The production of the Audi q5 (8R) crossover was started in 2008 and is still ongoing. This material provides information on the locations of relay blocks and fuses for the audi q5 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016 and 2017, with diagrams and decoding of their elements. We will show you how to replace the fuse responsible for the cigarette lighter.
Our material provides only a general description of the power supply system, relay boxes and fuses in the Audi q5. Check the correct information for your car with your manual or other relevant information.
Locations of relay and fuse boxes in the audi q5
1. Fuse box and connector for starting the engine from an external power source in the plenum chamber;
2. Fuse box on the right side of the front panel. The fuses installed in it are indicated on the wiring diagram "SC". The customer can access these fuses on his own by removing the side cover of the front panel;
3. Relay box and bracket for onboard supply control unit in driver's side footwell;
4. Fuse / relay box and CAN bus hub in the luggage compartment on the right. The fuses installed in it are indicated on the wiring diagram "SF". These fuses can be accessed by the customer by removing the storage compartment in the rear right side of the luggage compartment
5. Main fuse box on the positive battery terminal;
6. CAN bus junction box and hub at the bottom of the left A-pillar;
7. Fuse box on the left side of the front panel. The fuses installed in it are indicated on the wiring diagram "SB". The customer can access these fuses on their own by removing the side cover of the front panel;
8. Relay and fuse box in the E-Box.
Fuse box in plenum chamber
| Diagram | |
|---|---|
| For vehicles up to 2012. | |
|
|
| A - Splitter 2 for terminal 30 -TV22- | |
| B - Socket for starting from external power supply -U6- | |
| 1 | 40 (2) 60 (1) Fan control unit 400 W / Fan control unit 600 W |
| 2 | 110 Fan control unit 400 W |
| 1) On vehicles with 1000 W fan control, -S204- (600 W) and -S205- (400 W) are installed. | |
| 2) On vehicles with 800 W fan control, -S204- (400 W) and -S205- (400 W) are installed. | |
| For vehicles with a high voltage system or from 2012 onwards. | |
|
|
| A - Splitter 2 for terminal 30 -TV22- | |
| B - Socket for starting from external power supply -U6 | |
| № | Function / component |
| 1 | 40 / 60A Fan control 400 W (2) , Power and control unit for electric drive -JX1- (1) |
| 2 | 40 / 175A Fan control 400W, Fan control 600W / Fan control 1000W (3) |
| 3 | - Supply for fuse -S126-, fuse -S328- |
| 4 | 110A Power steering control unit -J500- |
| 1) S204 (600W) and S205 (400W) are installed on vehicles with 1000W fan control. | |
| 2) S204 (400 W) and S205 (400 W) are installed on vehicles with 800 W fan control. | |
| 3) For vehicles with high voltage system. | |
Fuse box in the right end of the front panel
Location
| Diagram | ||
|---|---|---|
|
||
| Fuses in fuse holder ST1 (black) | ||
| № | A | Description |
| 1 | - | Not used |
| 2 | - | Not used |
| 3 | - | Not used |
| 4 | - | Not used |
| 5 | 5 | Steering column control unit -J527- |
| 6 | - | Not used |
| 7 | 5 | Connector 16-pin -T16-, diagnostic connector |
| 8 | 5 | Data bus diagnostic interface -J533- |
