The Honda Stream is a 5/7-seater compact MPV produced by the Japanese automaker since 2000. It distinguishes itself from most vehicles in its class through its aerodynamic design and high dynamic performance. In this guide, we will examine in detail the fuse box diagrams and circuit assignments for the first-generation Honda Stream (RN1–RN5 chassis codes), covering model years 2000, 2001, 2002, 2003, 2004, 2005, 2006 for both 2WD and 4WD configurations equipped with the D17A (1.7 L) and K20A (2.0 L) gasoline engines.
Here you will find the locations and photographs of the power distribution boxes. The fuses protecting the "Cigarette lighter" and "Fuel pump" circuits are highlighted in bold.
Passenger Compartment Fuse Box
The power distribution box is located on the driver's side, under the steering column.
General view.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Amps (A) |
| 1 | Ignition coils | 15 |
| 2 |
|
20 |
| 3 | Fog lights | 20 |
| 4 | Alternator, Vehicle Speed Sensor (VSS) (D17A engine models), front oxygen sensor (O2S), rear oxygen sensor (O2S), bypass solenoid valve (K20A engine models), EVAP purge solenoid valve, Camshaft Position (CMP) sensor (K20A engine models), control module supply voltage, Air/Fuel Ratio (AFR) sensor relay (K20A engine models) | 10 |
| 5 | Unused | - |
| 6 |
|
7.5 |
| 7 | Sunroof motor | 20 |
| 8 |
|
7.5 |
| 9 | Rear wiper motor, rear washer pump, rear wiper intermittent control module, front passenger's weight sensor unit (OPDS) (models with side airbags) | 10 |
| 10 |
|
7.5 |
| 11 | ABS modulator-valve unit and ABS control module | 7.5 |
| 12 | Unused | - |
| 13 | Supplemental Restraint System (SRS) control module | 10 |
| 14 |
|
10 |
| 15 | Audio amplifier (models with Premium audio system) | 10 |
| 16 | Rear blower motor (models with rear A/C) | 10 |
| 17 |
|
15 |
| 18 | Cigarette lighter | 15 |
| 19 | Turn signal/hazard flasher relay | 7.5 |
| 20 |
|
20 |
| 21 | Unused | - |
| 22 | Front passenger's power window motor | 20 |
| 23 | Driver's power window motor | 20 |
| 24 | Rear left power window motor | 20 |
| 25 | Rear right power window motor | 20 |
| Relays | ||
|
||
| 20 | Power window relay | |
| 24 | Starter relay | |
| 22 | Tail light relay | |
| 10 | Turn signal/hazard flasher relay | |
| 21 | Electrical control module diagnostic connector | |
| Other slots: Either wiring harnesses or unused. | ||
Engine Compartment Fuse Box
Fuse box location.
Example configuration shown.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Amps (A) |
| 1 |
|
20 |
| 2 | Tail light relay, accessory connector (V), parking lights, tail lights, license plate lights, switch illumination, ashtray illumination, HVAC control panel illumination, instrument cluster illumination, fog light switch, radio illumination (models without navigation), Multivision display unit illumination (models with navigation), navigation system control module | 15 |
| 3 | Cargo area light, ignition switch light, dome light, map lights |
7.5 |
| 4 | Radiator fan motor | 20 |
| 5 | Turn signal/hazard flasher relay | 10 |
| 6 | PGM-FI Main Relay 1, Powertrain Control Module (PCM), Idle Air Control (IAC) valve, Top Dead Center (TDC) sensor, Crankshaft Position (CKP) sensor, fuel injectors, PGM-FI Main Relay 2 | 15 |
| 7 |
|
15 |
| 8 | ABS modulator-valve unit and ABS control module | 20 |
| 9 | Data Link Connector (DLC), instrument cluster, keyless entry control module, navigation system control module, Multivision display unit (models with navigation), radio/head unit (models without navigation), electrical control module | 10 |
| 10 | ABS modulator-valve unit and ABS control module | 30 |
| 11 | Rear window defogger | 20 |
| 12 | Blower motor | 40 |
| 13 | Fuses No. 7, 22, 23, 24, and 25 (passenger compartment fuse box) | 40 |
| 14 | Fuses No. 2, 3, 15, and 16 (passenger compartment fuse box), accessory connector (U) | 40 |
| 15 | Left headlight (halogen models), left HID headlight (HID models), high beam indicator | 15 |
| 16 | Electrical control module | 20 |
| 17 | Right headlight (halogen models), right HID headlight (HID models) | 15 |
| 18 | Unused | - |
| 19 | Main fuse (Battery) | 100*1 80*2 |
| 20 | Ignition switch | 40 |
| Note: *1 – K20A engine models, D17A engine models with rear A/C; *2 – D17A engine models without rear A/C. | ||
| Relays | ||
|
||
| 4 | A/C compressor clutch relay | |
| 6 | Blower motor relay | |
| 1 | Condenser fan relay | |
| 14 | Control module power relay | |
| 7 | Headlight relays 1 and 2 | |
| 15 | ||
| 2 | Horn relay | |
| 3 | Radiator fan relay | |
| 5 | Rear window defogger relay | |
| Other slots: Either wiring harnesses or unused. | ||
