Fuses Jeep Compass (MK49; 2006–2011)

This article provides comprehensive fuse box diagrams and circuit layouts for the first-generation Jeep Compass (chassis MK49; model years 2006, 2007, 2008, 2009, 2010, and 2011).

Fuses #11, #13, and #16 in the engine compartment fuse box supply power to the cigarette lighter and 12V auxiliary power outlets.

Engine Compartment Fuse Box

General view of the engine compartment fuse box (Integrated Power Module).

Location

Located in the engine compartment near the air cleaner assembly beneath a protective plastic cover.

Cover removal and access point.

Fuse Layout Diagram

Fuse block assignment and circuit ratings.

No.	Circuit Protected	Rating
9	Power Seats	40 A
15	Radiator Fan Relay Feed	40 A
18	Auto Shutdown (ASD) Relay Contact Feed	40 A
32	Engine Auto Shutdown (ASD) Control Module	30 A
34	Anti-Lock Brake System (ABS) Valves	30 A
35	Anti-Lock Brake System (ABS) Pump	40 A
36	Headlamp, Smart Glass, and Washer Control Module	30 A
1	Spare / Unused	-
2	AWD / 4WD Control Module (ECU)	15 A
3	Center High-Mounted Stop Lamp (CHMSL) / Brake Light Switch	10 A
4	Ignition Switch Feed	10 A
5	Trailer Tow Harness	20 A
6	Ignition Off Draw (IOD) Power Mirrors Occupant Classification Module (OCM), Steering Column Module, SDARS (Satellite Radio) Hands-Free Telephone Module (Uconnect)	10 A
7	Ignition Off Draw (IOD) Sense #1	30 A
8	Ignition Off Draw (IOD) Sense #2	30 A
10	Cabin Compartment Node (CCN) – Power Door Locks 2009–2011: Interior Lighting	20 A
11	Cigarette Lighter and 12V Auxiliary Power Outlet	15 A
12	Ignition RUN / ACC Power Inverter	20 A
13	Power RUN Feed, Rear 12V Power Outlet, Cigarette Lighter 2009–2011: Dome Lamp	20 A
14	2006–2008: Interior Lighting Ignition Off Draw (IOD) – Cabin Compartment Node (CCN)	10 A
16	2009–2011: IGN RUN, Dome Lamp, Sunroof, Rear Wiper, ACC Power Inverter 2006–2008: IGN RUN, Sunroof, Cigarette Lighter	15 A
17	Ignition Off Draw (IOD) Feed – Wireless Control Module (WCM)	10 A
19	Audio Power Amplifier 1 & 2	20 A
20	Radio / Head Unit	15 A
21	Hazard Flashers, IOD Feed – Intrusion Alarm Module	10 A
22	Compass Module, IGN RUN HVAC / Climate Control	10 A
23	Engine ASD Relay Feed 3	15 A
24	Power Sunroof / Moonroof	15 A
25	Heated Exterior Mirrors	10 A
26	Engine ASD Relay Feed 2	15 A
27	IGN RUN Occupant Restraint Controller (ORC) Feed	10 A
28	Occupant Classification Module (OCM) Feed, IGN RUN ORC	10 A
30	Heated Seats	20 A
31	Headlamp Washer Relay Control Module	10 A
33	J1962 Data Link Connector (OBD-II), ABS Module, Powertrain Control Module (PCM)	10 A
37	2006–2008: 110V AC Power Inverter 2009–2011: Diesel Fuel Heater	25 A
29	Unused / Constant Battery Feed (B+)	-
