In this article, we will take a detailed look at the fuse diagrams for the Lincoln MKZ (first generation; cd3): 2005, 2006, 2007, 2008, 2009 release.
Fuse #22 in the engine bay block and #15 in the interior block is responsible for the power outlets and cigarette lighter.
In the engine compartment
Located on the left side of the engine bay (near the battery), under the plastic cover.
General view.
| Diagram | |
|---|---|
 |
|
| No. | Description |
| 41 | Fog lamps relay |
| 42 | Wiper park relay |
| 43 | A/C clutch relay |
| 44 | Empty |
| 50 | Left HID low beam relay |
| 51 | Right HID low beam relay |
| 52 | Blower relay |
| 53 | Empty |
| 54 | Fuel pump relay / fuel injectors |
| 55 | Wiper RUN relay |
| 56 | Empty |
| 57 | PCM relay |
| 58 | Empty |
| 1 | Fuses #12, #13, #14, #15, #16, #17, #18, C/B - SJB power feed (60A) |
| 2 | Fuses #1, #2, #4, #10, #11 - SJB power feed (60A) |
| 3 | PCM relay coil / Powertrain power (40A) |
| 4 | Blower motor (40A) |
| 5 | Empty |
| 6 | Heated mirrors / Rear window defroster (40A) |
| 7 | Empty |
| 8 | ABS pump (40A) |
| 9 | Wipers (20A) |
| 10 | ABS Valves (30A) |
| 11 | Heated seats (up to 2008), Passenger cooled/heated seat (30A) |
| 12 | Driver cooled/heated seat (30A) |
| 13 | from 2008: SYNC (10A) |
| 14 | Ignition switch (15A) |
| 15 | Memory module logic (10A) |
| 16 | Transmission (15A) |
| 17 | Alternator sense (10A) |
| 18 | Empty |
| 19 | solid state devices - Logic feed to SJB (40A) |
| 20 | THXII Amp #1 (20A) |
| 21 | THXII Amp #2 (20A) |
| 22 | 12V power outlet - Console (20A) |
| 23 | PCM KAM, canister vent solenoid and FNR5 (10A) |
| 24 | Fog lamps (15A) |
| 25 | A/C Compressor clutch (10A) |
| 26 | Left HID Low beam (15A) |
| 27 | Right HID Low beam (15A) |
| 28 | Engine radiator fan (80A) |
| 29 | Empty |
| 30 | Lincoln MKZ fuel pump fuse / fuel injectors (30A) |
| 31 | Power seat - Passenger (30A) |
| 32 | Power seat - Driver (30A) |
| 33 | Sunroof (20A) |
| 34 | Driver - Smart window power (30A) |
| 35 | Passenger - Smart window power (30A) |
| 36 | PCM diode (1A) |
| 37 | from 2008: One Touch Integrated Start (OTIS) diode (1A) |
| 38 | Empty |
| 39 | Empty |
| 40 | Empty |
| 45 | Empty |
| 46 | Injectors (15A) |
| 47 | PCM class B (15A) |
| 48 | Coil on plug (15A) |
| 49 | PCM class C (15A) |
In the passenger compartment
Fuse box located to the left of the steering wheel near the brake pedal, under the block cover.
General view.
| Diagram | |
|---|---|
 |
|
| No. | Description |
| 1 | Electrochromatic mirror, Backup lamps (10A) |
| 2 | Horn (20A) |
| 3 | Battery saver: Puddle lamps, Glovebox lamp, Interior lamps, Luggage compartment lamp, Rear power windows (15A) |
| 4 | License plate lamps / Parking lamps (15A) |
| 5 | Empty |
| 6 | Empty |
| 7 | Empty |
| 8 | Window defroster - Rear (30A) |
| 9 | Heated mirrors (10A) |
| 10 | PCM / Starter coil (30A) |
| 11 | Headlamp High beams (15A) |
| 12 | Delay accessories: Sunroof module, Radio head units, Power front windows, Electrochromatic mirrors (7,5A) |
| 13 | Analog clock, Cluster, Climate control head units (7,5A) |
| 14 | Washer pump (15A) |
| 15 | Lincoln MKZ cigarette lighter fuse (20A) |
| 16 | Decklid lock solenoid, Door lock actuator (15A) |
| 17 | Reserve (20A) |
| 18 | OBD2 module, Radio head unit (20A) |
| 19 | Reserve (7,5A) |
| 20 | Power mirrors, Satellite radio module, All wheel drive (7,5A) |
| 21 | Stop lamps, CHMSL (7,5A) |
| 22 | Audio module (7,5A) |
| 23 | Cluster logic / Wiper relay coil (7,5A) |
| 24 | Passenger's seat OCS, PAD indicator (7,5A) |
| 25 | RCM system (7,5A) |
| 26 | Brake shift interlock solenoid, PATS Transceiver, Automatic transmission control unit, Brake pedal switch (7,5A) |
| 27 | Climate control head units, Cluster (7,5A) |
| 28 | Heated seats, ABS/Traction Control, Reverse sensing system (from 2008), Compass (10A) |
| C/B | Circuit Breaker: Sunroof, Delayed accessory - SJB fuse #12, power rear windows (30A) |