| 9 | 5 (1) | Low heat output relay -J359- Coolant glow plug relay 2 -J390- Additional air heater control unit -J604- |
| 10 | - | Not used |
| 11 | - | Not used |
| 12 | - | Not used |
| Fuses in fuse holder ST2 (brown) | ||
| 1 | 5 | CD changer -R41- DVD changer -R161- connector for external audio sources -R199- |
| 2 | 5 | Changeover module for Charisma -E592- |
| 3 | 5 (2.3) 20 (4.5) |
Display of control unit for front operating, display and information output -J685- Control unit for information electronics 1 -J794- Radio -R- |
| 4 | 5 | Control unit in dash panel insert -J285- |
| 5 | 5 | Data bus diagnostic interface -J533- |
| 6 | 5 | Access and start authorization switch -E415- |
| 7 | 5 | Light switch -E1- |
| 8 | 40 | Light switch -J126- |
| 9 | 5 | ELV control unit -J764- |
| 10 | 10 | Climatronic control unit -J255- |
| 11 | 10 | Connector 16-pin -T16-, diagnostic connector |
| 12 | 5 | Steering column control unit -J527- |
| 1) Only for vehicles with 4-cylinder petrol engine with high voltage system (hybrid) 2 ) Only for vehicles with radio (CAN) and external amplifier 3) Only for vehicles with MMI (MOST) 4) Only for vehicles with chorus radio with Basic sound system (from November 2009) 5) Only for vehicles with chorus / concert / symphony radio with Basic sound system (from May 2010) |
||
Units on the onboard power supply control bracket
| Relay / fuse holder -J519- (3) diagram | ||
|---|---|---|
|
||
| № | A | Legend |
| A | 40 (2) 30 (1) |
Fuse 1 for ABS control unit -S123- (2) Fuse for trailer terminal 30 -S77- (1) |
| Relay | ||
| 1 | Not used | |
| 2 | Relay for circulation pump -J160- (3) Relay for horn -J413- Relay for dimming rearview mirror -J910- (4) Relay for vacuum pump -J318- (6) |
|
| 3 | Terminal 15 voltage supply relay -J329- | |
| 4 | Taxi alarm remote control unit -J601- (5) Special vehicle control unit -J608- (5) Driver training vehicle relay -J746- (7) |
|
| 1) Only for cars with right-hand drive 2) Only for cars with left-hand drive 3) Valid until May 2009 for vehicles with 3.2l 6-cylinder petrol engine without auxiliary heater 4) Only for vehicles with start-up system stop 5) Only for special vehicles 6) Only for vehicles with 4-cylinder petrol engine with high voltage system (hybrid) 7) Only for training vehicles |
||
| 3-section relay and fuse box diagram | ||
|---|---|---|
|
||
| № | A | Fuse |
| A | - | Not used |
| B | - | Not used |
| C | 40 | Fuse for auxiliary heater -S126- |
| D | 60 | Fuse 2 for auxiliary heater -S328- |
| Relay | ||
| 1 | Additional air heater control unit -J604- | |
| 2 | Low heat output relay -J359- (only for vehicles with diesel engine) | |
| 3 | High heat output relay -J360- (only for vehicles with diesel engine) | |
Luggage compartment fuse and relay box -SF-
Located behind the right side trim.
| Diagram | ||
|---|---|---|
|
||
| Fuses in fuse holder ST1 (black) | ||
| 1 | 30 10 (7) |
Trunk lid control unit 2 -J756- (up to 2009) Digital radio -R247- (from 2013) |
| 2 | 10 (7) | Radio isolation relay, radio relay -J84- (from 2013) |
| 3 | 30 15 (1.7) |
|
| 4 | 5 15 (1.7) |
|
| 5 | 5 | Control panel for special signaling unit -E507- (from 2010) Signal installation control unit -J616- (from 2010) |
| 6 | 3 |
