Fuses and relays Kia Carnival (UP/GQ), 1998 - 2006

The Kia Carnival  minivan has been produced from 1998 to the present in three generations and is shipped worldwide. In our material you will find a description of the Kia Carnival fuses and relays with block diagrams and their locations for cars produced in 1999, 2000, 2001, 2002, 2003, 2004, 2005 and 2006. Separately, we note the cigarette lighter fuse.

The purpose of the elements in the blocks may differ from the one presented and depends on the year of manufacture and the country of delivery. Check the description with the diagrams on the back of the protective cover.

In the passenger compartment


Located under the panel, on the left side, near the pillar behind the protective cover.


Photo example.

Diagram
Description
1 15A Heated windshield
2 15A Alarm
3 10A Diagnostic connector (DLC)
4 Reserve
5 15A Fog lights
6 10A Interior lamp
7 20A brake light
8 10A Trip computer, brake lights, instrument cluster, air conditioning / heater blower motor (front), gearbox ECM, ECM, daytime lighting system, multifunction control unit
9 20A Hatch
10 20A Auxiliary equipment connector (front)
11 20A Wipers and washers (front), headlamp, air conditioning / heater blower motor (front), defroster
12 10A Rear window wiper / washer, sunroof, trip computer, multifunction control unit, air conditioning / heating system
13 15A Transmission
14 Reserve
15 10A Direction indicators / hazard warning lights
16 Reserve
17 10A Starting system, electronic engine control module (ECM), electronic transmission control module (TCM)
18 20A Cigarette lighter
19 30A Auxiliary power connector (rear)
20 10A Electric door mirrors, cigarette lighter, auxiliary equipment connector, clock, remote central locking system, audio system
21 Reserve
22 Reserve
F23 10A SRS electronic control unit
24 10A ECM, vehicle speed sensor, diagnostic connector, ABS, instrument cluster, electronic gearbox control unit
The fuse number 18, 20A, is responsible for the lighter.

In the engine compartment


Located on the left side next to the battery.

Diagram
Legend
F1 120A Generator
F2 15A Buzzer
F3 15A Audio system
F4 15A High beam headlights
F5 15A Low beam headlights
F6 15 / 25A Heated rear window
F7 10A Air conditioning / heater control unit, electronic gearbox control unit
F8 15A Rear fog lamp
F9 30A Starting system
F10 30A Anti lock brake system (ABS)
F11 20A Air conditioning system
F12 30A Cooling fan motor
F13 30A Ignition switch
F14 30A Spare
F15 20A Spare
F16 15A Spare
F17 10A Spare
F18 30A Anti lock brake system (ABS)
F19 10A Ignition switch illumination lamp
F20 10A License plate lamps, rear
F21 15A Fuel pump relay
F22 40A Cigarette lighter
F23 30A Air conditioning system (rear heater)
F24 30A Heater blower motor relay (front)
F25 40A Accessory power connector
F26 40A Power passenger seat
F27 10 / 15A Electronic Engine Control Module (ECM), Engine Control System Relay
F28 -
F29 25A Electric lift glass, left
F30 25A Electric lift glass, right
F31 15A Electronic engine control unit
F32 15A Electronic engine control unit
F33 15A Electronic engine control unit
F34 10A Control unit fan motor
1 Heated rear window relay
2 Fog lamp relay
3 Tailgate relay
4 High beam relay
5 Headlamp low beam relay
6 Horn relay
7 Fuel pump relay
8 Cooling Fan Motor Relay (Low Speed)
9 Air conditioner relay
10 Cooling fan motor relay (high speed)
11 Starter relay
12 Engine control relay
13 Heater blower motor relay (front)
14 Power window relay
15 A / C condenser fan motor relay
16 Fully open throttle position relay
