The Jaguar F-Type is a two-seat sports car that debuted for the 2013 model year, serving as the spiritual successor to the legendary E-Type. Available in both coupé and convertible body styles with rear-wheel or all-wheel drive, this guide provides detailed fuse box diagrams and panel locations for first-generation Jaguar F-Type (chassis code X152) models produced from 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, and 2022.
Below you will find power distribution box locations, photo reference guides, and complete fuse assignment tables. Fuses for critical components such as the “Cigarette Lighter” and “Fuel Pump” are highlighted in bold text.
Luggage Compartment Fuse Box
1. Convertible: Remove the left-side trunk access panel (covering the battery). Remove the lower trunk floor liner.
2. Coupé: Lift the luggage compartment floor panel and remove the floor support assembly. Remove the left-side trunk side panel (battery access). Remove the remaining luggage compartment trim panels.
General view.
| Diagram | ||
|---|---|---|
| 2017–2022 Model Years | ||
|
||
| No. | Description | Rating (A) |
| 1 | Right door switch pack | 25 |
| 3 | Electronic Parking Brake (EPB) | 30 |
| 6 | Convertible soft top mechanism | 15 |
| 8 | Left door switch pack | 25 |
| 9 | Convertible soft top mechanism | 15 |
| 11 | Rearview camera | 10 |
| Electrochromic interior rearview mirror | ||
| Blind Spot Monitoring (BSM) | ||
| 14 | Electronic Toll Collection (ETC) module | 2 |
| 15 | Power tailgate / trunk lid | 25 |
| 16 | Electronic Parking Brake (EPB) | 30 |
| 18 | Fuel pump fuse (Jaguar F-Type) | 30 |
| 19 | Windshield washer pump | 15 |
| 20 | Audio/Video control panel | 10 |
| 21 | Instrument cluster module | 10 |
| 22 | Body Control Module (BCM) | 5 |
| 28 | Infotainment system | 15 |
| 29 | Instrument panel switch pack | 5 |
| 2013–2017 Model Years | ||
|
||
| No. | Description | Rating (A) |
| 1 | Data Link Connector (OBD-II port) | 5 |
| 2 | Windshield washer pump | 20 |
| 3 | Unused | - |
| 4 | Starter motor monitor relay | 5 |
| 5 | Engine management system (ignition coils) | 25 |
| 6 | Mass Air Flow (MAF) sensors | 5 |
| 7 | Engine management sensors | 5 |
| 8 | Engine management actuators | 10 |
| 9 | Electronic throttle body motor | 10 |
| 10 | Variable Valve Timing (VVT) solenoids | 15 |
| 11 | Left-side oxygen sensor (O2S) | 20 |
| 12 | Right-side oxygen sensor (O2S) | 20 |
| 13 | Post-catalyst oxygen sensors | 20 |
| 14 | Auxiliary electric coolant pump | 10 |
| 15 | Active exhaust valve control unit | 5 |
| 16 | Unused | - |
| 17 | Engine Control Module (ECM) | 5 |
| 18 | Anti-lock Braking System (ABS) control valves | 30 |
| 19 | Transmission Control Module (TCM), electronic shift selector | 15 |
| 20 | All-Wheel Drive (AWD) module | 30 |
Engine Compartment Fuse Boxes
- Left-side fuse box (#1): Remove the left under-hood trim cover, then press the retaining clip to release the protective cover.
- Right-side fuse box (#2): Open the side access cover and press the two retaining tabs to remove the fuse box lid.
Fuse Box #1
Located on the left side of the engine bay.
