This article provides a detailed overview of the fuse diagrams for the seventh-generation Chevrolet Malibu, covering model years 2007, 2008, 2009, 2010, 2011, and 2012.
Fuse number 20 in the trunk fuse block protects the cigarette lighter and auxiliary power receptacles.
Engine Compartment
The engine compartment fuse block is located adjacent to the battery. To access the fuses, remove the protective cover.
Overview of the engine compartment fuse block.
| Diagram | ||
|---|---|---|
|
||
| No. | Relay | |
| 28 | Cooling Fan 1 (Left) | |
| 29 | Cooling Fan Motor | |
| 30 | Cooling Fan 2 (Right) | |
| 31 | Starter Motor | |
| 32 | Ignition (Start) Relay | |
| 33 | Engine Control Module (ECM) | |
| 34 | A/C Compressor Clutch | |
| 35 | High Beam Headlamps | |
| 36 | Front Fog Lamps | |
| 37 | Horn Relay | |
| 38 | Low Beam Headlamps | |
| 39 | Windshield Wiper 1 | |
| 40 | Windshield Wiper 2 / Wiper Motor | |
| 48 | Daytime Running Lamps (DRL) | |
| 49 | Stop Lamps | |
| 53 | Transmission Auxiliary Fluid Pump Control Module / Secondary Air Injection (AIR) Pump | |
| No. | Diodes | |
| 27 | Windshield Wiper Relays 1 and 2 | |
| No. | Fuse | Amps |
| 1 | A/C Compressor Clutch Relay | 10 |
| 2 | Engine Control Module (ECM) | 15 |
| 3 | 3.5L (LZ4, LZE): Engine Control Module (ECM) | 10 |
| 2.4L (LAT): Generator Battery Disconnect Control Module, Starter Generator Control Module (SGCM) | 10 | |
| 4 | Shift Solenoid 1-2, Shift Solenoid 2-3, Shift Solenoid 4-3, Torque Converter Clutch Pulse Width Modulation (TCC PWM), Transmission Control Module (TCM) | 10 |
| 5 | 3.6L (LY7): Mass Air Flow (MAF) Sensor / Intake Air Temperature (IAT) Sensor | 10 |
| 2.4L (LAT): Starter Generator Control Module (SGCM), Heater Coolant Pump | 20 | |
| 6 | Evaporative Emission (EVAP) Canister Purge Solenoid, Heated Oxygen Sensors (HO2S), Mass Air Flow (MAF) / Intake Air Temperature (IAT) Sensor (2.4L (LAT, LE5, LE9)) | 10 |
| 7 | Left Low Beam Headlamp | 10 |
| 8 | Horn Relay | 15 |
| 9 | Right Low Beam Headlamp | 10 |
| 10 | Front Fog Lamp Relay | 15 |
| 11 | Left High Beam Headlamp | 10 |
| 12 | Right High Beam Headlamp | 10 |
| 13 | 2.4L (LAT, LE5, LE9), 3.6L (LY7): Engine Control Module (ECM), Telematics Vehicle Localization and Immobilizer Control Module | 10 |
| 14 | Windshield Wiper Relays 1 and 2, Wiper Motor Assembly | 25 |
| 15 | Anti-lock Brake System (ABS) / Electronic Brake Control Module (EBCM) | 10 |
| 16 | 2.4L (LAT, LE5, LE9), 3.6L (LY7): Engine Control Module (ECM), Telematics Vehicle Localization and Immobilizer Control Module | 10 |
| 17 | Cooling Fan Relay 1 | 30 |
| 18 | Cooling Fan Relay 2 | 30 |
| 3.6L (LY7 - 2012): Cooling Fan Relay 2 | 40 | |
| 19 | Cooling Fan Motor Control Module, Cooling Fan Motor Relay, RUN Relay | 30 |
| 20 | Body Control Module (BCM); Passenger Compartment Fuses: “20”, “21”, “22”, “23”, “24” | 30 |
| 21 | Passenger Compartment Fuses: “12”, “14”, “15” | 30 |
| 22 | Trunk Block Fuses: “10”, “13”, “14”, “16”, “17”, “20”, “23” | 60 |
| 23 | Trunk Block Fuses: “1”, “2”, “5”, “6”, “22”, “25” | 60 |
| 24 | Anti-lock Brake System (ABS) / Electronic Brake Control Module (EBCM) | 60 |
| 25 | Body Control Module (BCM); Passenger Compartment Fuses: “1”, “2”, “5”, “6”, Auxiliary Relay | 50 |
| 26 | Starter Relay | 30 |
| 41 | 2.4L (LE5, LE9, LAT): Power Steering Control Module (PSCM) | 80 |
| 42 | Transmission Control Module (TCM) | 10 |
| 43 | 3.6L (LY7): Fuel Injectors (Odd), Ignition Coils/Modules (Odd) | 15 |
| 2.4L (LE5 or LE9): Ignition Coils | 15 | |
| 3.5L (LZ4, LZE): Ignition Control Module (ICM) | 15 | |
| 44 | 3.6L (LY7): Fuel Injectors (Even), Ignition Coil Modules (Even) | 15 |
| 2.4L (LE5, LE9, LAT), 3.5L (LZ4, LZE): Fuel Injectors | 10 | |
| 45 | 3.5L (LZ4, LZE), 3.6L (LY7): Heated Oxygen Sensor (HO2S) Bank 1 Sensor 2, Heated Oxygen Sensor (HO2S) Bank 2 Sensor 2 | 10 |
| 46 | Daytime Running Lamps (DRL) Relay | 15 |
| 47 | Stop Lamp Relay | 10 |
| 50 | Power Windows | 20 |
| 51 | 2.4L (LAT): Starter Generator Control Module (SGCM) | 10 |
| 3.5L (LZ4, LZE): Engine Control Module (ECM) | 10 | |
| 52 | Secondary Air Injection (AIR) Pump Relay | 10 |
| Transmission Auxiliary Fluid Pump Control Module | 20 | |
| 54 | Body Control Module (BCM) (Regulated Voltage Control) | 5 |
| 2.4L (LAT): Body Control Module (BCM) (Regulated Voltage Control) | 15 | |
| 55 | DC/AC Inverter | 30 |
| 56 | Anti-lock Brake System (ABS) / Electronic Brake Control Module (EBCM) | 30 |
| 57 | Spare | 20 |
Passenger Compartment
The fuse block is located on the passenger side, near the floorboard. Remove the interior trim panel, and then remove the fuse block cover.
