In the fourth generation, the Prius is the brand’s first global model built on the Toyota New Global Architecture (TNGA) platform. This provides a 60% increase in torsional body rigidity, along with a lower center of gravity due to the low-slung powertrain. The hybrid battery pack is located beneath the rear seat rather than under the cargo floor. Visually, the updated model features a more aggressive and dynamic stance than its predecessor, accompanied by a redesigned interior and reduced cabin noise at highway speeds. At the core of the hybrid drive system is the 1.8-liter 2ZR-FXE engine, operating on the Atkinson cycle and featuring VVT-i intelligent variable valve timing.
Fuse box diagrams apply to the Toyota Prius 4th Gen (chassis codes ZVW50, ZVW51, ZVW52, ZVW55; TNGA-C platform) for model years 2015, 2016, 2017, 2018, 2019, 2020, 2021, and 2022.
Passenger Compartment
Component locations: 1. A/C control module (amplifier), 2. Wiper relay, 3. Fuse box / Main Body ECU, 4. Relay box, 5. Electric Power Steering (EPS) ECU, 6. Combination meter (instrument cluster) ECU, 7. Hybrid Vehicle (HV) ECU, 8. Parking assist ECU, 9. Driver assistance systems ECU, 10. Network gateway ECU, 11. Navigation ECU, 12. LHD: Telematics transceiver module, 13. Airbag (SRS) ECU, 14. Audio amplifier, 15. RHD: Double-locking relay
Fuse Box
Fuse box location.
General view.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | A |
| 1 | Air conditioning, cruise control, power door locks, active grille shutter system, hybrid system, Main Body ECU (CAN), power windows, power mirrors, shift lock system, engine immobilizer, Tire Pressure Monitoring System (TPMS), Acoustic Vehicle Alerting System (AVAS) | 7.5 |
| 2 | Power tailgate release, cruise control, Smart Key system (Smart Entry & Start), hybrid system, engine immobilizer, shift lock system, push-button start system, electric steering column lock, Acoustic Vehicle Alerting System (AVAS), remote keyless entry | 5 |
| 3 | Power door locks, power tailgate release, Smart Key system, engine immobilizer, push-button start system, electric steering column lock, remote keyless entry | 20 |
| 4 | Stop lights, ABS, power tailgate release, cruise control, Radar Cruise Control, Smart Key system, hybrid system, engine immobilizer, shift lock system, push-button start system, electric steering column lock, Traction Control (TRC), Acoustic Vehicle Alerting System (AVAS), Vehicle Stability Control (VSC), remote keyless entry | 7.5 |
| 5 | Power tailgate release, Smart Key system, engine immobilizer, push-button start system, electric steering column lock, remote keyless entry | 7.5 |
| 6 | Turn signals / hazard warning lights, power tailgate release, combination meter, Smart Key system, engine immobilizer, push-button start system, electric steering column lock, remote keyless entry | 10 |
| 7 | Interior background illumination, clearance / side marker lamps | 5 |
| 8 | Clearance / side marker lamps, rear fog lamps, front fog lamps, interior background illumination | 10 |
| 9 | Power windows | 20 |
| 10 | 20 | |
| 11 | 12V Power Outlet (Cigarette Lighter) | 15 |
| 12 | Not used | - |
| 13 | Windshield wiper and washer, rear wiper and washer | 15 |
| 14 | Rear wiper and washer | 15 |
| 15 | ABS, air conditioning, audio system, auto-dimming rearview mirror, automatic headlight control, power tailgate release, multi-display, Blind Spot Monitor (BSM), combination meter, cruise control, power door locks, double locking system, Radar Cruise Control, Smart Key system, front fog lamps, rain-sensing wipers, headlights, headlight leveling system, hybrid system, instrument panel illumination, engine immobilizer, Intelligent Parking Assist (IPA), interior lighting, Lane Departure Alert (LDA), turn signal auto-cancel, light reminder buzzer, heated exterior mirrors, Main Body ECU (CAN), navigation system, power windows, Pre-Collision System (PCS), rear fog lamps, rear window defogger, power mirrors, seat belt reminder, seat heaters, shift lock system, power sunroof, push-button start system, electric steering column lock, clearance lamps, anti-theft alarm system, Tire Pressure Monitoring System (TPMS), Traction Control (TRC), Acoustic Vehicle Alerting System (AVAS), Vehicle Stability Control (VSC), remote keyless entry | 10 |
| 16 | Reverse lamps, audio system, multi-display, navigation system | 7.5 |
| 17 | ABS, Traction Control (TRC), Vehicle Stability Control (VSC) | 5 |
| 18 | Not used | - |
| 19 | Rear fog lamps | 7.5 |
| 20 | OBD-II diagnostic link connector | 7.5 |
| 21 | Interior lighting, power tailgate release, Smart Key system, engine immobilizer, push-button start system, electric steering column lock, remote keyless entry | 7.5 |