| Diagram | ||
|---|---|---|
|
||
| 2017–2022 Model Years | ||
| No. | Description | Rating (A) |
| 1 | Data Link Connector (OBD-II port) | 5 |
| 4 | 2017–2018: Starter motor relay | 5 |
| 2019–2022: Starter motor monitor module | ||
| 5 | Engine Management System (EMS) | 25 |
| 6 | 5 | |
| 7 | 5 | |
| 8 | 10 | |
| 10 | 10 | |
| 11 | 20 | |
| 12 | 20 | |
| 13 | 20 | |
| 14 | Auxiliary electric coolant pump | 10 |
| 15 | Active exhaust system control unit | 5 |
| 16 | Left LED headlamp assembly | 20 |
| 17 | Right LED headlamp assembly | 20 |
| 18 | Anti-lock Braking System (ABS) module | 25 |
| 19 | Electronic gear selector control module | 15 |
| Transmission Control Module (TCM) | ||
| 20 | All-Wheel Drive (AWD) control module | 30 |
| 2013–2017 Model Years | ||
| No. | Description | Rating (A) |
| 1 | Data Link Connector (OBD-II port) | 5 |
| 2 | Windshield washer pump | 20 |
| 3 | Unused | - |
| 4 | Starter motor monitor module | 5 |
| 5 | Engine management system (ignition coils) | 25 |
| 6 | Mass Air Flow (MAF) sensors | 5 |
| 7 | Engine management sensors | 5 |
| 8 | Engine management actuators | 10 |
| 9 | Electronic throttle body motor | 10 |
| 10 | Variable Valve Timing (VVT) solenoids | 15 |
| 11 | Left-side oxygen sensor (O2S) | 20 |
| 12 | Right-side oxygen sensor (O2S) | 20 |
| 13 | Post-catalyst oxygen sensors | 20 |
| 14 | Auxiliary electric coolant pump | 10 |
| 15 | Active exhaust valve control unit | 5 |
| 16 | Unused | - |
| 17 | Engine Control Module (ECM) | 5 |
| 18 | Anti-lock Braking System (ABS) valves | 30 |
| 19 | Electronic gear shift module, Transmission Control Module (TCM) | 15 |
| 20 | All-Wheel Drive (AWD) control module | 30 |
Fuse Box #2
Located on the right side of the engine bay.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Rating (A) |
| 1 | Headlamp high-pressure washer pump | 25 |
| 3 | Dual horn assembly | 15 |
| 2, 4-10 |
Unused | - |
Passenger Compartment Fuse Boxes
- Fuse Box #1 (2013–2017 models only) is located in the front passenger footwell: Fold back the carpet panel to reveal the access cover, then pull upward to remove it.
- Fuse Box #2 is located at the base of the left A-pillar: Unclip the lower kick panel trim to gain access.
Fuse Box #1 (2013–2017 models only)
General view of the interior passenger footwell fuse box.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Rating (A) |
| 1 | Radio Frequency (RF) receiver, interior intrusion sensor, Tire Pressure Monitoring System (TPMS) receiver | 5 |
| 2 | Unused | - |
| 3 | Unused | - |
| 4 | CAN gateway control module | 5 |
| 5 | Anti-lock Braking System (ABS), Steering Angle Sensor (SAS) | 5 |
| 6 | Unused | - |
| 7 | Unused | - |
| 8 | Right power seat module (feed 2) | 30 |
| 9 | Electronic Parking Brake (EPB) control switch | 5 |
| 10 | Adaptive Damping System (ADS) control module | 5 |
| 11 | Unused | - |
| 12 | Reverse lamps and electrochromic mirror dimming interlock | 5 |
| 13 | Unused | - |
| 14 | Brake pedal position switch | 5 |
| 15 | Heated rear screen grid (defroster) | 30 |
| 16 | Unused | - |
| 17 | Unused | - |
| 18 | Unused | - |
| 19 | Powertrain Control Module (PCM), Engine Control Module (ECM) feed | 5 |
| 20 | Heated steering wheel control module | 10 |
| 21 | Passenger Airbag Deactivation (PAD) indicator (overhead console) | 10 |
| 22 | Transmission Control Module (TCM), electronic rear differential control, electronic gear selector (ignition feed) | 5 |
| 23 | Fuse box noise suppression circuit | 5 |
| 24 | Right rear fog lamp | 5 |
| 25 | Left rear fog lamp | 5 |
| 26 | Unused | - |
| 27 | Unused | - |
| 28 | Right door control module | 25 |
| 29 | Unused | - |
| 30 | Unused | - |
| 31 | Rain sensor, Automatic Climate Control (ACC) sensors | 5 |
| 32 | Left door control module | 25 |
| 33 | Unused | - |
| 34 | Central console storage compartment & glovebox solenoid locks | 10 |
| 35 | Unused | - |
| 36 | Unused | - |
| 37 | Unused | - |