|
| 7 | 20 | Special vehicle control unit -J608- (from 2010) |
| 8 | 10 | Accident data logger (since 2010) |
| 9 | 10 | 12 V socket 4 -U20- (from 2010) |
| 10 | 10 |
|
| 11 | 10 |
|
| 12 | - | Not used |
| Fuses in fuse holder ST2 (black) | ||
| 1 | 5 30 (1.7) |
Tire pressure monitor control unit -J502- (up to 2009) Boot lid control unit 2 -J756- (from 2010) |
| 2 | 15 | Trailer detection control unit -J345- |
| 3 | 20 | Trailer detection control unit -J345- |
| 4 | 20 | Trailer detection control unit -J345- |
| 5 | 5 | Electromechanical parking brake button -E538- (up to 2009), (from 2013) AUTO HOLD button -E540- (from 2010) |
| 6 | 15 | Electronic damping control unit -J250- |
| 7 | 30 | Electromechanical parking brake control unit -J540- |
| 8 | 30 | Convenience system central control unit -J393- |
| 9 | 5 (2) 35 |
Four-wheel drive control unit -J492- Tire pressure monitor control unit -J502- (2) |
| 10 | 30 | Convenience system central control unit -J393- |
| 11 | 20 | Convenience system central control unit -J393- |
| 12 | 5 |
|
| Fuses in fuse holder ST3 (brown) | ||
| 1 | 30 | Boot lid control unit -J605- (from 2010) |
| 2 | 15 20 (7) |
Heated front right seat control unit -J799- Socket relay -J807- (from 2013) Cigarette lighter -U1- (from 2013) 12 V socket -U5- (from 2013) Inverter with socket, 12 V-230 V -U13- (from 2013) 12 V socket 2 -U18- (from 2013) 12 V socket 3 -U19- (from 2013) |
| 3 | 7.5 15 (2) 40 (1.7) |
|
| 4 | 30 (4.7) 40 (1) |
|
| 5 | 7.5 25 (7) |
|
| 6 | 30 | Additional heater control unit -J364- |
| 7 | 30 | Electromechanical parking brake control unit -J540- |
| 8 | 30 | Left rear seat heater adjustment switch -E128- Right rear seat heater adjustment switch -E129- |
| 9 | 30 | Front passenger side door control unit -J387- Rear right door control unit -J389- |
| 10 | 5 | Auxiliary heater radio -R64- |
| 11 | 15 | Front passenger side door control unit -J387- Rear right door control unit -J389- |
| 12 | 5 (4.7) 30 (1) |
Reversing camera control unit -J772- (up to 2009) Additive dosing system control unit -J880- (from 2010) Telephone signal transmitter and receiver -R36- (from 2013) Mobile phone amplifier -R86- (from 2013) ) Phone holder -R126- (from 2013) |
| Fuses in fuse holder ST4 (red) | ||
| 1 | 15 | 12 V socket 2 -U18- Not used (from 2013) |
| 2 | 15 | 12 V socket -U5- Inverter with socket, 12 V-230 V -U13- (from 2010) Drink holder with heating and cooling element -Z105- (from 2010) Not used (from 2013) |
| 3 | 15 | 12 V socket 3 -U19- Not used (since 2013) |
| 4 | 15 | Cigarette lighter -U1- Not used (since 2013) |
| 5 | 5 |
|
| 6 | 5 |
|
| 7 | 5 7.5 (1) |
Distance control control unit -J428- (up to 2009) Park assist control unit -J791- (from 2010) Not used (from 2013) |
| 8 | 15 | Rear window wiper motor -V12- Not used (from 2013) |
| 9 | 5 | AUTO HOLD key -E540- Not used (since 2013) |
| 10 | 5 | Lane change assist control unit 2 -J770- Not used (from 2013) |
| 11 | 5 | Left rear seat heater adjustment switch -E128- Right rear seat heater adjustment switch -E129- (up to 2009) Not used (from 2013) |
| 12 | 5 |
|
| Fuses in fuse holder ST5 (black) | ||
| 1 | 15 | Heated front right seat control unit -J799- (from 2013) |