| 22 | Power tailgate release, Smart Key system, engine immobilizer, push-button start system, electric steering column lock, remote keyless entry | 7.5 |
| 23 | Not used | - |
| 24 | ABS, air conditioning, audio system, automatic headlight control, power tailgate release, multi-display, combination meter, cruise control, power door locks, double locking system, Radar Cruise Control, Engine Control Module (ECM), Smart Key system, Electric Power Steering (EPS), front fog lamps, fuel filler door release, active grille shutter system, headlights, headlight leveling system, hybrid system, instrument illumination, engine immobilizer, Intelligent Parking Assist (IPA), interior lighting, Lane Departure Alert (LDA), turn signal auto-cancel, light reminder buzzer, navigation system, power windows, Pre-Collision System (PCS), rear fog lamps, power mirrors, seat belt reminder, shift lock system, power sunroof, Supplemental Restraint System (SRS airbags), push-button start system, electric steering column lock, clearance lamps, telematics system, anti-theft alarm system, Tire Pressure Monitoring System (TPMS), Traction Control (TRC), turn signals / hazard warning lights, Acoustic Vehicle Alerting System (AVAS), Vehicle Stability Control (VSC), wireless phone charger, remote keyless entry | 10 |
| 25 | ABS, Traction Control (TRC), Vehicle Stability Control (VSC) | 5 |
| 26 | Audio system, multi-display, navigation system | 15 |
| 27 | Power windows | 20 |
| 28 | Not used | - |
| 29 | Not used | - |
| 30 | Not used | - |
| 31 | ABS, air conditioning, audio system, automatic headlight control, power tailgate release, multi-display, combination meter, power door locks, double locking system, Smart Key system, front fog lamps, headlights, headlight leveling system, instrument illumination, engine immobilizer, interior lighting, turn signal auto-cancel, light reminder buzzer, Main Body ECU (CAN), navigation system, 12V power outlet, power windows, rear fog lamps, power mirrors, seat belt reminder, power sunroof, push-button start system, electric steering column lock, clearance lamps, telematics system, anti-theft alarm system, Tire Pressure Monitoring System (TPMS), Traction Control (TRC), Vehicle Stability Control (VSC), wireless phone charger, remote keyless entry | 5 |
| 32 | Air conditioning, Radar Cruise Control, headlights, headlight leveling system, instrument illumination, Lane Departure Alert (LDA), heated exterior mirrors, Pre-Collision System (PCS), rear window defogger, clearance lamps | 7.5 |
| 33 | Electric Power Steering (EPS) | 5 |
| 34 | Supplemental Restraint System (SRS airbags), seat belt reminder | 10 |
| 35 | ABS, air conditioning, audio system, automatic headlight control, power tailgate release, multi-display, combination meter, cruise control, Radar Cruise Control, Engine Control Module (ECM), Smart Key system, Electric Power Steering (EPS), front fog lamps, fuel filler door release, active grille shutter system, headlights, headlight leveling system, hybrid system, instrument illumination, engine immobilizer, Intelligent Parking Assist (IPA), Lane Departure Alert (LDA), turn signal auto-cancel, light reminder buzzer, navigation system, power windows, Pre-Collision System (PCS), rear fog lamps, seat belt reminder, shift lock system, power sunroof, Supplemental Restraint System (SRS airbags), push-button start system, electric steering column lock, clearance lamps, telematics system, anti-theft alarm system, Tire Pressure Monitoring System (TPMS), Traction Control (TRC), turn signals / hazard warning lights, Acoustic Vehicle Alerting System (AVAS), Vehicle Stability Control (VSC), remote keyless entry | 5 |
| 36 | ABS, cruise control, Radar Cruise Control, hybrid system, Main Body ECU (CAN), shift lock system, telematics system, Traction Control (TRC), Acoustic Vehicle Alerting System (AVAS), Vehicle Stability Control (VSC) | 5 |
| Top Side | ||
|
||
| No. | Description | A |
| 1 | Not used | - |
| 2 | Power windows | 30 |
| 3 | Power front seats | 30 |
| 4 | Power sunroof | 30 |
Relay Box
(#4 in component location diagram)
| Diagram | |
|---|---|
|
|
| No. | Description |
| R1 | Power mirror fold-in relay (R/MIR (-)) |
| R2 | Power mirror fold-out relay (R/MIR (+)) |
| R3 | Ignition relay (IG1 NO.4) |
| R4 | Not used |
| R5 | Front fog lamps relay (FR FOG) |
| R6 | RHD: Anti-theft horn relay (S-HORN) |
Engine Compartment
Component locations: 1. Engine compartment fuse box, 2. Fusible link block (power battery fuse box), 3. Left headlight control module, 4. Right headlight control module, 5. Relay box, 6. RHD: Brake control module, 7. Hybrid inverter with DC-DC converter, 8. Engine Control Module (ECM), 9. LHD: Brake control module.
