In this article, we will take a detailed look at the fuse diagrams for the Lincoln MKZ (second generation / including restyling; cd4 platform): 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020 release with petrol and hybrid engines.
Fuses #5, #10, #16 and #17 (from 2017) in the engine bay top block are responsible for the power outletls and cigarette lighter.
In the engine compartment
Located on the left side of the engine bay, behind the protection cover.
Top Fuse Block
General view.
| Diagram | |
|---|---|
|
|
| No. | Description |
| 2 | Starter relay |
| 4 | Blower motor relay |
| 6 | from 2018: Water pump relay |
| 9 | Powertrain control module |
| 15 | Run-start relay |
| 32 |
|
| 33 | except Hybrid: Air conditioner clutch |
| 38 |
|
| 39 |
|
| 40 |
|
| 41 |
|
| 42 | except Hybrid and from 2015: Fuel pump coil |
| 86 | Empty |
| 1 |
|
| 3 | Rain sensor (15A) |
| 5 | back of console - 12 Power outlet #3 (20A) |
| 7 | vehicle power 1 - Powertrain control module (20A) |
| Powertrain control module power (20A) | |
| 8 | vehicle power 2 - Powertrain control module (20A) |
| Emission components (20A) | |
| 10 | Front Driver 12V Power outlet #1 / Lincol MKZ cigarette lighter fuse (20A) |
| 11 | vehicle power #4 - Powertrain control module (15A) |
| Ignition coils (15A) | |
| 12 | vehicle power #3 - Powertrain control module (15A) |
| Non-emission components (15A) | |
| 13 | except Hybrid: vehicle power #5 - PCM (10A) |
| Hybrid: Fuel door mechanism (10A) | |
| 14 | except Hybrid: vehicle power #6 - PCM (10A) |
| 16 | up to 2016: Console Power outlet #2 (20A) |
| from 2017: Rear Power outlet #2 (20A) | |
| 17 | from 2017: Front Power outlet #4 - (20A) |
| 18 | except Hybrid and up to 2014: PCM - keep alive power (10A) |
| Hybrid: Powertrain and hybrid powertrain control module keep alive power (10A) | |
| except Hybrid and from 2017: Right side headlamp ballast (20A) | |
| 19 | Run-start electronic power assist steering |
| 20 | Run/start lighting |
| from 2017: Adaptive cruise control system | |
| 21 | except Hybrid: Run/start transmission control, Transmission oil pump start/stop (15A) |
| Hybrid: Run-start transmission switch, HEV inverter (15A) | |
| 22 | except Hybrid: Air conditioner clutch solenoid (10A) |
| Hybrid and from 2017: USB smart charger (5A) | |
| 23 | Run-start Rear view camera, Blind spot information system, Adaptive cruise control, Shifter, Heads-up display, 3.0L engine - All-wheel drive system (15A) / from 2015 and except Hybrid: Voltage stability module (15A) |
| 24 | Empty |
| 25 | Run-start ABS |
| 26 | Run-start PCM |
| 27 | Hybrid:
|
| 28 | Hybrid from 2017: Right hand side headlamp ballast |
| 29 | except Hybrid and from 2015: Mass air flow monitor (5A) |
| Hybrid up to 2016: Hybrid content vehicle power 5 (15A) | |
| Hybrid from 2017: Left hand side headlamp ballast (20A) | |
| 30 | Empty |
| 31 | Empty |
| 34 | Empty |
| 35 | Hybrid and up to 2016: Charger fan (15A) |
| 36 | Hybrid: HEV battery electronic control module fan (15A) |
| 37 | Hybrid up to 2016: Remote CD (5A) |
| 43 | Empty |
| 44 | except Hybrid and from 2017: Left hand side headlamp ballast (20A) |
| 45 |
|
| 46 |
|
| 47 |
|
| 48 |
|
| 49 |
|
| except Hybrid and from 2015: Keep alive power (10A) | |
| 50 | except Hybrid and from 2015: Horn (20A) |
| Hybrid from 2017: Battery energy control module fan (15A) | |
| 51 | Hybrid: content vehicle power 1, powertrain control module (15A) |
| 52 | Hybrid: Battery energy control module, content vehicle power 2 (15A) |
| 53 | up to 2016: Power seats, from 2017: Multi-contour seats (10A) |
| 54 |
|
| 55 |
|
Bottom Fuse Block
Located on the bottom of the top fuse box.
To access:
- Release the latches, located on both sides of the block.
- Raise the inboard side of the block from the cradle.
- Move the block toward the center of the engine bay.