| 2 | 5 (8) | Relay for auto-dimming interior mirror -J910- Auto-dimming interior mirror -Y7 |
| 3 | 15 20 (3) 30 (1.7) |
Alarm system control unit -J616- (up to 2009) Digital sound package control unit -J525- (from 2010) Radio -R- (from 2010) Power supply for fuse holder 2 -ST2- (from 2013) From fuse 1 to fuse holder D -SD1- up to fuse 4 on fuse holder D -SD4- (from 2013) |
| 4 | 15 7.5 (1.7) |
Signaling electronics control unit -J616- (up to 2009) Information electronics control unit 1 -J794- (from 2010), (from 2013) |
| 5 | 5 (4.5.7) 7.5 (6) |
Control unit for special signals -E507- (up to 2009) Signal unit control unit -J616- (up to 2009) Radio -R- (from 2010), (from 2013) Telephone signal transmitter and receiver -R36- (from 2010) TV tuner -R78- (from 2010), (from 2013) Mobile phone amplifier -R86- (from 2010) Telephone holder -R126- (from 2010) Connector, 18-pin, black -T18a - (as of 2010) Chip card reader control unit -J676- (as of 2013) |
| 6 | 10 5 (1.7) |
Control panel for special signals -E507- (up to 2009) Signal unit control unit -J616- (up to 2009) Tachograph control unit -J621- (up to 2009) 3-pin connector -T3d- (up to 2009) Data logger Accident (up to 2009) Rear view camera control unit -J772- (from 2010), (from 2013) |
| 7 | 20 5 (1) 30 (7) |
Special vehicle control unit -J608- (up to 2009) Mobile phone amplifier -R86- (from 2010) Heated rear window relay -J9- (from 2013) Heated rear window -Z1- (from 2013) |
| 8 | 10 5 (7) 7.5 (1) |
Accident data logger (up to 2009) Battery regulation control unit -J840- (from 2010) Multimedia system connection set: Connector, 2-pin, in the backrest of the driver's seat -T2dy- (from 2013) connector, 2-pin , in the backrest of the front passenger seat -T2dz- (from 2013) |
| 9 | 10 | 12 V socket 4 -U20- (up to 2009) |
| 10 | 10 | Radio isolation relay, radio relay -J84- (up to 2009) |
| 11 | 10 30 (7) |
Radio isolation relay, radio relay -J84- (up to 2009) Additive dosing system control unit -J880- (9) (from 2013) |
| 12 | 10 (7) 15 (8) |
Additive metering unit control unit -J880- (7) Battery regulation control unit -J840- (8) |
| Individual fuses on fuse holder F -SF- | ||
| H | 40 | Heated rear window relay -J9- Heated rear window -Z1- (from 2013) |
| Relay | ||
| A | Not used | |
| B | Radio isolation relay, radio relay -J84- (11) (up to January 2011) Fan release relay -J937- (2) Additive dosing system relay -J963- (9) |
|
| C | Heated rear window relay -J9- (up to January 2011) Radio isolation relay, radio relay -J84- (11) |
|
| D | Not used (until January 2011) Heated rear window relay -J9- |
|
| E | Socket relay -J807- | |
| 1) Vehicles from 2010 2) Only for vehicles with 4-cylinder petrol engine with high voltage system (hybrid) 3 ) Only for vehicles with radio (CAN) with Basic sound system (up to November 2009) 4) Vehicles up to 2009 5) Vehicles from May 2010 6) Vehicles up to April 2010 7) Vehicles from 2013 8) Only for vehicles with start / stop system 9) Only for vehicles with SCR system 10) Only for vehicles with high voltage system 11) Only for special vehicles. |
||
| Diagram (battery box audi q3) | ||
|---|---|---|
|
||
| № | A | Diagram |
| 1 | 110 |
|
| 2 | 110 |
|
| 3 | 40 50 110 80 |
|
Fuse box on the left side of the front panel
Location