Fuse box location.
Fuse Box
Fuse box cover removal.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | A |
| 1 | Windshield wiper and washer | 30 |
| 2 | 12V Power outlet | 15 |
| 3 | Double locking system | 20 |
| 4 | Not used | - |
| 5 | Engine Control Module (ECM), fuel filler door release | 10 |
| 6 | Seat heaters | 20 |
| 7 | Not used | - |
| 8 | Front fog lamps | 10 |
| 9 | Trailer wiring connector | 20 |
| 10 | Engine Control Module (ECM), air conditioning system, fuel filler door release | 25 |
| 11 | Not used | - |
| 12 | Not used | - |
| 13 | Not used | - |
| 14 | Not used | - |
| 15 | Not used | - |
| 16 | Not used | - |
| 17 | Not used | - |
| 18 | Seat heaters | 10 |
| 19 | Seat heaters | 10 |
| 20 | Air conditioning system, cooling fan, ECU, fuel filler door release | 10 |
| 21 | Engine Control Module (ECM), fuel filler door release | 10 |
| 22 | Ignition system, combination meter, Engine Control Module (ECM), fuel filler door release | 15 |
| 23 | Cruise control, Engine Control Module (ECM), fuel filler door release, hybrid system, shift lock system, Acoustic Vehicle Alerting System (AVAS) | 10 |
| 24 | Hybrid system, cruise control, Radar Cruise Control, shift lock system, Acoustic Vehicle Alerting System (AVAS) | 10 |
| 25 | Cruise control, Radar Cruise Control, hybrid system, shift lock system, Acoustic Vehicle Alerting System (AVAS) | 10 |
| 26 | Hybrid system, cruise control, shift lock system, Acoustic Vehicle Alerting System (AVAS) | 15 |
| 27 | 10 | |
| 28 | 10 | |
| 29 | 10 | |
| 30 | Trailer wiring connector | 20 |
| 31 | Anti-theft alarm system | 10 |
| 32 | Not used | - |
| 33 | Engine Control Module (ECM), fuel filler door release | 10 |
| 34 | Horn, power tailgate release, Smart Key system, engine immobilizer, push-button start system, electric steering column lock, remote keyless entry | 10 |
| 35 | Not used | - |
| 36 | Not used | - |
| 37 | Not used | - |
| 38 | Fuses: “ECU-DCC NO.2”, “ECU-DCC NO.1”, “RADIO” | 25 |
| 39 | Engine Control Module (ECM), cooling fan, air conditioning system, fuel filler door release | 20 |
| 40 | Not used | - |
| 41 | Fuses: “ECU-IG2 NO.1”, “INJ” | 25 |
| 42 | Not used | - |
| 43 | Cruise control, hybrid system, shift lock system, Acoustic Vehicle Alerting System (AVAS) | 5 |
| 44 | Audio system, multi-display, navigation system | 10 |
| 45 | Not used | - |
| 46 | ABS, Traction Control (TRC), Vehicle Stability Control (VSC) | 10 |
| 47 | ABS, Traction Control (TRC), Vehicle Stability Control (VSC) | 10 |
| 48 | Telematics system | 10 |
| 49 | Hybrid system, cruise control, shift lock system, Acoustic Vehicle Alerting System (AVAS) | 30 |
| 50 | Right headlight | 20 |
