Fuses and relays Honda HR-V (GH; 1998 - 2005)

Most of the power supply circuits of the Japanese crossover electrical equipment are protected by fuses. Powerful current consumers are connected via relays. Protective elements are installed in mounting blocks, which are located in the engine compartment and the passenger compartment. In this material, we will analyze in detail the fuse circuits of Honda HR-V (GH) 1st generation 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005 release.

Here you will find the locations and photos of the fuse boxes. Separately, we note the element responsible for the cigarette lighter.

In the passenger compartment

Location of components: 1. Integral control unit, 2. Electric lock / remote control unit, 3. Rear window wiper control unit (KG, KE models), 4. Auto speed alarm unit (KY model), 8. Mounting fuse block under dashboard.

General view of the block.

Diagram
No.	Decoding	A
1	SRS unit (VA)	10
2	SRS unit (VA) Inertia switch (KG and KE models), PGM-FI main relay (excluding KG and KE models)	15
3	Windshield wiper motor, windshield washer motor	20
4	Headlight corrector switch (KG and KE models), headlight corrector switch (KG and KE models), rear window wiper control unit (KG and KE models), rear window washer motor, rear window wiper motor, power window main switch, power window relay	10
5	Integral control box, turn signal / alarm relay, reversing lights	10
6	Instrument Cluster, Clock, Vehicle Speed ​​Alarm Unit (KY Model), Seat Belt Alarm Unit (KY and KQ Models), Power Lock / Remote Control Unit, Secondary HO2S Sensor (KG, KQ, KE and KU Models), ELD (CVT) unit, alternator, VSS, HO2S primary sensor (KG, KQ, KE and KU models), PCM, EVAP purge control solenoid valve (KG, KY, KE and KU models)	7.5
7	Distributor	15
8	Empty	-
9		-
10	Heated rear window	15
11	Empty	7.5
12		-
13	ECM / PCM, PGM-FI Master Relay	7.5
14	Empty	-
15		-
16		-
17		-
18	Audio system, cigarette lighter fuse Honda HR-V	15
19	Empty	-
20		-
21		-
22		-
23	Clock, seat belt alarm unit (KY and KQ models), integral control unit, interior lighting, immobilizer warning lamp (KG, KE, KQ and KU models), luggage compartment lighting, ECM / PCM	7.5
24	Audio system	15
25	Electric lock / remote control unit	15
26	Empty	-
27		-
28		-
Relay
1	To the power window relay
2	Turn Signal / Alarm Relay
3	To the rear light relay
4	To ignition switch
5	To seat heater main relay (KG model) To shift lock relay (KQ and KU models: OD)
6	To main harness SRS

In the engine compartment

Location of components: The mounting block is located on the left side of the engine compartment. It is designated by number 10. Number 9 denotes the ABS modulator assembly (has a built-in control unit)

Photo is an example.

Diagram
No.	Decoding of fuses	A
41	Battery, power supply system	80
42	Ignition switch (BAT)	50
43	Right headlight, high beam warning light	20
44	Rear fog lamp control unit (KG, KE models)	7.5
45	Left headlight	20
46	Tail light relay, clock, turn signals, tail lights, license plate light, integral control unit, instrument cluster light, audio system light, cup holder light, heater control panel light, front side lights, dashboard dimmer (KQ model), connector C (if available)	10 * 1 7.5 * 2
47	Brake Lights, Key Lock Solenoid (KQ, KU Models), ABS Modulator Assembly, ECM / PCM	15 * 1 10 * 2
48	ABS modulator (ABS assembly)	20
49	Turn signal / alarm relay, warning light (KG and KE models)	15 * 1 10 * 2
50	ABS modulator (ABS assembly)	40
51	Power window relay, passenger power window motor	20
52	Power Window Main Switch, Driver Power Window Motor	20
53	No	-
54	Fuses Nos. 23, 24 and 25 (in the fuse / relay box under the dash), connector B (if equipped).	30
55	Seat heaters (KG model)	20
56	Fan motor	40
57	Radiator fan motor	20
58	Condenser fan motor A / C Compressor Clutch	20
59	PGM-FI Main Relay, Data Connector	15
*1. KG and KE models, * 2: Except for KG and KE models
Relay
1	Headlight relay # 1 and # 2
2
3	Horn relay
4	Fan motor
5	Condenser fan
6	Radiator fan
7	A / C Compressor Clutch
8	ELD block (CVT)
