This article provides a detailed overview of the fuse box diagrams for the ninth-generation Chevrolet Malibu E2XX, covering model years 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, and 2023.
Fuse number 37 in the instrument panel fuse block protects the front power outlets (cigarette lighter).
Engine Compartment Fuse Block
The underhood fuse block is located on the driver's side of the engine compartment. To access the fuses, remove the protective cover.
General overview.
| Diagram | ||
|---|---|---|
|
||
| No. | Relay | |
| 4 | AC/DC inverter | |
| 20 | Rear window defogger | |
| 25 | Front wiper control | |
| 31 | Starter relay 1 | |
| 37 | Front wiper speed control | |
| 42 | Auxiliary transmission fluid pump | |
| 64 | Starter relay 2 | |
| 68 | Engine Control Module (ECM) relay | |
| 71 | HID headlamps - low beam | |
| 73 | A/C compressor clutch | |
| 80 | Starter motor | |
| 90 | Secondary Air Injection (SAI) valve | |
| 94 | Headlamp washer | |
| 98 | Secondary Air Injection (SAI) pump | |
| No. | Fuses | Amps |
| 1 | Empty | - |
| 2 | Empty | - |
| 3 | Anti-lock Brake System (ABS) pump | 60 |
| 5 | AC/DC inverter | 60 |
| 6 | Trunk release | 7.5 |
| 7 | Theft-deterrent siren / Horn | 7.5 |
| 8 | Power windows / Power mirrors / Power seats | 5 |
| 9 | Electronic brake booster | 5 |
| 10 | Power seats / AOS / Airbag (HEV) | 15 |
| 11 | Battery 1 | 40 |
| 12 | Rear window defogger | 40 |
| 13 | Heated outside mirrors | 10 |
| 14 | Empty | - |
| 15 | Passive Entry / Passive Start (PEPS) | 5 |
| 16 | Front wipers | 20 |
| 17 | Passenger power seat | 30 |
| 18 | Anti-lock Brake System (ABS) valves | 30 |
| 19 | Driver power seat | 30 |
| 21 | Sunroof | 30 |
| 22 | Parking lamps | 5 |
| 23 | Adaptive Forward Lighting (AFL) | 10 |
| 24 | Empty | - |
| 26 | Transmission Control Module (TCM) / Ignition | 15 |
| 27 | Instrument cluster / Ignition | 10 |
| 28 | Fuel pump | 10 |
| 29 | Regulated Voltage Control (RVC) / Ventilated seats / Rearview camera | 10 |
| 30 | Malfunction Indicator Lamp (MIL) / Ignition | 5 |
| 32 | EVAP canister vent solenoid / EVAP leak detection pump | 5 |
| 33 | Heated front seats | 15 |
| 34 | Blind Spot Monitoring (BSM) / ESS cooling fan / Heated rear seats | 10/15 |
| 35 | Body Control Module (BCM) 6 and 7 | 10 |
| 36 | Fuel pump control module | 20 |
| 38 | Empty | - |
| 39 | Empty | - |
| 40 | Electronic steering column lock | 10 |
| 41 | Empty | - |
| 43 | Heated steering wheel | 15 |
| 44 | Adaptive Forward Lighting (AFL) | 10 |
| 45 | Empty | - |
| 46 | Engine Control Module (ECM) / Ignition | 15 |
| 47 | Empty | - |
| 48 | Electronic brake booster (HEV) | 60 |
| 49 | DC battery 2 | 40 |
| 50 | Empty | - |
| 51 | Empty | - |
| 52 | Empty | - |
| 53 | Empty | - |
| 54 | Empty | - |
| 55 | Empty | - |
| 56 | Starter motor | 30 |
| 57 | Auxiliary transmission fluid pump | 40 |
| 58 | Empty | - |
| 59 | High beam headlamps | 10 |
| 60 | Engine cooling fan | 60 |
| 61 | Empty | - |
| 62 | Empty | - |
| 63 | Empty | - |
| 65 | A/C compressor (HEV) | 10 |
| 67 | Empty | - |
| 68 | Empty | - |
| 69 | Right HID low beam headlamp | 20 |
| 70 | Left HID low beam headlamp | 20 |
| 72 | Starter pinion | 40 |
| 74 | Empty | - |
| 75 | Engine Control Module (ECM) | 25 |
| 76 | Engine-off auxiliary power unit | 15 |
| 78 | Horn | 20 |
| 79 | Windshield washer pump | 20 |
| 81 | Transmission Control Module (TCM) / Engine Control Module (ECM) | 15 |
| 82 | Empty | - |
| 83 | Ignition coils | 15 |
| 84 | Engine-mounted power unit | 15 |
| 85 | Engine Control Module (ECM) switch 2 | 60 |
| 86 | Engine Control Module (ECM) switch 1 | 60 |
| 87 | Secondary Air Injection (SAI) pump | 50 |
| 88 | Active aero shutters | 10 |
| 89 | Headlamp washer | 25 |
| 91 | Empty | - |
| 92 | Traction Power Inverter Module (TPIM) / Generator motor | 10 |
| 93 | Adaptive Forward Lighting (AFL) | 10 |
| 95 | Secondary Air Injection (SAI) valve | 15 |
| 96 | Fuel heater | 25 |
| 97 | Empty | - |
| 99 | Engine coolant pump | 10 |
Instrument Panel Fuse Block
The instrument panel fuse block is located on the lower left side of the dashboard, behind the plastic trim cover.
Access example.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Amps |
| F1 | Left power windows | 30 |
| F2 | Right power windows | 30 |
| F3 | Empty | — |
| F4 | HVAC blower motor | 40 |
| F5 | Body Control Module (BCM) 2 | 15 |
| F6 | Left heated rear seat | — |
| F7 | Right heated rear seat | — |
| F8 | Body Control Module (BCM) 3 | 15 |
| F9 | Engine Control Module (ECM) / Rear battery | 5 |
| F10 | Body Control Module (BCM) 2 (with Start/Stop) | 15 |
| F11 | Empty | — |
| F12 | Empty | — |
| F13 | Empty | — |
| F14 | Empty | — |
| F15 | Transmission Control Module (TCM) (with Start/Stop) | 20 |
| F16 | Audio amplifier | 30 |
| F17 | Power lumbar support | — |
| F18 | OnStar system | — |
| F19 | Empty | — |
| F20 | Body Control Module (BCM) 1 | 15 |
| F21 | Body Control Module (BCM) 4 | 15 |
| F22 | Empty | — |
| F23 | Electronic steering column lock (China and Russia only) | 10 |
| F24 | Airbags | 10 |
| F25 | Data Link Connector (DLC) | 7.5 |
| F26 | Empty | — |
| F27 | AC/DC inverter (30A) | 30 |
| F28 | Empty | — |
| F29 | Body Control Module (BCM) 8 | 20 |
| F30 | Overhead console | 10 |
| F31 | Steering wheel controls | — |
| F32 | Empty | — |
| F33 | HVAC control module | 10 |
| F34 | Gateway module | — |
| F35 | Empty | — |
| F36 | Wireless charging module | 5 |
| F37 | Front power outlets / Cigarette lighter | 20 |
| F38 | OnStar system | 5 |
| F39 | Infotainment display | 7.5 |
| F40 | Park assist | 10 |
| F41 | Body Control Module (BCM) 1 (with Start/Stop) | 15 |
| F42 | Radio | 15 |
| CB1 | Empty | — |
| CB2 | Center console power outlet | 15 |
| Relay | ||
| K1 | Empty | — |
| K2 | Auxiliary relay | — |
| K3 | Empty | — |
| K4 | Empty | — |
| K5 | Empty | — |
