Fuses and relays Lincoln Town Car (FN36 / FN116; 1992–1997)

In this article, we examine the fuse box diagrams and component layouts for the second-generation Lincoln Town Car (FN36 / FN116 series) for model years 1992 through 1997.

Fuse #10 (1992–1994) or Fuse #17 (1995–1997) in the passenger compartment fuse panel powers the cigarette lighter.

Engine Compartment

Component locations:
1. Power Distribution Box (Fuse Box)
2. Auxiliary Relay Block

Power Distribution Box (Fuse Box)

General view.

Diagram
No.	Description	Rating
R1	Horn relay
R2	Air suspension relay
R3	1995–1997: Engine cooling fan relay 1992–1994: Anti-lock brake system (ABS) relay
R4	1992–1994: Power window safety relay
A	Exterior and interior lighting	50 A
B	1992–1994: Anti-lock brake system (ABS)	40 A
	1995–1997: Anti-lock brake system (ABS)	50 A
C	Ignition switch	50 A
D	Heated exterior mirrors, rear window defroster	40 A
E	Ignition switch	40 A
F	Circuit breaker: Sunroof, power windows	30 A
G	Not used	-
H	1992–1994: Circuit breaker – Power door locks, power seats, trunk lid pull-down motor, fuel filler door release, trunk release switch	30 A
J	Alternator voltage regulator	10 A
K	Airbag Supplemental Restraint System (SRS) module	10 A
L	1992–1994: Horn	15 A
	1995–1997: Horn	20 A
M	1992–1994: Daytime running lamps (DRL)	15 A
N	Fuel pump	20 A
P	1992–1994: Ignition switch	25 A
	1995–1997: Engine cooling fan	30 A
R	Audio amplifier	25 A
S	1992–1994: Anti-lock brake system (ABS)	30 A
	1995–1997: Heated seats	30 A
T	Powertrain Control Module (PCM)	30 A
U	Air suspension system	30 A
V	Trailer tow package – battery charge circuit	30 A
W	Trailer tow package – electric brakes	30 A
X	Trailer tow package – exterior lamps	30 A
Y	Not used	-

Auxiliary Relay Block

Relay block location.

Diagram
R1	A/C Wide-Open Throttle (WOT) cutout relay
R2	Fuel pump relay
R3	Powertrain Control Module (PCM) relay
1	Powertrain Control Module (PCM) power diode / circuit

Passenger Compartment

Located on the driver’s side, under the instrument panel.

General view.

Diagram
No.	Description	Rating
1	1992–1994: Keep-Alive Memory (KAM) – clock, audio unit, CD changer, instrument cluster, cellular telephone connector, trunk lid pull-down motor, power antenna, air suspension module, daytime running lamps (DRL)	30 A
	1995–1997: Electronic Automatic Temperature Control (EATC) module, turn signal indicators, backup lamps, trailer tow battery charging relay, brake-shift interlock, heated seats	15 A
2	1992–1994 circuit breaker: Interval windshield wiper and washer system	25 A
	1995–1997: Windshield wiper motor, windshield washer and wiper control module	30 A
3	1995–1997: Instrument cluster	5 A
4	1992–1994: Warning lamps, instrument cluster, airbag module, warning chime, Electronically Variable Option (EVO) power steering	10 A
	1995–1997: Lighting Control Module (LCM)
5	1992–1994: Heated exterior mirrors	10 A
	1995–1997: PCM power relay coils, ignition coils	15 A
6	1992–1994: Warning chime, power antenna, audio unit, dome/reading/map lamps, anti-theft system, clock, power windows, Remote Keyless Entry (RKE), brake-shift interlock	10 A
	1995–1997: Audio control unit, Lighting Control Module (LCM), cellular phone, clock, auto-dimming rearview mirror, electronic compass
7	1992–1994: Instrument panel illumination lamps	5 A
	1995–1997: Air suspension and EVO steering control module, airbag diagnostic monitor, steering wheel rotation sensor, Electronic Automatic Temperature Control (EATC) module, ABS module, daytime running lamps (DRL), instrument cluster, warning indicators, speed control servo, transmission control switch (O/D off)	15 A
8	1992–1994: Manual Lever Position Sensor (MLPS), autolamp control module, daytime running lamps (DRL), Remote Keyless Entry (RKE), Electronic Automatic Temperature Control (EATC) module, auto-dimming rearview mirror, air suspension and EVO steering control module, anti-theft system	15 A
	1995–1997: Power mirrors, memory seats, trunk lid pull-down motor, CD changer, steering wheel audio/climate controls, cellular phone
9	1992–1994: Climate control blower motor	30 A
	1995–1997: Lighting Control Module (LCM), airbag diagnostic monitor, audio control unit, warning indicators	5 A
10	1992–1994: Cigarette lighter fuse	30 A
	1995–1997: Electronic Automatic Temperature Control (EATC) module	30 A
11	1992–1994: Courtesy lamps, exterior lamps, autolamp module, anti-theft system	20 A
	1995–1997: Driver front seat and door module	5 A
12	1992–1994: Stop lamps, hazard flashers, speed control, warning lamps	15 A
	1995–1997 circuit breaker: Lighting Control Module (LCM), headlamps	18 A
13	1992–1994: Electronic Engine Control (EEC) system, ignition coils	15 A
	1995–1997: Heated rear window defroster and heated mirrors	10 A
14	1995–1997 circuit breaker: Remote Keyless Entry (RKE), power seats, fuel filler door release, driver front seat and door module	20 A
15	1995–1997: Courtesy lamps, instrument panel (I/P) illumination, Lighting Control Module (LCM), daytime running lamps (DRL) 1992–1994: Trailer tow adapter, rear window defroster, turn signals, headlamp flash-to-pass, A/C compressor clutch	15 A
16	1995–1997: Brake pressure switch, trailer tow adapter, brake pedal position (BPP) switch, hazard flashers 1992–1994: Heated Oxygen Sensors (HO2S)	15 A
17	1992–1994: Memory seats, courtesy lamps, warning lamps, Electronic Automatic Temperature Control (EATC) module, Remote Keyless Entry (RKE), power mirrors	10 A
	1995–1997: Cigarette lighter fuse	30 A
18	1992–1994: Anti-lock brake system (ABS)	5 A
	1995–1997: Instrument cluster, Electronic Automatic Temperature Control (EATC) module, On-Board Diagnostics (OBD-II) connector, audio control unit, clock	10 A