- Pivot the outboard side of the fuse block to access the bottom side.
| Diagram | |
|---|---|
|
|
| No. | Description |
| 56 | except Hybrid and up to 2014: Fuel pump (30A) |
| Hybrid: Fuel pump 30A | |
| 57 | Empty |
| 58 | from 2015: Fuel pump (30A) |
| 59 |
|
| 60 |
|
| 61 | Empty |
| 62 | Body control module 1 (50A) |
| 63 | except Hybrid / up to 2014: Electric fan 2 (20A), from 2015: Electric fan 2 (25A), from 2017 with 3.0L engine: Electric fan 2 (30A) |
| 64 | except Hybrid and from 2017: All-wheel drive (30A). |
| 65 | Petrol engine: Front heated seat (20A) |
| 66 | Heated wiper park (15A) |
| 67 | Body control module 2 (50A) |
| 68 | Heated rear window (40A) |
| 69 | Anti-lock brake system valves (30A) |
| 70 | Passenger seat (30A) |
| 71 | Empty |
| 72 |
|
| 73 | Rear climate controlled seats (20A) |
| 74 | Driver seat module (30A) |
| 75 | Petrol engine and from 2015: Wiper motor 1 (25A) |
| 76 |
|
| 77 | Front climate controlled seats (30A) |
| 78 | Trailer tow module (40A) |
| 79 | Blower motor (40A) |
| 80 |
|
| 81 | Inverter |
| 82 |
|
| 83 |
|
| 84 | except Hybrid: Starter solenoid (30A) |
| 85 | Sunroof #2 (30A) |
| 87 | except Hybrid from 2015: ABS pump (60A) |
In the passenger compartment
Located under the dashboard to the left of the steering column, behind the plactic cover.
General view of the fuse box.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Amps |
| 1 | up to 2017: Lighting (ambient, vanity, glove box, dome, trunk) | 10 A |
| 2 | Memory seats and Power mirror (up to 2016), Lumbar | 7,5 A |
| 3 | Driver door unlock | 20 A |
| 4 | Reserve | 5 A |
| 5 | Subwoofer amp, Audio amplifier (up to 2014) | 20 A |
| 6 | Reserve | 10 A |
| 7 | Reserve | 10 A |
| 8 | Reserve | 10 A |
| 9 | Rear seat entertainment module (2017) | 10 A |
| 10 | Keypad, Power trunk logic, Cellphone passport module (from 2015) | 5 A |
| 11 | Reserve | 5 A |
| 12 | Climate control unit, Gear shift | 7,5 A |
| 13 | Cluster, Steering wheel column lock, Datalink logic | 7,5 A |
| 14 |
|
10 A |
| 15 | Datalink gateway module | 10 A |
| 16 | Trunk release and Child lock | 15 A |
| 17 | Tracking and blocking system | 5 A |
| 18 | Push button stop-start switch, Ignition (from 2015) | 5 A |
| 19 | 2017-2019: Extended power module 2015-2016: Transmission range, Passenger airbag disabled indicator |
7,5 A |
| up to 2014: Transmission range, Passenger airbag disabled indicator | 5 A | |
| 20 | up to 2014: Adaptive headlamp | 5 A |
| from 2015: Adaptive headlamp | 7,5 A | |
| 21 | Humidity and in-car temperature sensor, Rear climate seats (up to 2014) | 5 A |
| 22 | from 2017: Pedestrian sounder (only Hybrid) up to 2016: Occupant classification sensor |
5 A |
| 23 | Delayed accessory (sunroof logic, power inverter logic, driver master switch), Rear sunshade (from 2017), sunroof (from 2017) | 10 A |
| 24 | from 2015: Central lock/unlock | 20 A |
| up to 2014: Central lock/unlock | 30 A | |
| 25 | Driver door (power window, power mirror) | 30 A |
| 26 | Front passenger door (power window, power mirror) | 30 A |
| 27 | Sunroof | 30 A |
| 28 | Audio Amplifier | 20 A |
| 29 | Rear driver side door (power window) | 30 A |
| 30 | Rear passenger side door (power window) | 30 A |
| 31 | Reserve | 15 A |
| 32 | Global positioning system (up to 2016), Voice control, Display, Radio frequency receiver, Adaptive cruise control (up to 2016) | 10 A |
| 33 | Active noise control unit, Radio, CD changer (from 2015) | 20 A |
| 34 | Run-start bus (fuses #19, #20, #21, #22, #35, #36, #37, circuit breaker) | 30 A |
| 35 | up to 2016: Restraints control module | 5 A |
| 36 | Continuous control damping suspension system, Auto-dimming rear view mirror, Rear heated seats (from 2015) | 15 A |
| 37 | up to 2014: All wheel drive system, Heated steering wheel | 15 A |
| from 2015: All wheel drive, Heated steering wheel (2015-2016) | 20 A | |
| 38 | up to 2014: Rear window shade | 30 A |