| Diagram (type 1) | ||
|---|---|---|
|
||
| № | A | Legend |
| 1 | 15 | Automatic gearbox control unit -J217- Mechatronic unit for dual clutch gearbox -J743- |
| 2 | 5 | Oil level and oil temperature sender -G266- |
| 3 | 5 | Engine control unit -J623- Power and control unit for electric drive -JX1- |
| 4 | 5 | Engine control unit -J623- |
| 5 | 5 (4.5) 10 (1.2.3) |
|
| 6 | 15 | Engine control unit -J623- |
| 7 | 10 (3.4.5) 15 (1.2) |
|
| 8 | 5 (4.5) 10 (6) 15 (1) |
|
| 9 | 5 | Engine control unit -J623- |
| 10 | 10 (4.5) 15 (1.2.3) |
Lambda probe heater -Z19- Lambda probe 1 heater after catalytic converter -Z29- Power steering control unit -J500- |
| 11 | 5 | Radiator fan control unit -J293- Radiator fan -V7- Radiator fan 2 -V177- |
| 12 | 5 | Automatic gearbox control unit -J217- Mechatronic unit for dual clutch gearbox -J743- |
| 13 | 5 (2) | Air conditioner compressor control unit -J842- Electric air conditioner compressor -V470- |
| 14 | 5 (4) 20 (1,2,3) |
|
| 15 | 5 |
|
| 16 | 15 |
|
| 17 | 10 (2) 15 (3) |
Low temperature coolant pump -V468- Lambda probe heater -Z19- Lambda probe 1 heater after catalytic converter -Z29- |
| Relay | ||
| A | Glow plug control unit -J179- (7) Relay for voltage supply for engine electronics -J757- (8.9) |
|
| B | Starter relay -J53- Starter relay 2 -J695- |
|
| C | Secondary air pump relay -J299- (8.2) | |
| D | Terminal 30 voltage supply relay -J317- (7) Motronic supply relay -J271- (8.9) |
|
| E |
|
|
| F | Not used | |
| 1) Only for vehicles with 4-cylinder petrol engine (2.0l TFSI generation 3) 2) Only for vehicles with 4-cylinder petrol engine with high voltage system (hybrid) 3) Only for vehicles with 6-cylinder petrol engine (3 , 0 l TFSI) 4) Only for vehicles with a 4-cylinder diesel engine (2.0 l TDI) 5) Only for vehicles with a 6-cylinder diesel engine (3.0 l TDI) 6) Only for vehicles with a 6-cylinder diesel engine (3.0l TDI BIN 5) 7) Only for vehicles with diesel engine 8) Only for vehicles with 4-cylinder petrol engine 9) Only for vehicles with 6-cylinder petrol engine |
||
| Diagram (type 2) | ||
|---|---|---|
|
||
| Fuses in fuse holder ST1 (black) | ||
| 1 | 5 | Active steering control unit -J792- |
| 2 | 5 | Clutch pedal sender -F36- Clutch pedal sender for starting the engine -F194- Clutch pedal position sender -G476- Not used (from 2010) ABS control unit -J104- (from 2013) |
| 3 | 5 |
|
| 4 | 10 | Lane departure warning control unit -J759- |
| 5 | 5 15 (9) |
Air quality sender -G238- Structure-borne noise control control unit -J869- (from 2013) Engine noise control unit -J943- (from 2013) |
| 6 | 5 15 (9) |
|
| 7 | 5 | Power module for left headlight -J667- Front left headlight -MX1- (from 2013) |
| 8 | 5 |
|
| 9 | 5 | Automatic dimming interior mirror -Y7- (up to 2009) Distance control control unit -J428- (from 2010) and (from 2013) |
| 10 | 5 | Selector lever sender control unit -J587- Clutch pedal position sender -G476- (from 2010) and (from 2013) Selector lever lock solenoid -N110- |
| 11 | 5 |
|
| 12 | 5 | Refrigerant pressure and temperature sender -G395- (up to 2013) Onboard supply control unit -J519- (from 2013) |
| Supplement for fuse boxes from 2010 | ||