| 51 | Left headlight | 20 |
| 52 | Rear window defogger, heated exterior mirrors | 50 |
| 53 | Auxiliary heater (PTC) | 30 |
| 54 | Not used | - |
| 55 | Air conditioning system | 40 |
| 56 | Auxiliary heater (PTC) | 30 |
| 57 | ABS, Traction Control (TRC), Vehicle Stability Control (VSC) | 30 |
| 58 | Not used | - |
| 59 | Cooling fan | 30 |
| 60 | Auxiliary heater (PTC) | 50 |
| 61 | Cooling fan | 30 |
| 62 | ABS, Traction Control (TRC), Vehicle Stability Control (VSC) | 30 |
| 63 | Not used | - |
| 64 | Hybrid system, cruise control, Radar Cruise Control, shift lock system, Acoustic Vehicle Alerting System (AVAS); Fuses: “INV W/PMP”, “PCU FR”, “BATT FAN”, “PCU BUB / PCU RR”, “IGCT NO.2”, “PM-IGCT” | 40 |
| 65 | ABS, Traction Control (TRC), Vehicle Stability Control (VSC) | 30 |
| 66 | ABS, Traction Control (TRC), Vehicle Stability Control (VSC) | 30 |
| 67 | Fuses: IG2-NO.2 Relay, “D/L”, “ECU-B NO.1”, “ECU-B NO.2”, “HAZ”, “STOP”, “AM2” | 50 |
| 68 | Not used | - |
| 69 | Not used | - |
| 70 | Not used | - |
| Relays | ||
| R1 | Hybrid / Ignition Control Relay (IGCT) | |
| R2 | Engine Water Pump Relay (ENG W/PMP) | |
| R3 | Horn Relay | |
Relay Box
(#5 in component location diagram)
| Diagram | ||
|---|---|---|
|
||
| No. | Description | A |
| 1 | Heated exterior mirrors, rear window defogger | 10 |
| 2 | Daytime Running Lights (DRL) | 10 |
| Relays | ||
| R1 | Rear window defogger relay (DEF) | |
| R2 | Auxiliary heater relay No. 1 (PTC HTR NO.1) | |
| R3 | Circuit opening relay / Fuel pump (C/OPN) | |
| R4 | Cooling fan relay No. 3 (FAN NO.3) | |
| R5 | Cooling fan relay No. 2 (FAN NO.2) | |
| R6 | Auxiliary heater relay No. 2 (PTC HTR NO.2) | |
| R7 | Cooling fan relay No. 1 (FAN NO.1) | |
| R8 | Not used | |
| R9 | Not used | |
| R10 | Auxiliary heater relay No. 3 (PTC HTR NO.3) | |
Fusible Link Block (Power Battery Fuse Box)
(#2 in component location diagram)
| Diagram | ||
|---|---|---|
| No. | Description | A |
| 1 | ACC relay, TAIL relay, IG1-NO.2 relay, IG1-NO.1 relay; Fuses: “POWER”, “P/SEAT”, “S/ROOF”, “DOOR R/R”, “DOOR R/L”, “DOOR”, “FOG RR”, “DOME”, “OBD”, “DOOR BACK” | 60 |
| 2 | Electric Power Steering (EPS) | 80 |
| 3 | Fuses: “J/B-AM”, “FOG FR”, “ENG W/PMP”, “HTR”, “ABS MTR NO.2”, “FAN NO.1”, “FAN NO.2”, “FUEL OPN”, “P/OUTLET NO.2”, “PTC HTR NO.3”, “PTC HTR NO.2”, “PTC HTR NO.1”, “ABS-MAIN”, “DOOR DBL/L”, “WIPER”, “S/HTR-MAIN”, “TOWING-DC/DC”, “DEF” | 120 |
| 4 | Fuses: “HORN”, “ETCS”, “TOWING-B”, “ABS MTR NO.1”, “S-HORN”, “P CON MTR”, “DCM/MAYDAY”, “ABS NO.2”, “ABS NO.3”, “BATT-S”, “ABS MTR NO.3”, “H-LP LH”, “AMP”, “H-LP RH”, “J/BB”, “D/C CUT”, “IGCT-IG”, “EFI-MAIN”, “IG2-MAIN”, “DRL” | 140 |
