The VW Scirocco is a sport compact hatchback produced across three generations starting in 1974. This guide applies to third-generation models manufactured from 2008 through 2017. Below are the locations, circuit diagrams, and fuse assignment tables for the Volkswagen Scirocco Mk3 (chassis code 13; A6 / PQ35 platform).
Note: Fuse box layouts and amperage ratings may vary depending on the vehicle's model year, engine variant, and equipment configuration.
Passenger Compartment
Located on the driver-side edge of the dashboard, behind the end-panel cover.
| Diagram | |
|---|---|
 |
|
| Circuit / Function | Fuse No. (A) |
| ABS (Anti-lock Braking System) | 2 (10 A), 4 (5 A) |
| Vehicle inclination sensor | 17 (5 A) |
| Airbag control module | 3 (5 A) |
| Brake light switch | 2 (10 A) |
| Adaptive Chassis Control (DCC) | 35 (20 A) |
| ESP (Electronic Stability Program) | 2 (10 A), 4 (5 A) |
| Front power windows | 23 (30 A) |
| Blower motor / Climate control fan | 22 (40 A), 40 (40 A) |
| Heated rear window | 25 (25 A) |
| Rear window wiper motor | 41 (15 A) |
| Interior security / Anti-theft alarm | 17 (5 A) |
| Instrument cluster | 2 (10 A) |
| Fuel pump relay | 27 (15 A) |
| Power lumbar support adjustment | 34 (15 A) |
| Headlight range control | 1 (10 A) |
| Panoramic sunroof | 33 (30 A) |
| Rain and light sensor | 13 (10 A) |
| Heated windshield washer nozzles | 4 (5 A) |
| Headlight washer system | 36 (20 A) |
| Heated seats | 37 (30 A) |
| Cigarette lighter and 12V power sockets | 42 (20 A) |
| Central locking system | 12 (10 A) |
Fuse No. 42 (20 A) controls the 12V power outlet and cigarette lighter circuit.
Engine Compartment
Shown below is a representative fuse panel layout option.
| Diagram | |
|---|---|
| Type 1 | |
 |
|
| Type 2 | |
 |
|
| Circuit / Function | Fuse No. (A) |
| ABS control module | 4 (30 A), 25 (30 A) |
| Left headlight assembly | 26 (30 A) |
| Right headlight assembly | 16 (30 A) |
| ESP control module | 4 (30 A), 25 (30 A) |
| Windshield wiper motor | 19 (30 A) |
| Horn | 17 (15 A) |
| Radiator cooling fan | 24 (10 A) |
| Radio / Infotainment head unit | 8 (15 A) |
| Audio sound system amplifier | 18 (30 A) |
| Telephone control module | 9 (15 A) |