| 13 | 5 | 18-pin connector -T18a- (up to 2013) Airbag control unit -J234- (from 2013) Seat occupied recognition control unit -J706- (from 2013) Front passenger airbag deactivation warning lamp -K145- ( since 2013) |
| 14 | 5 15 (9) |
Warning light button -E229- (up to 2013) Airbag control unit -J234- (up to 2013) Seat occupied recognition control unit -J706- (up to 2013) Warning light warning lamp -K6- (up to 2013) ) Rear window wiper motor -V12- (from 2013) |
| 15 | 25 10 (9) |
ABS control unit -J104- (up to 2013) Fuse holder 2 -ST2- on fuse holder C -SC- (up to 2013) Fuse holder 1 -ST1- on fuse holder D -SD- (up to 2013) Fuse holder 4 -ST4- on fuse holder F -SF- (up to 2013) Power supply for fuse holder 1 -ST1- fuse holder D -SD- (from 2013) |
| 16 | 40 | Starter relay -J53- Starter relay 2 -J695- Fuse holder 1 -ST1- with fuse 3 on fuse holder B -SB3- Fuse holder 1 -ST1- with fuse 12 on fuse holder B -SB12- Fuse holder 1 -ST1- fuse 15 on fuse holder B -SB15- (from 2013) |
| Fuses in fuse holder ST2 (brown) | ||
| 1 | 5 | Circulation pump relay -J160- (up to 2009) Auto dimming interior mirror -Y7- (from 2010) Exhaust gas flap valve -N220- (from 2013) |
| 2 | 5 | Clutch pedal sender -F36- (up to 2009) Clutch pedal sender for engine starting -F194- (up to 2009) Clutch pedal position sender -G476- Brake light sender -F- (from 2010) and (from 2013) year) brake pedal position sender -G100- (from 2010) |
| 3 | 20 (3) 25 (1,2,4,9) |
Fuel booster pump -G6- Fuel pump control unit -J538- |
| 4 | 5 (8) 10 25 (2) |
|
| 5 | 15 (7) 30 (6) |
Onboard supply control unit -J519- Front left seat ventilation control unit -J800- |
| 6 | 5 (2.9) 10 |
ABS control unit -J104- |
| 7 | 25 15 (9) |
High pitched horn -H2- (from 2013) Low pitch horn -H7- (from 2013) Horn relay -J413- (up to 2013) |
| 8 | 30 | Driver side door control unit -J386- Rear left door control unit -J388- |
| 9 | 30 | Wiper motor control unit -J400- |
| 10 | 25 | ABS control unit -J104- |
| 11 | 15 30 (9) |
Driver side door control unit -J386- Rear left door control unit -J388- |
| 12 | 5 | Rain and light sensor -G397- |
| Fuses in fuse holder ST3 (red) | ||
| 1 | - | Not used |
| 2 | - | Not used |
| 3 | 10 | Switch for lumbar support for driver's seat -E176- Switch for lumbar support for front passenger seat -E177- |
| 4 | 35 | Active steering control unit -J792- |
| 5 | 10 | heating element for beverage holder -Z105- |
| 6 | 35 | Onboard supply control unit -J519- |
| 7 | 20 | Onboard supply control unit -J519- |
| 8 | 30 | Onboard supply control unit -J519- |
| 9 | 20 | Sliding sunroof control unit -J245- |
| 10 | 30 | Onboard supply control unit -J519- |
| 11 | 20 | Sunroof blind control unit -J394- |
| 12 | 5 | Alarm signal -H12- Anti -theft alarm sender -G578- |
| 1) Only for vehicles with petrol engine 2) Only for vehicles with 4-cylinder petrol engine with high voltage system (hybrid) 3) Only for vehicles with diesel engine (without J538) 4) Only for vehicles with diesel engine (with J538) 5 ) Only for left-hand drive vehicles 6) Only for vehicles without seat ventilation 7) Only for vehicles with seat ventilation 8) Vehicles up to and including 2009 9) Vehicles from 2013 |
||
Relay and fuse box in the switching unit
Located near the engine
| Diagram | ||
|---|---|---|
|
||
| № | A | Legend |
