The electrical circuits of this Japanese premium sedan are protected by fuses and relays. These components are housed in distribution panels located in the engine compartment and the passenger compartment.
This guide provides detailed fuse box diagrams and location references for the first-generation (V36) Infiniti G35 / G37 / G25 / Q40 (2006–2015 model years). Component layout photos and distribution box locations are detailed below. The fuse assigned to the cigarette lighter is highlighted in bold text.
In the engine compartment
The engine compartment fuse blocks are located on the left side of the engine bay.
Fuse box #1
General view.
| Diagram | ||
|---|---|---|
|
||
| No. | Circuit Protected | A |
| 41 | Fuel pump relay | 15 |
| 42 | Cooling fan relay | 10 |
| 43 | Transmission Control Module (TCM), Snow Mode switch, Park/Neutral position switch | 10 |
| 44 | Fuel injectors, Engine Control Module (ECM), Body Control Module (BCM) | 10 |
| 45 | ABS, Intelligent Cruise Control (ICC), steering angle sensor, yaw rate & lateral G-sensor, power steering control unit, AWD control unit, Four-Wheel Active Steer (4WAS) control unit | 10 |
| 46 | Air/fuel ratio (A/F) sensors, heated oxygen sensors (HO2S) | 15 |
| 47 | Windshield washer pump | 10 |
| 48 | '06–'11: Steering lock relay | 10 |
| '14–'15 (Q40): A/C compressor relay | 10 | |
| 49 | '06–'13: A/C compressor relay | 10 |
| '14–'15 (Q40): Engine Control Module (ECM), ECM relay (ignition coils, condenser, intake valve timing control solenoid valve, MAF sensor, EVAP vent control valve), Variable Valve Event and Lift (VVEL) | 15 | |
| 50 | '06–'13: Engine Control Module (ECM), ECM relay (ignition coils, condenser, intake valve timing control solenoid valve, exhaust valve timing control magnet retarder, MAF sensor, EVAP vent control valve), Variable Valve Event and Lift (VVEL) | 15 |
| '14–'15 (Q40): Throttle control motor relay | 15 | |
| 51 | '06–'13: Throttle control motor relay | 15 |
| 52 | '06–'13: Front clearance / parking lights | 10 |
| '14–'15 (Q40): Taillights, license plate light, interior lights, instrument panel illumination | 10 | |
| 53 | '06–'13: Taillights, license plate light, interior lights, instrument panel illumination | 10 |
| '14–'15 (Q40): Left headlight (high beam) | 10 | |
| 54 | '06–'13: Left headlight (high beam) | 10 |
| '14–'15 (Q40): Right headlight (high beam) | 10 | |
| 55 | '06–'13: Right headlight (high beam) | 10 |
| '14–'15 (Q40): Left headlight (low beam) | 15 | |
| 56 | '06–'13: Left headlight (low beam) | 15 |
| '14–'15 (Q40): Right headlight (low beam) | 15 | |
| 57 | '06–'13: Right headlight (low beam) | 15 |
| '14–'15 (Q40): Front fog light relay | 15 | |
| 58 | '06–'13: Front fog light relay | 15 |
| 59 | '11–'13: Daytime running light (DRL) relay | 10 |
| '14–'15 (Q40): Windshield wiper relay | 30 | |
| 60 | '06–'13: Windshield wiper relay | 30 |
Fuse box #2
General view.
| Diagram | ||
|---|---|---|
|
||
| No. | Circuit Protected | A |
| 31 | Horn relay #1 | 15 |
| 32 | Alternator | 10 |
| 33 | All-Wheel Drive (AWD) control unit | 10 |
| 34 | Audio system, AV control unit, subwoofer, camera control unit, Bluetooth/telephone adapter, satellite radio receiver, CD changer | 15 |
| 35 | Heated seat relay, climate-controlled seat relay (Convertible) | 15 |
| 36 | Transmission Control Module (TCM) | 10 |
| 37 | '06–'10: Four-Wheel Active Steer (4WAS) relay | 20 |
| Convertible: Climate-controlled seat relay | 15 | |
| 38 | Horn relay #2 | 10 |
| F | Cooling fan relay | 50 |
| G | Pre-crash seat belt system | 30 |
| H | Ignition relay (fuses “2”, “3”, “4”) | 30 |
| I | '06–'10: Four-Wheel Active Steer (4WAS) control unit | 40 |
| Convertible: Convertible top hydraulic unit | 50 | |
| J | - | - |
| K | Body Control Module (BCM), circuit breaker (Automatic Drive Positioner, power seat) | 40 |
| L | ABS control unit | 30 |
| M | ABS motor / control unit | 50 |
| N | Variable Valve Event and Lift (VVEL) control unit | 50 |
| O | Convertible: Convertible top control unit | 30 |
| Relay | ||
| R1 | Horn relay #1 | |
| R2 | Shift lock solenoid / relay | |
Fusible link block (Battery)
Located on the battery positive terminal.
