This article provides a detailed overview of the fuse box diagrams for the second-generation Ford Fusion (CD4 platform; chassis code CD389), covering the 2013, 2014, 2015, 2016, 2017, 2018, 2019, and 2020 model years.
Fuses No. 17, 16, 10, and 5 in the engine compartment fuse block protect the electrical circuits for the USB ports and 12V power points (cigarette lighters).
Engine Compartment Fuse Box
The engine compartment fuse and relay box (Battery Junction Box) is located on the left side of the engine bay, behind a protective cover.
Upper Section of the Fuse Box
Example of access.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Current (A) |
| 29 | Mass Air Flow (MAF) sensor or Not used | 5 |
| 44 |
|
5 / 20 |
| 49 |
|
5 / 20 / 10 |
| 54 |
|
5 / 10 |
| 13 | Powertrain Control Module (PCM) or Not used | 10 |
| 14 | Powertrain Control Module (PCM) or Not used | 10 |
| 18 | Powertrain Control Module (PCM) or Not used | 10 |
| 19 | Power Steering Control Module (PSCM) | 10 |
| 20 | Push-button start/stop illumination, Cruise control | 10 |
| 22 | Air conditioning (A/C) clutch solenoid | 10 |
| 24 | Spare or Run/Start circuit | 10 |
| 25 | Anti-lock Braking System (ABS) | 10 |
| 26 | Powertrain Control Module (PCM) | 10 |
| 27 | Spare | 10 |
| 28 | Rear window washer pump or Not used | 10 |
| 46 | Alternator or Not used | 10 |
| 47 | Brake pedal position switch or Not used | 10 |
| 50 |
|
10 / 20 |
| 53 | Power seats or Not used | 10 |
| 55 | Battery Management Sensor (BMS) or Not used | 10 |
| 3 | Automatic windshield wipers, Rain sensor, Rear wipers | 15 |
| 11 | Powertrain Control Module (PCM) | 15 |
| 12 | Powertrain Control Module (PCM) | 15 |
| 21 | Transmission Control Module (TCM), Transmission fluid pump | 15 |
| 23 | Auto Start-Stop system, Blind Spot Information System (BLIS), Rearview camera, Adaptive cruise control, Forward collision warning, Voltage Quality Module (VQM), Air quality sensor | 15 |
| 34 | Electronic steering column lock or Not used | 15 |
| 5 | Rear console 12V power point | 20 |
| 7 | Powertrain Control Module (PCM) | 20 |
| 8 | Powertrain Control Module (PCM) | 20 |
| 10 | Driver's side front 12V power point | 20 |
| 16 | Front console 12V power point (cigarette lighter) | 20 |
| 17 | Trunk/cargo area 12V power point or Not used | 20 |
| 48 | Horn or Not used | 20 |
| 1 |
|
25 / 30 |
| 2 | Starter motor relay | - |
| 4 | Electric cooling fan relay | - |
| 6 | Auxiliary heater relay or Not used | - |
| 9 | Powertrain Control Module (PCM) relay | - |
| 15 | Run/Start relay | - |
| 32 | Engine cooling fan relay #1 | - |
| 33 | Air conditioning (A/C) clutch relay | - |
| 38 | Engine cooling fan relay #2 | - |
| 39 | Engine cooling fan relay #3 or Not used | - |
| 40 | Horn relay or Fuel pump relay or Engine cooling fan relay #2 and #3 | - |
| 41 | Horn relay or Not used | - |
| 42 | Fuel pump relay or Not used | - |
| 30 | Spare | - |
| 31 | Spare | - |
| 35 | Spare | - |
| 36 | Spare | - |
| 37 | Spare | - |
| 43 | Spare | - |
| 45 | Spare | - |
| 51 | Spare | - |
| 52 | Spare | - |
Bottom Section of the Fuse Box
Located on the reverse side of the block.