| 1 | 15 | Automatic gearbox control unit -J217- Mechatronic unit for dual clutch gearbox -J743- |
| 2 | 5 | Oil level and oil temperature sender -G266- |
| 3 | 5 | Air mass meter -G70- Engine control unit -J623- Power and control unit for electric drive -JX1- (10) |
| 4 | 5 | Engine control unit -J623- |
| 5 | 10 (2.10) 15 (3,4,5,6,7,8) 20 (1) |
|
| 6 | 15 | Engine control unit -J623- |
| 7 | 10 (1,4,5,6,7,8) 15 (2,3,10) |
Use element 1 of variable valve timing system -F366- BIS camshaft timing system element 8 -F373- Isp. element 9 of variable valve timing system -F374- BIS Isp. camshaft timing system element 12 -F377- Coolant circulation relay after off. -J151- motor relay additional coolant pump -J496- solenoid valve -N75- supercharging pressure limiting solenoid valve 1 absorber -N80- Solenoid valve left engine support -N144- electrohydraulic solenoid valve right engine mounts -N145- electrohydraulic valve 1 valve timing system -N205- Valve 2 for variable valve timing -N208- Bypass valve for turbocharger -N249- Fuel pressure regulator valve -N276- Fuel metering valve -N290- Intake manifold flap valve -N316- Valve 1 for variable valve timing -N318- Valve 2 for variable valve timing exhaust camshaft -N319- Climatronic coolant shut- off valve -N422- Oil pressure regulator valve -N428- Fuel system diagnostic pump -V144- Charge air cooling pump -V188- Secondary air pump relay -J299- (10) Secondary air injection valve -N112- (10) Exhaust gas flap valve 1 -N321-(10) Coolant circulation pump after off. engine -V51- (10) High temperature coolant pump -V467- (10) |
| 8 | 5 (7.10) 10 (5.6.8) 20 ( 1.2.3.4 ) |
Exhaust gas recirculation cooler pump -V400- Ignition coil 1 with output stage -N70- Ignition coil 2 with output stage -N127- Ignition coil 3 with output stage -N291- Ignition coil 4 with output stage -N292- Ignition coil 5 with output stage -N323- Ignition coil 6 with output stage -N324- Power and control unit for electric drive -JX1- |
| 9 | 5 (7.10) 15 (3.4) 20 (5.6.8) |
Additional fuel pump relay -J832- Lambda probe 1 heater after catalytic converter -Z29- Lambda probe 2 heater after catalytic converter -Z30- Power steering control unit -J500- (10) |
| 10 | 10 (7) 15 (1,2,3,4, 5,8,10) |
Lambda probe heater -Z19- Lambda probe 2 heater after catalytic converter -Z28- Lambda probe 1 heater after catalytic converter -Z29- |
| 11 | 5 | Radiator fan control unit -J293- Radiator fan control unit 2 -J671- Radiator fan -V7- (10) Radiator fan 2 -V177- (10) |
| 12 | 5 | Air mass meter -G70- Automatic gearbox control unit -J217- Mechatronic unit for dual clutch gearbox -J743- |
| K | 60 (9) 80 (8) 50 (10.11) |
Plate fuse for engine glow plugs -S39- Fuse for secondary air pump -S130- |
| L | 50 (10) 5 (9) |
Fuse 1 -S131- Fuse for NOx sensor -S360- |
| Hybrid Vehicle Supplement (up to 2012) | ||
| 13 | 5 | Air conditioner compressor control unit -J842- Electric air conditioner compressor -V470- |
| 14 | 20 | Ignition coil 1 with output stage -N70- Ignition coil 2 with output stage -N127- Ignition coil 3 with output stage -N291- Ignition coil 4 with output stage -N292- |
| 15 | - | Not used |
| 16 | 5 | Coolant pump for low temperature circuit -V468- |
| 17 | 5 | Engine control unit -J623- |
View and print PDF:
