This guide provides detailed fuse box diagrams and panel layouts for the fourth-generation Jeep Liberty (North American market version; chassis code KK), covering model years 2008 through 2013.
Fuses #6, #7, and #36 in the engine compartment power the 12V power outlets and the cigar lighter.
Engine Compartment Fuse Box
The totally integrated power module (TIPM) is located in the engine compartment near the battery, beneath a protective plastic cover.
Accessing the power module.
General view.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Amps |
| R1 | Ignition (Run/Accessory) | |
| R2 | Ignition (Run) | |
| R3 | Starter Relay | |
| R4 | Ignition (Run/Start) | |
| R5 | Transmission Control Module (TCM) Relay | |
| R6 | Rear Window Defogger Relay | |
| R7 | Unused | |
| R8 | Unused | |
| R9 | Unused | |
| R10 | Auto Shut Down (ASD) Relay | |
| R11 | Radiator Fan Control Relay | |
| CB1 | Power Seat Circuit Breaker | 25 A |
| 1 | Stop Lamp Switch, Center High-Mounted Stop Lamp (CHMSL) | 15 A |
| 2 | Trailer Lighting | 20 A |
| 3 | Front/Rear Axle Locker Relay | 20 A |
| 4 | Trailer Tow | 10 A |
| 5 | Power Inverter | 25 A |
| 6 | 12V Power Outlet #1, Rain Sensor, Trailer Tow / Cigar Lighter | 20 A |
| 7 | 12V Power Outlet #2 (BATTERY/ACC SELECT) / Cigar Lighter | 20 A |
| 8 | Front Seat Heater | 20 A |
| 9 | Rear Seat Heater | 20 A |
| 10 | Universal Garage Door Opener, Hands-Free Module, Vanity Lamp | 15 A |
| 11 | Automatic Temperature Control (ATC) | 10 A |
| 12 | Audio Amplifier / Radio | 30 A |
| 13 | Cabin Compartment Node (CCN), Wireless Control Module, Multifunction Switch | 20 A |
| 14 | Trailer Tow (BUX) | 20 A |
| 15 | Multifunction Switch, Cabin Compartment Node (CCN), Steering Column Control Module, Rearview Mirror, Tire Pressure Monitor, IR Sensor, Transfer Case Module | 20 A |
| 16 | Occupant Restraint Controller (ORC) | 10 A |
| 17 | Left Front Parking Lamp, Side Marker Lamps, Left Tail Lamp, Running Lamps, License Plate Lamps | 15 A |
| 18 | Right Front Parking Lamp, Side Marker Lamps, Right Tail Lamp, Running Lamps | 15 A |
| 19 | Auto Shut Down Relays (#1 and #2) | 25 A |
| 20 | Steering Wheel Switches, Interior Lighting, Switch Bank, Electronic Vehicle Information Center (EVIC) | 15 A |
| 21 | Auto Shut Down Relay (#3) | 20 A |
| 22 | Right Horn | 10 A |
| 23 | Left Horn | 10 A |
| 24 | Rear Wiper | 25 A |
| 25 | Fuel Pump | 20 A |
| 26 | Power Window Switch, Driver Window Switch | 10 A |
| 27 | Ignition Switch Feed, Wireless Control Module, Steering Column Lock | 10 A |
| 28 | Powertrain Control Module (PCM) | 10 A |
| 29 | Occupant Classification Module (OCM) | 10 A |
| 30 | Diagnostic Connector / Rear Wiper Module | 15 A |
| 31 | Backup Lamps | 20 A |
| 32 | Occupant Restraint Controller (ORC) | 10 A |
| 33 | Powertrain Control Module (PCM) | 10 A |
| 34 | Park Assist Module, Heating, Ventilation & Air Conditioning (HVAC) Control Module, Compass Module | 10 A |
| 35 | Heated Mirrors | 10 A |
| 36 | 12V Power Outlet #3 / Cigar Lighter | 20 A |
| 37 | ABS Module, Stop Lamp Switch, Electronic Stability Control (ESC) Module | 10 A |
| 38 | Door & Liftgate Lock/Unlock Motors | 25 A |
| J1 | Unused | - |
| J2 | Transfer Case Module | 30 A |
| J3 | Rear Door Node | 40 A |
| J4 | Driver Door Node | 25 A |
| J5 | Passenger Door Node | 25 A |
| J6 | ABS Pump Module | 40 A |
| J7 | ABS Valve Module | 30 A |
| J8 | Power Seats | 40 A |
| J9 | Partial Zero Emission Vehicle (PZEV) / Flex Fuel | 40 A |
| J10 | Headlamp Washer Relay, Manifold Tuning Valve | 30 A |
| J11 | Sway Bar, Power Sliding Door Module, Thatcham Lock/Unlock | 30 A |
| J13 | Ignition Off Draw (IOD) - Main | 60 A |
| J14 | Rear Window Defogger | 40 A |
| J15 | Rear Blower Motor | 30 A |
| J17 | Starter Solenoid | 40 A |
| J18 | Powertrain Control Module (PCM), Transmission Control Relay | 20 A |
| J19 | Radiator Fan | 60 A |
| J20 | Front Wiper | 30 A |
| J21 | Front and Rear Washer Pump | 20 A |
| J22 | Moonroof | 25 A |