| Diagram | ||
|---|---|---|
|
||
| No. | Circuit Protected | A |
| A | Alternator, fuses “B” and “C” | 140 |
| B | Fuses “F”, “H”, “I”, “K”, “L”, “M”, “31”, “32”, “33”, “34”, “35”, “36”, “37”, “38” | 100 |
| C | Ignition relay (fuses “41”–“47”), fuses “48”, “50”, “51” | 80 |
| D | High beam relay (fuses “54”, “55”), low beam relay (fuses “56”, “57”), parking light relay (fuses “52”, “53”), fuse “58” | 60 |
| E | Accessory relay (fuses “18”, “19”, “20”), rear window defogger relay (fuses “13”, “14”, “15”), blower motor relay (fuses “21”, “22”), fuses “5”, “6”, “7”, “9”, “10”, “11” | 80 |
In the passenger compartment
Located in the driver's footwell, behind the protective kick panel cover.
General view of the interior fuse panel.
| Diagram | ||
|---|---|---|
|
||
| No. | Circuit Protected | A |
| 1 | Pre-crash seat belt system | 10 |
| 2 | Airbags (SRS) | 10 |
| 3 | Headlight aiming control unit, camera control unit, shift lock relay, cruise control (ASCD), Intelligent Cruise Control (ICC), Adaptive Front-lighting System (AFS), Data Link Connector (DLC), Unified Meter and A/C Amp, heated seat relay, AV control unit, Bluetooth/telephone adapter, A/C compressor, auto-dimming rearview mirror, Four-Wheel Active Steer (4WAS) control unit, parking sonar control unit, PlasmaCluster ionizer, air quality sensor, climate-controlled seat relay | 10 |
| 4 | Combination meter, reverse lamp relay (A/T), reverse lamp switch (M/T) | 10 |
| 5 | Bose® audio amplifier | 15 |
| 6 | Intelligent Key slot, Intelligent Key warning buzzer, Data Link Connector (DLC), Unified Meter and A/C Amp, clock, auto-dimming rearview mirror, rain and light sensor, sunroof warning buzzer | 10 |
| 7 | Stop lamp switch, Body Control Module (BCM), Intelligent Cruise Control (ICC) | 10 |
| 8 | Bose® audio amplifier | 15 |
| 9 | Intelligent Key slot, push-button ignition switch, clutch interlock switch (M/T) | 10 |
| 10 | Body Control Module (BCM), seat memory, Automatic Drive Positioner (ADP), driver power seat control module | 10 |
| 11 | Combination meter, Unified Meter and A/C Amp, All-Wheel Drive (AWD) control unit | 10 |
| 12 | - | - |
| 13 | Heated outside mirrors | 10 |
| 14 | Rear window defogger | 20 |
| Convertible: Convertible top control unit | 20 | |
| 15 | Rear window defogger | 20 |
| Convertible: Convertible top control unit | 20 | |
| 16 | - | - |
| 17 | - | - |
| 18 | '06–'11: Cigarette lighter | 15 |
| 19 | Combination meter, Unified Meter and A/C Amp, display unit, combination switch, AV control unit, Body Control Module (BCM), Bluetooth/telephone adapter, camera control unit, power mirrors, satellite radio receiver, CD changer, parking sonar control unit | 10 |
| 20 | '06–'09: Center console power socket | 15 |
| '10–'13: Cigarette lighter, center console power socket | 20 | |
| 21 | Blower motor | 15 |
| 22 | 15 | |
|
|
| No. | Relay |
| R1 | Ignition relay |
| R2 | Rear window defogger relay |
| R3 | Accessory relay |
| R4 | Blower motor relay |
