In this article, we take a detailed look at the fuse box diagrams for the first-generation Lincoln Corsair (model years 2019, 2020, 2021, and 2022).
Fuses #70 and #71 in the engine compartment fuse box power the 12V auxiliary power outlets (cigarette lighter).
Engine Compartment Fuse Box
Located on the left side of the engine compartment, beneath the protective cover.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Amps |
| 1 | Not used | — |
| 2 | Heated rear glass | 30 |
| 3 | Heated exterior mirrors | 10 |
| 4 | Hybrid: Electric water pump | 50 |
| 5 | Not used | — |
| 6 | Not used | — |
| 7 | Driveline control module | 40 |
| 8 | Not used | — |
| 9 | Second-row seat release module | 30 |
| 10 | Not used | — |
| 11 | Powertrain control module (PCM) | 15 |
| 12 | 15 | |
| 13 | 15 | |
| 14 | 15 | |
| 15 | Not used | — |
| 16 | Not used | — |
| 17 | Heated windshield wiper park | 15 |
| 18 | Air conditioning (A/C) clutch | 10 |
| 19 | Not used | — |
| 20 | Hybrid: DC/DC converter | 5 |
| 21 | Hybrid: Battery charge control module | 10 |
| 22 | Adaptive cruise control system | 5 |
| 23 | Hybrid: Charge port status indicator ring | 5 |
| 24 | Hybrid: Battery energy control module | 5 |
| 25 | Left-hand enhanced exterior lighting module | 25 |
| 26 | Right-hand enhanced exterior lighting module | 25 |
| 27 | Hybrid: Powertrain control module (PCM) | 5 |
| 28 | ABS module | 10 |
| 29 | Powertrain control module (PCM) | 10 |
| 30 | Auxiliary transmission oil pump, Electronic Stability Control (ESC) | 10 |
| 31 | Electronic power-assisted steering (EPAS) | 5 |
| 32 | Body control module (BCM) | 30 |
| 33 | Image processing module B, Cruise control, Gearshift actuator, Blind Spot Information System (BLIS), Rearview camera, Front parking aid camera | 10 |
| 34 | Headlamp leveling system | 10 |
| 35 | Heated steering wheel | 15 |
| 36 | Hybrid powertrain control module | 10 |
| 37 | Horn | 20 |
| 38 | Blower motor | 40 |
| 39 | Not used | — |
| 40 | Brake pedal switch | 10 |
| 41 | Audio amplifier | 20 |
| 42 | Driver power seat switch | 30 |
| 43 | ABS valves | 40 |
| 44 | Trailer tow module | 40 |
| 45 | Front passenger power seat switch | 30 |
| 46 | Transmission fluid temperature sensor, Transmission auxiliary oil pump | 20 |
| 47 | Heated front seats | 20 |
| 48 | Power liftgate module | 30 |
| 49 | ABS pump motor | 60 |
| 50 | Engine cooling fan motor | 60 |
| 51 | Panoramic roof / Sunroof | 30 |
| 52 | Rear console USB charging ports | 5 |
| 53 | 5 | |
| 54 | Rear heated seat module | 20 |
| 55 | Starter motor relay | 30 |
| 56 | Audio amplifier | 20 |
| 57 | Data Link Connector (DLC) / OBD-II port | 10 |
| 58 | Climate-controlled seat module | 30 |
| 59 | Body control module (BCM) | 40 |
| 60 | Not used | — |
| 61 | Not used | — |
| 62 | Not used | — |
| 63 | Not used | — |
| 64 | Not used | — |
| 65 | Not used | — |
| 66 | Not used | — |
| 67 | Not used | — |
| 68 | Air intake shutoff valve, Intake air temperature (IAT) sensor, Mass air flow (MAF) sensor | 5 |
| 69 | Port fuel injectors | 15 |
| 70 | 12V power outlet (cargo area) | 20 |
| 71 | 12V power outlet (rear console / cigarette lighter) | 20 |
| 72 | Rear window wiper motor | 20 |
| 73 | Not used | — |
| 74 | Windshield wiper motor | 30 |
| 75 | Electronic steering column lock | 20 |
| 76 | Not used | — |
| 77 | Not used | — |
| 78 | Multi-contour seat module | 15 |
| 79 | Headlamp washer pump | 10 |
| 80 | Fuel pump control module | 20 |
| 81 | Rear window washer pump | 10 |
| 82 | AC power inverter module | 40 |
| 83 | Not used | — |
| 84 | Hybrid: Auxiliary power distribution box | 40 |
| 85 | Rain sensor | 5 |
| 86 | Not used | — |
| 87 | Not used | — |
| 88 | Not used | — |
Passenger Compartment Fuse Box
Located under the glove compartment on the passenger side.
Fuse box overview.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Amps |
| 1 | Not used | 5 |
| 2 | Heated rear seat module | 5 |
| 3 | Pedestrian alert sounder module | 10 |
| 4 | Ignition switch | 10 |
| 5 | Door lock/unlock system | 20 |
| 6 | DC/AC inverter, Panoramic roof switch | 10 |
| 7 | Front passenger door module | 30 |
| 8 | Parking assist module | 5 |
| 9 | Electrochromic rear-view mirror, Image processing module A | 5 |
| 10 | Extended power module | 10 |
| 11 | Telematics control unit (TCU) module, Hands-free liftgate actuation module, Power liftgate module | 5 |
| 12 | Keyless entry keypad module | 5 |
| 13 | Driver door lock switch | 15 |
| 14 | Driver door module | 30 |
| 15 | Extended power module | 15 |
| 16 | Vehicle dynamics module | 15 |
| 17 | Radio transceiver module (RTM), Integrated control panel, SYNC infotainment system | 15 |
| 18 | Selectable drive mode switch, Wireless accessory charging module, Power seat switches (driver and passenger) | 7.5 |
| 19 | Bluetooth Low Energy module, Telematics control unit (TCU) module, Headlamp switch module | 7.5 |
| 20 | Not used | 10 |
| 21 | Electronic gearshift selector module (E-shifter), Climate control module | 7.5 |
| 22 | Steering column control module, Gateway module, Instrument cluster | 7.5 |
| 23 | Audio unit | 20 |
| 24 | Head-Up Display (HUD) module | 20 |
| 25 | Not used | 30 |
