This article provides a detailed overview of the fuse box diagrams for the fifth-generation Daihatsu Mira and Cuore (L700 / L7 code; Lightweight K-car platform) covering the 1998 through 2003 model years.
Fuse No. 12 in the passenger compartment fuse box protects the cigarette lighter circuit.
Engine Compartment Fuse Box
The engine compartment fuse box is located on the left side of the engine bay, beneath a protective cover.
An example of the engine compartment fuse box.
| Diagram | ||
|---|---|---|
|
||
| No. | Circuit Description | Amperage (A) |
| R1 | Fuel pump relay | |
| R2 | Starter motor relay | |
| R3 | Fuel injection system relay | |
| R4 | A/C compressor relay | |
| R5 | Engine management relay | |
| R6 | Radiator cooling fan relay | |
| 1 | Reverse lights | 10 |
| 2 | Fuel injection system | 15 |
| 3 | Horn / Hazard warning lights | 15 |
| 4 | Engine control module (ECM) / A/C system | 10 / 20 |
| 5 | Ignition switch (Main) | 60 |
| 6 | ABS / ESC control module | 50 |
| 7 | Taillights main | 40 |
| 8 | Headlights main | 30 |
| 9 | Radiator cooling fan | 30 |
Passenger Compartment Fuse Box
The interior fuse box is located on the left side, behind the instrument panel.
General view of the interior fuse box.
| Diagram | ||
|---|---|---|
|
||
| No. | Circuit Description | Amperage (A) |
| 1 | Fog lights | 15 |
| 2 | Taillights / Parking lights | 10 |
| 3 | Rear window defogger | 15 |
| 4 | Power accessories | 30 |
| 5 | Instrument cluster | 10 |
| 6 | Engine control module (ECM) | 10 |
| 7 | Spare | 10 |
| 8 | Spare | 15 |
| 9 | Not used | - |
| 10 | Windshield wipers / Washer | 15 |
| 11 | HVAC blower motor | 20 |
| 12 | Cigarette lighter | 15 |
| 13 | Left headlight | 10 |
| 14 | Right headlight | 10 |
| 15 | Brake lights | 10 |
| 16 | Engine control module (ECM) | 10 |
| 17 | SRS airbags | 10 |
| 18 | Central power door locks | 15 |
| 19 | Not used | - |