| 38 | Windshield washer pump control | 15 |
| 39 | Unused | - |
| 40 | Unused | - |
| 41 | Unused | - |
| 42 | Left power seat module (feed 1) | 30 |
| 43 | Active exhaust control system | 10 |
| 44 | Unused | - |
| 45 | Right power seat module (feed 1) | 30 |
| 46 | Left power seat module (feed 2) | 30 |
| 47 | Unused | - |
| 48 | Unused | - |
| 49 | Unused | - |
| 50 | Unused | - |
| 51 | Steering wheel control switches | 5 |
| 52 | Center console auxiliary power socket | 20 |
| 53 | 12V auxiliary power socket / cigarette lighter (center console cubby box) | 20 |
| 54 | Unused | - |
| 55 | Unused | - |
| 56 | Restraints Control Module (RCM / Airbag control unit) | 10 |
| 57 | Glovebox illumination, interior map light assembly | 10 |
| 58 | Unused | - |
| 59 | Soft-close door cinch motors | 10 |
| 60 | Occupant Detection System (ODS) / Passenger seat weight sensor | 5 |
| 61 | Passive start immobilizer antenna unit | 5 |
| 62 | Unused | - |
| 63 | Unused | - |
| 64 | Unused | - |
| 65 | Unused | - |
| 66 | Unused | - |
| 67 | Unused | - |
| 68 | Unused | - |
| 69 | Unused | - |
Fuse Box #2
General view.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Rating (A) |
| 2017–2022 Model Years | ||
| 1 | Right power seat adjustment module | 20 |
| 2 | Unused | - |
| 3 | Unused | - |
| 4 | Automatic Climate Control (HVAC) module | 10 |
| 5 | Telematics control unit | 5 |
| 6 | Unused | - |
| 7 | Keyless entry and passive locking system | 5 |
| 8 | Body Control Module (BCM) logic feed | 5 |
| 9 | Tire Pressure Monitoring System (TPMS) module | 5 |
| Overhead console unit | ||
| 10 | Brake pedal position sensor switch | 5 |
| 11 | Climate seat / seat heating module | 25 |
| 12 | Power seat memory and movement module | 5 |
| 13 | Dynamic Stability Control (DSC) module | 10 |
| Center console control switchpack | ||
| 14 | Dynamic Stability Control (DSC) module logic | 10 |
| 15 | Unused | - |
| 16 | Engine immobilizer system module | 5 |
| 17 | Alarm battery-backed sounder / siren | 5 |
| 18 | Unused | - |
| 19 | Electrically adjustable steering column module | 5 |
| 20 | Climate control system (HVAC) module | 15 |
| Body Control Module (BCM) | ||
| 21 | Unused | - |
| 22 | Spare circuit | 5 |
| 23 | Spare circuit | 5 |
| 24 | Automatic headlamp leveling system | 5 |
| 25 |
|
20 |
| 26 |
|
20 |
| 27 | Heated steering wheel element | 15 |
| 28 | Unused | - |
| 29 | Unused | - |
| 30 | Body Control Module (BCM) | 5 |
| Instrument panel switchpack | ||
| 2013–2017 Model Years | ||
| 1 | Electronic Parking Brake (EPB) actuator (left side) | 30 |
| 5 | Instrument cluster module, cluster cooling fan | 10 |
| 6 | Convertible top mechanism (front latch) | 15 |
| 8 | Keyless Vehicle Module (KVM) logic feed | 5 |
| 9 | Convertible top mechanism (hydraulic pump / rear latch) | 15 |
| 10 | Air Conditioning (A/C) compressor magnetic clutch | 10 |
| 11 | Heated front seats module | 25 |
| 12 | Power seat adjustment switch feed | 5 |
| 13 | Chassis Control Module (active rear spoiler), JaguarDrive Control selector panel | 10 |
| 15 | Power tailgate / trunk lid module | 25 |
| 16 | Electronic Parking Brake (EPB) actuator (right side) | 30 |
| 17 | Adaptive Damping System (ADS) module, Chassis Control Module | 10 |
| 18 | Unused | - |
| 19 | Fuel pump fuse (Jaguar F-Type) | 30 |
| 20 | Unused | - |
| 21 | Rearview camera, headlamps, Blind Spot Monitoring (BSM), Park Assist / Parking Distance Control (PDC), auto-dimming interior mirror | 10 |
| 22 | Right headlamp leveling actuator motor | 5 |
| 23 | Left headlamp leveling actuator motor | 5 |
| 24 | Headlamp automatic leveling module | 5 |
| 25 | Instrument cluster control module, cluster cooling fan | 10 |
| 26 | Central CAN gateway module | 5 |
| 27 | Unused | - |
| 28 | Unused | - |
| 29 | Rearview camera, headlamps, Blind Spot Monitoring (BSM), Park Assist / Parking Distance Control (PDC), interior mirror | 10 |
| 30 | Normal / Transport mode relay unit | 5 |
