Power Sunshade |
| SPARE | Spare |
| Stop Lamps (China Only) | Stop Lamps (China) |
| STRTR | Starter Motor |
| TCM | Transmission Control Module (TCM) |
| TRANS | Transmission Controls |
| TRLR BRK | Trailer Brake Controller |
| TRLR PRK LAMP | Trailer Parking Lamps |
| TRLR PWR | Trailer Battery Power |
| TRLR BCK/UP | Trailer Backup Lamps |
| WPR/WSW | Windshield Wiper/Washer |
2009–2010 Model Years
Engine compartment fuse box layout and component assignments (2009–2010 model years).
| Diagram | |
|---|---|
|
|
| Relays | Assignment |
| A/C CMPRSR CLTCH |
Air Conditioning Compressor Clutch Relay |
| AUX VAC PUMP | Auxiliary Vacuum Pump Relay |
| CRNK | Starter / Crank Relay |
| FAN 1 | Cooling Fan Relays |
| FAN 2 | |
| FAN 3 | |
| FOG LAMP | Fog Lamps Relay |
| HI BEAM | High-Beam Headlamps Relay |
| HID/LO BEAM | HID Low-Beam Headlamps Relay |
| HORN | Horn Relay |
| IGN | Ignition Main Relay |
| LT TRLR STOP/TRN | Trailer Left Stop and Turn Signal Relay |
| PRK LAMP | Parking Lamps Relay |
| PWR/TRN | Powertrain Relay |
| RR DEFOG | Rear Window Defogger Relay |
| RT TRLR STOP/TRN | Trailer Right Stop and Turn Signal Relay |
| Stop Lamps (China Only) | Stop Lamps Relay (China) |
| TRLR BCK/UP | Trailer Backup Lamps Relay |
| WPR | Windshield Wiper Relay |
| WPR HI | Windshield Wiper High Speed Relay |
| Fuses | Assignment |
| A/C CLUTCH | Air Conditioning Clutch |
| ABS MTR | Antilock Braking System (ABS) Pump Motor |
| AFS | Adaptive Forward Lighting System |
| AIRBAG | Airbag Control Module |
| AUX POWER | Auxiliary Power Outlet, GMC Acadia Cigarette Lighter Fuse |
| AUX VAC PUMP | Auxiliary Vacuum Pump |
| AWD | All-Wheel-Drive System |
| BATT 1 | Battery Main Power Feed |
| BATT 2 | |
| BATT 3 | |
| ECM | Engine Control Module (ECM) |
| ECM 1 | |
| EMISSION 1 | Emissions Controls |
| EMISSION 2 | |
| EVEN COILS | Even Cylinder Ignition Coils |
| FAN 1 | Cooling Fans |
| FAN 2 | |
| FOG LAMP | Fog Lamps |
| FSCM | Fuel System Control Module |
| HORN | Horn |
| HTD WASH | Heated Windshield Washer Fluid System |
| HTD MIR | Heated Outside Rearview Mirrors |
| HVAC BLWR | HVAC Blower Motor |
| LT HI BEAM | Left High-Beam Headlamp |
| LT LO BEAM | Left Low-Beam Headlamp |
| LT PRK | Left Parking Lamp |
| LT TRLR STOP/TRN | Trailer Left Stop/Turn Signal |
| ODD COILS | Odd Cylinder Ignition Coils |
| PCM IGN | Powertrain Control Module Ignition |
| PWR L/GATE | Power Liftgate |
| PWR OUTLET | 12V Auxiliary Power Outlet |
| REAR CAMERA | Rearview Camera Module |
| RR APO | Rear Auxiliary Power Outlet |
| RR DEFOG | Rear Window Defogger |
| RR HVAC | Rear Climate Control System |
| RT HI BEAM | Right High-Beam Headlamp |
| RT LO BEAM | Right Low-Beam Headlamp |
| RT PRK | Right Parking Lamp |
| RT TRLR STOP/TRN | Trailer Right Stop/Turn Signal |
| RVC SNSR | Regulated Voltage Control Sensor |
| S/ROOF/SUNSHADE | Sunroof / Power Sunshade |
| SPARE | Spare |
| Stop Lamps (China Only) | Stop Lamps (China) |
| STRTR | Starter Motor |
| TCM | Transmission Control Module |
| TRANS | Transmission Controls |
| TRLR BCK/UP | Trailer Backup Lamps |
| TRLR BRK | Trailer Brake Controller |
| TRLR PRK LAMP | Trailer Parking Lamps |
| TRLR PWR | Trailer Power Feed |
| WPR/WSW | Windshield Wiper/Washer |
2007–2008 Model Years
Engine compartment fuse box layout and component assignments (2007–2008 model years).