Example of access.
Overview of the passenger compartment fuse block.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Amps |
| 1 | Body Control Module (BCM) (Door Locks) | 15 |
| 2 | Body Control Module (BCM) (Interior Lamps) | 10 |
| 3 | Steering Wheel Controls | 2 |
| 4 | 2007-2008: Adjustable Pedal Module, Adjustable Pedal Position Switch | 10 |
| 5 | Vehicle Communication Interface Module (VCIM) / OnStar | 10 |
| 6 | Power Mirror Switch | 2 |
| 7 | Heated Seat Control Module (Driver/Passenger), Heated Seat Switch (Driver/Passenger), Interior Rearview Mirror, Sunroof Control Module | 10 |
| 8 | Empty | — |
| 9 | Empty | — |
| 10 | Windshield Wiper/Washer Switch | 10 |
| 11 | Empty | — |
| 12 | Power Steering Control Module (PSCM) | 2 |
| 13 | Power Windows | 30 |
| 14 | Inflatable Restraint Sensing and Diagnostic Module (SDM) | 10 |
| 15 | Automatic Transmission Shift Lock Control Assembly, Cruise Control Switch, Passenger Airbag Status Indicator | 2 |
| 16 | Empty | — |
| 17 | Heating, Ventilation, and Air Conditioning (HVAC) Control Module | 10 |
| 18 | Empty | — |
| 19 | Heating, Ventilation, and Air Conditioning (HVAC) - Blower Switch | 20 |
| 20 | Inflatable Restraint Sensing and Diagnostic Module (SDM) | 10 |
| 21 | Audio System | 10 |
| 22 | Ignition Switch | 2 |
| 23 | Data Link Connector (DLC), Heating, Ventilation, and Air Conditioning (HVAC) Control Module | 10 |
| 24 | Instrument Cluster, Theft-Deterrent Control Module | 10 |
| Relays | ||
| R1 | Cooling Fan Motor | |
| Non-Serviceable Relays | ||
| R2 | Power Door Locks | |
| R3 | Power Door Locks (Unlock) | |
| R4 | Driver Door Lock Actuator (Unlock) | |
| R5 | Interior Lamps | |
Trunk Compartment
The fuse block is located on the right side of the trunk, behind the trim panel.
Example of access.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Amps |
| 1 | Passenger Power Seat Control Module | 30 |
| 2 | Driver Power Seat Control Module | 30 |
| 3 | Spare | — |
| 4 | Spare | — |
| 5 | Evaporative Emission (EVAP) Canister Vent Solenoid Valve | 10 |
| 6 | Park Lamp Relay (Body Control Module (BCM), License Plate Lamps, Park/Turn Signal Lamps, Tail Lamps, Tail/Stop Lamps, and Turn Signal Lamps), Instrument Panel Dimmer | 10 |
| 7 | Spare | — |
| 8 | Spare | — |
| 9 | Sunroof Control Module, Sunshade Module | 25 |
| 10 | Sunroof Control Module | 15 |
| 11 | Spare | — |
| 12 | Spare | — |
| 13 | Audio Amplifier | 25 |
| 14 | Heated Seats | 15 |
| 15 | Spare | — |
| 16 | Digital Radio, Garage Door Opener Transmitter, Remote Control Door Lock Receiver (RCDLR) | 7.5 |
| 17 | Backup Lamp Relay | 10 |
| 18 | Spare | — |
| 19 | Spare | — |
| 20 | Chevrolet Malibu Cigarette Lighter Fuse, Auxiliary Power Receptacle (Center Console) | 20 |
| 21 | Spare | — |
| 22 | Trunk Release Relay | 10 |
| 23 | Rear Window Defogger | 30 |
| 24 | Heated Mirrors | 10 |
| 25 | Fuel Pump Fuse | 15 |
| 26 | Rear Window Defogger and Heated Mirror Relay | |
| 27 | Park Lamps (Backup Lamps, Body Control Module (BCM), Garage Door Opener Transmitter, HVAC Control Module, License Plate Lamps, Park/Turn Signal Lamps, Tail Lamps, Tail/Stop Lamps, and Turn Signal Lamps) | |
| 28 | Spare | |
| 29 | Spare | |
| 30 | Spare | |
| 31 | Spare | |
| 32 | Spare | |
| 33 | Backup Lamps, Interior Rearview Mirror | |
| 34 | Spare | |
| 35 | Spare | |
| 36 | Trunk Release Relay | |
| 37 | Fuel Pump Relay | |
| 38 | Trunk Release Diode | |