Example of access.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Current (A) |
| 57 | Diesel fuel vaporizer or Not used | 20 |
| 65 | Heated front seats | 20 |
| 72 |
|
20 / 30 |
| 73 | Heated rear seats or Not used | 20 |
| 76 | Transmission fluid pump or Power liftgate module or Not used | 20 |
| 83 | Windshield wiper motor or Transmission Range Control Module (TRCM) | 25 |
| 56 | Fuel pump fuse or Not used | 30 |
| 64 | Auxiliary heater or Not used | 30 |
| 69 | Anti-lock Braking System (ABS) module | 30 |
| 70 | Passenger seat control module | 30 |
| 74 | Driver seat control module | 30 |
| 75 | Auxiliary heater or Not used or Windshield wiper motor #1 | 30 |
| 77 | Climate Controlled Seat Module (CCSM) or Not used | 30 |
| 80 | Rear power module (trunk) or Not used or Windshield wiper motor #2 | 30 / 25 |
| 84 | Starter motor solenoid | 30 |
| 61 | Heated windshield (left side) or Not used | 40 |
| 66 | Heated windshield (right side) or Not used | 40 |
| 68 | Heated rear window (defrost) | 40 |
| 78 | Trailer tow module or Not used | 40 |
| 79 | Electric cooling fan | 40 |
| 81 |
|
40 |
| 62 | Body Control Module (BCM) | 50 |
| 67 | Body Control Module (BCM) | 50 |
| 71 |
|
60 / 50 |
| 82 | Anti-lock Braking System (ABS) pump or Not used | 60 |
| 58 | Fuel pump or Not used | 30 |
| 63 | DW10F and 2.0L GTDI AU engine cooling fan | 20 / 30 |
| 85 |
|
20 / 60 / 30 |
| 59 | DW10F and 2.0L GTDI AU engine cooling fan | 30 / 40 |
| 60 | DW10F and 2.0L GTDI AU engine cooling fan | 30 / 40 |
Passenger Compartment Fuse Box
The interior fuse box is located behind the lower instrument panel trim on the driver's side.
The trim panel must be removed to gain access.
General overview.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Current (A) |
| 1 | Interior lighting, Glove box lamp, Vanity mirror lamp, Courtesy lamp, Trunk/cargo area lamp / Not used since 2019 | 10 |
| 2 | Memory seat module, Driver's seat backrest, Power exterior mirrors | 7.5 |
| 3 | Driver's door unlock relay | 20 |
| 4 | Not used | 5 |
| 5 | Subwoofer amplifier | 20 |
| 6 | Not used or Heated seat relay | 10 |
| 7 | Not used | 10 |
| 8 | Anti-theft alarm sounder or Not used | 10 |
| 9 | Not used | 10 |
| 10 | Rear door power module, Keyless entry keypad, SYNC/Telematics module or Not used | 5 |
| 11 | Restraint Control Module (RCM) or Not used | 5 |
| 12 | Climate control module, Transmission shifter | 7.5 |
| 13 | Steering Column Control Module (SCCM), Instrument cluster, Data Link Connector (DLC) | 7.5 |
| 14 | Advanced Power Module (Battery Management System) or Not used | 10 |
| 15 | Data Link Gateway module | 10 |
| 16 | Child safety locks, Trunk release relay or Not used | 15 |
| 17 | Battery backup sounder (alarm) or Not used or Vehicle tracking module |
5 |
| 18 | Ignition switch, Push-button start switch | 5 |
| 19 | Passenger Airbag Deactivation (PAD) indicator, Transmission control or Advanced Power Module | 7.5 |
| 20 | Headlamp control module or Not used | 7.5 |
| 21 | In-vehicle temperature and humidity sensor. Blind Spot Information System (BLIS). Rearview camera. Adaptive cruise control. | 5 |
| 22 | Occupant Classification System (OCS) module or Not used | 5 |
| 23 | Accessory delay power circuit | 10 |
| 24 | Central locking system | 20 |
| 25 | Driver's door module and power exterior mirror | 25 |
| 26 | Passenger's door module and power exterior mirror | 30 |
| 27 | Moonroof / Sunroof | 30 |
| 28 | Audio amplifier | 20 |
| 29 | Power window, rear driver's side | 30 |
| 30 | Power window, rear passenger's side | 30 |
| 31 | Not used | 15 |
| 32 | GPS module, Voice control (SYNC), Infotainment display, Radio unit | 10 |
| 33 | Radio unit, Active Noise Control (ANC) system. CD player. | 20 |
| 34 | Auto Start-Stop system bus (fuses 19, 20, 21, 22, 35, 36, 37, circuit breaker) | 30 |
| 35 | Restraint Control Module (RCM) or Not used | 5 |
| 36 | Auto-dimming interior rearview mirror, Heated front and rear seats, Lane Keeping System, Automatic high beams. Climate Controlled Seat Module (CCSM). | 15 |
| 37 | All-Wheel Drive (AWD) module. Heated steering wheel. or Voltage Quality Module (VQM) | 15 |
| 38 | Not used | 30 |