| Diagram | |
|---|---|
|
|
| Relays | Assignment |
| A/C CMPRSR CLTCH |
Air Conditioning Compressor Clutch Relay |
| CRNK | Starter / Crank Relay |
| FAN 1 | Cooling Fan Relays |
| FAN 2 | |
| FAN 3 | |
| FOG LAMP | Fog Lamps Relay |
| FUEL PUMP | Acadia Fuel Pump Relay |
| HI BEAM | High-Beam Headlamps Relay |
| HID/LO BEAM | HID Low-Beam Headlamps Relay |
| HORN | Horn Relay |
| IGN | Ignition Main Relay |
| LT TRLR STOP/TRN | Trailer Left Stop and Turn Signal Relay |
| PRK LAMP | Parking Lamps Relay |
| PWR/TRN | Powertrain Relay |
| RR DEFOG | Rear Window Defogger Relay |
| RT TRLR STOP/TRN | Trailer Right Stop and Turn Signal Relay |
| SPARE | Spare Relay |
| TRLR BCK/UP | Trailer Backup Lamps Relay |
| WPR | Windshield Wiper Relay |
| WPR HI | Windshield Wiper High Speed Relay |
| J-Case Fuses | Assignment |
| ABS MTR | Antilock Brake System (ABS) Pump Motor |
| BATT 1 | Battery Main Power Feed |
| BATT 2 | |
| BATT 3 | |
| FAN 1 | Cooling Fans |
| FAN 2 | |
| HTD WASH | Heated Windshield Washer System |
| HVAC BLWR | Climate Control System Blower Motor |
| PWR L/GATE | Power Liftgate |
| RR DEFOG | Rear Window Defogger |
| S/ROOF/SUNSHADE | Sunroof / Power Sunshade |
| STRTR | Starter Motor |
| Fuses | Assignment |
| A/C CLTCH | Air Conditioning Clutch |
| ABS MTR | Antilock Brake System (ABS) Module |
| AFS | Adaptive Forward Lighting System |
| AIRBAG | Supplemental Inflatable Restraint (Airbag) Module |
| AUX POWER | Auxiliary Power Outlet Fuse |
| AWD | All-Wheel-Drive System |
| ECM | Engine Control Module (ECM) |
| ECM 1 | |
| EMISSION 1 | Emissions System 1 |
| EMISSION 2 | Emissions System 2 |
| EVEN COILS | Even Cylinder Ignition Coils |
| FOG LAMP | Fog Lamps |
| FUEL PUMP | GMC Acadia Fuel Pump Fuse |
| HORN | Horn |
| HTD MIR | Heated Outside Rearview Mirrors |
| LT HI BEAM | Left High-Beam Headlamp |
| LT LO BEAM | Left Low-Beam Headlamp |
| LT PRK | Left Parking Lamp |
| LT TRLR STOP/TRN | Trailer Left Stop and Turn Signal |
| ODD COILS | Odd Cylinder Ignition Coils |
| PCM IGN | Powertrain Control Module Ignition Supply |
| PWR OUTLET | 12V Power Outlet / Cigarette Lighter Fuse |
| REAR CAMERA | Rearview Camera Module |
| RR APO | Rear Auxiliary Power Outlet |
| RR HVAC | Rear Climate Control System |
| RT HI BEAM | Right High-Beam Headlamp |
| RT LO BEAM | Right Low-Beam Headlamp |
| RT PRK | Right Parking Lamp |
| RT TRLR STOP/TRN | Trailer Right Stop and Turn Signal |
| RVC SNSR | Regulated Voltage Control Sensor |
| SPARE | Spare |
| TCM | Transmission Control Module |
| TRANS | Transmission Controls |
| TRLR BCK/UP | Trailer Backup Lamps |
| TRLR BRK | Trailer Brake Controller |
| TRLR PRK LAMP | Trailer Parking Lamps |
| TRLR PWR | Trailer Power Feed |
| WPR/WSW | Windshield Wiper/Washer |
