The mid-size crossover from Czech automaker Škoda is named Kodiaq, after the Kodiak brown bear. Built on Volkswagen Group’s MQB platform (shared with the Volkswagen Tiguan), the vehicle shares much of its underlying electrical architecture with its sibling models. In this article, we provide detailed fuse box diagrams, relay locations, and circuit assignments for the first-generation Škoda Kodiaq (chassis code NS7; MQB platform; model years 2016, 2017, 2018, 2019, 2020, and 2021).
Below you will find the location diagrams and photo references for the power distribution boxes. Fuses for primary high-demand circuits, such as the “Cigarette lighter” and “Fuel pump,” are highlighted in bold.
Engine Compartment Fuse Box
Located on the left side of the engine compartment, beneath a protective plastic cover.
General view.
| Diagram | |
|---|---|
|
|
| No. | Circuit Protected |
| 1 | ESC (Electronic Stability Control), electric parking brake |
| 2 | ESC (Electronic Stability Control) |
| 3 | Engine control module (ECU) |
| 4 | Radiator fan, fuel pressure regulator, auxiliary electric heater, glow plug system, mass air flow meter, braking system, engine components |
| 5 | Ignition circuit, fuel pump, oil level and oil temperature sensor, engine components |
| 6 | Brake system pressure sensor |
| 7 | Auxiliary coolant pump, exhaust flap, crankcase ventilation heater, engine components |
| 8 | Lambda (oxygen) sensor, NOx sensor, particulate filter sensor |
| 9 | Coolant pump, ignition coils, engine components |
| 10 | Fuel pump fuse (Škoda Kodiaq) |
| 11 | Auxiliary electric heater, heated windshield |
| 12 | Auxiliary electric heater |
| 13 | Automatic transmission auxiliary oil pump |
| 14 | Unassigned / Spare |
| 15 | Horn |
| 16 | Ignition switch |
| 17 | ESC control unit, engine management system, main relay coil |
| 18 | Data bus gateway module, battery monitoring module |
| 19 | Windshield wiper motor |
| 20 | Unassigned / Spare |
| 21 | Automatic transmission control unit (TCM) |
| 22 | Engine control module (ECU) |
| 23 | Starter motor relay |
| 24 | Auxiliary electric heater |
| 25 | Unassigned / Spare |
| 26 | Unassigned / Spare |
| 27 | Automatic transmission control unit (TCM) |
| 28 | Unassigned / Spare |
Passenger Compartment Fuse Box
Left-hand drive (LHD) models: Located on the driver's side behind the storage compartment/glove box.
Right-hand drive (RHD) models: Located on the passenger side behind the glove box.
General view of the interior passenger compartment fuse panel.
| Diagram | |
|---|---|
|
|
| No. | Circuit Protected |
| 1 | SCR system (AdBlue®) |
| 2 | Heated steering wheel |
| 3 | Unassigned / Spare |
| 4 | Anti-theft alarm system |
| 5 | Data bus gateway module |
| 6 | Automatic transmission selector lever / control unit |
| 7 | Climate control system (HVAC), auxiliary heater remote control receiver, heated rear window, heated windshield, rear climate control, tire pressure monitoring system (TPMS) |
| 8 | Rotary light switch, rain and light sensor, electric parking brake switch, interior illumination, alarm sensors, headlight control unit |
| 9 | Headlight range adjustment thumbwheel |
| 10 | Infotainment display screen |
| 11 | Left-side exterior lighting |
| 12 | Infotainment main unit |
| 13 | Left-side seat belt pretensioner |
| 14 | Fresh air blower / HVAC fan |
| 15 | Electric steering column adjustment actuator |
| 16 | USB ports, OBD-II diagnostic connector, Phonebox (wireless charger) |
| 17 | Instrument cluster |
| 18 | Rearview camera module |
| 19 | KESSY (Keyless Entry and Start System) |
| 20 | SCR system (AdBlue®), brake control unit |
| 21 | All-wheel drive (AWD) control module |
| 22 | Trailer hitch control module |
| 23 | Panoramic sliding sunroof |
| 24 | Right-side headlight control module |
| 25 | Central locking (left doors), power windows (left side), heated/folding exterior mirror switch and adjustment (left side) |
| 26 | Front seat heating control unit |
| 27 | Interior ambient lighting |
| 28 | Trailer hitch control module |
| 29 | Unassigned / Spare |
| 30 | Adaptive Chassis Control (DCC / shock absorber regulation) |
| 31 | Power tailgate / luggage compartment lid release |
| 32 | Park Assist, Rear Traffic Alert, Blind Spot Detection |
| 33 | Airbag control unit (SRS) |
| 34 | Air conditioning unit, reverse light switch, auto-dimming exterior mirrors, seat heating switch, electric parking brake, light switch module, center console switches, auxiliary heater, USB charging ports |
| 35 | OBD-II diagnostic connector, driver assist camera, radar sensor (ACC) |
| 36 | Right LED headlight module |
| 37 | Left LED headlight module |
| 38 | Trailer hitch control module |
| 39 | Central locking (right doors), power windows (right side), heated/folding exterior mirror switch and adjustment (right side) |
| 40 | 12V power socket / Cigarette lighter fuse (Škoda Kodiaq) |
| 41 | Right-side seat belt pretensioner |
| 42 | Tailgate latch mechanism, headlight washer system, windshield and rear window washer pumps |
| 43 | Sound system audio amplifier |
| 44 | Trailer hitch socket module |
| 45 | Electrically adjustable driver seat |
| 46 | 230V AC power inverter socket |
| 47 | Rear window wiper motor |
| 48 | Engine sound generator (Soundactor) |
| 49 | Engine start switch, clutch pedal switch |
| 50 | Unassigned / Spare |
| 51 | Heated rear outer seats |
| 52 | Heated front seats |
| 53 | Heated rear window |
