Most of the power supply circuits in these Japanese coupes are protected by fuses. High-current consumers—such as headlights, cooling fan motors, and the fuel pump—are connected via relays. The protective elements are installed in fuse boxes located in the engine compartment and the passenger compartment.
Applies to Honda Integra and Acura RSX models produced from 2001 to 2007 equipped with the K20A (2.0 L) engine.
Passenger Compartment Fuse Box
Under-dash fuse box location (Honda Integra).
Under-dash fuse box location (Acura RSX).
General view.
| Under-Dash Fuse Diagram | ||
|---|---|---|
|
||
| No. | Circuit Protected | Rating (A) |
| 1 | Ignition coils | 15 |
| 2 | Air-fuel ratio (A/F) sensor (Honda Integra Type R and Acura RSX models), PGM-FI electronic control module (Honda Integra Type R and Acura RSX models) | 20 |
| 3 | Not used (Honda Integra), Daytime Running Lights (DRL) control module (Acura RSX, Canada models), rear accessory power socket (Acura RSX, US models) | -; 10* |
| 4 | Electrical Load Detector (ELD), generator (alternator), EVAP purge control solenoid valve, idle air control (IAC) valve (Honda Integra), camshaft position (CMP) sensor, vehicle speed sensor (VSS) (manual transmission models), reverse lock solenoid valve (Honda Integra Type R models), oxygen (O2) sensor (Honda Integra, including Type R), rear oxygen (O2) sensor (Honda Integra Type R and Acura RSX models), air-fuel ratio (A/F) sensor relay (Honda Integra Type R models), air-fuel ratio (A/F) sensor (Honda Integra Type R and Acura RSX models), intake manifold runner control (IMRC) valve actuator (Acura RSX), reverse lockout solenoid valve (Acura RSX Type-S models), cruise control module (Acura RSX) | 10 |
| 5 | - | |
| 6 |
|
7.5 |
| 7 | Power sunroof motor | 20 |
| 8 |
|
7.5 |
| 9 | Rear window wiper motor, rear window washer pump, front passenger OPDS (Occupant Position Detection System) unit (models with side airbags) | 10 |
| 10 |
|
7.5 |
| 11 | ABS modulator-control unit (IG2 terminal) | 7.5 |
| 12 | Not used (Honda Integra), Daytime Running Lights (DRL) control module (Acura RSX, Canada models) | -; 7.5* |
| 13 | Supplemental Restraint System (SRS) control unit (VB) | 10 |
| 14 |
|
20 |
| 15 | Not used (Honda Integra), front and rear audio amplifiers (Acura RSX with Bose system) | -; 20* |
| 16 | Not used (Honda Integra), seat heaters (Acura RSX, Canada models) | -; 20* |
| 17 | Supplemental Restraint System (SRS) control unit (VA), PGM-FI electronic control module (IG1 terminal), fuel pump | 15 |
| 18 | Front accessory power socket, rear accessory power socket (Acura RSX) | 20; 15* |
| 19 | Turn signal / hazard flasher relay | 7.5 |
| 20 |
|
20 |
| 21 | Not used | - |
| 22 | Front passenger power window | 20 |
| 23 | Driver power window | 20 |
| 24 | Not used | - |
| 25 | - | |
| Relays | ||
|
||
| 20 | Power window relay | |
| 24 | Starter relay | |
| 22 | Taillight relay | |
| 10 | Turn signal flasher relay | |
| Note: Remaining slots house wiring harness connectors or are unused. | ||
Under-Hood Fuse Box
Location of components in the engine compartment: 1. ABS modulator-control unit, 2-11. Fuse box
Opening the cover.
| Under-Hood Fuse Diagram | ||
|---|---|---|
|
||
| No. | Circuit Protected | Rating (A) |
| 1 |
|
30 |
| 2 | Parking light relay, accessory power socket connector (Honda Integra), front and rear parking lights, license plate light, switch illumination (Honda Integra), display illumination (models with navigation system), instrument cluster illumination, navigation control unit illumination (models with navigation system), glove box light (Honda Integra), cup holder light (Honda Integra), HVAC control panel illumination (Honda Integra), automatic transmission shift indicator illumination, trailer connector (Acura RSX) | 7.5 |
| 3 | Interior light, map lights (sunroof models), trunk light, ignition switch light | 15 |
| 4 | Radiator cooling fan motor | 20 |
| 5 | Turn signal flasher relay, right turn signal relay (Honda Integra, models from 09.2003), left turn signal relay (Honda Integra, models from 09.2003), security alarm system control unit (Honda Integra, models from 09.2004), turn signal lights (Acura RSX) | 15 |
| 6 | PGM-FI main relays #1 and #2, PGM-FI electronic control module, Top Dead Center (TDC) sensor, crankshaft position (CKP) sensor (Honda Integra), fuel injectors, camshaft position (CMP) sensor (Acura RSX), idle air control (IAC) valve (Acura RSX), immobilizer receiver (Acura RSX) | 15 |
| 7 |
|
15 |
| 8 | ABS modulator-control unit (FSR +B) | 20 |
| 9 | Data Link Connector (DLC), Multiplex integrated control unit (MICU), instrument cluster, keyless entry receiver unit, audio system unit (models without navigation system), Multi-Vision display unit (models with navigation system), TV tuner (models with navigation system), security alarm system control unit (Honda Integra, models from 09.2004 and Acura RSX), immobilizer indicator (Acura RSX), immobilizer receiver (Acura RSX) | 10; 7.5* |
| 10 | ABS modulator-control unit (MR +B) | 30 |
| 11 | Rear window defogger, noise filter | 40 |
| 12 | Heater blower motor | 40 |
| 13 | Under-dash fuse box fuses No. 7, 21 (Acura RSX), 22 (Honda Integra), 23 (Honda Integra); power window relay (Acura RSX) | 40 |
| 14 | Under-dash fuse box fuses No. 2, 3 (Acura RSX), 15 (Acura RSX), 16 (Acura RSX); accessory power socket connector (Honda Integra) | 30 |
| 15 | High-beam indicator, left headlight, Daytime Running Lights (DRL) control module and relay (Acura RSX, Canada models) | 20 |
| 16 | Multiplex integrated control unit (MICU) | 15 |
| 17 | Right headlight | 20 |
| 18 |
|
- |
| 19 | Battery, main power distribution (Acura RSX) | 100 |
| 20 | Ignition switch (+B line) | 40; 50** |
| * Acura RSX; ** Acura RSX (Canada models) | ||
| Relays | ||
|
||
| 4 | A/C compressor clutch relay | |
| 6 | Blower motor relay | |
| 1 | A/C condenser fan motor relay | |
| 14 | Electrical Load Detector (ELD) unit | |
| 7 | Headlight relay No. 1 | |
| 15 | Headlight relay No. 2 | |
| 2 | Horn relay | |
| 3 | Radiator fan motor relay | |
| 5 | Rear window defogger relay | |
| 17 | Starter harness T-1 | |
| 16 | Starter harness T-101 | |
| Note: Remaining slots house wiring harness connectors or are unused. | ||
