The third-generation Lexus GS sedan became an independent model line, no longer sharing its platform with the Toyota Aristo as its two predecessors did. Corporate reorganization established Lexus as a fully standalone premium brand in design and sales. The new Lexus GS introduced the brand's signature L-finesse design language—characterized by smooth, flowing, dynamic, and powerful proportions—which defined the appearance of subsequent Lexus models. The sedan also features an aerodynamically optimized fastback profile. The quad-headlight front-end styling and distinctive rear door kink pay homage to the previous generation.
Electrical circuits in this vehicle are protected by a combination of fuses, fusible links, and relays. Components are housed in distribution blocks located in the engine compartment, passenger compartment, and luggage compartment. The following diagrams apply to 3rd-generation Lexus GS 300 (chassis codes GRS190 / UZS190 / URS190) models produced for model years 2005 through 2012 in Left-Hand Drive (LHD) and Right-Hand Drive (RHD) configurations, and are also applicable to GS 430 and GS 460 models.
Engine Compartment
Component Location:
1. Fuse Block No. 1,
2. Engine Control Module (ECM),
3. Headlight Washer Relay,
4. Cooling Fan ECU,
5. Injector Driver Unit (EDU),
6. Relay Box No. 1,
7. Fuse Block No. 2,
8. Electronic Power Steering (EPS) ECU,
9. Relay Box No. 2 (3UZ-FE),
10. Relay Box No. 2 (3GR-FSE, 3GR-FE),
11. Vehicle Stability Control (VSC) ECU (3GR-FSE, 3GR-FE),
12. Vehicle Stability Control (VSC) ECU (3UZ-FE).
Component Location (RHD).
Fuse Block No. 1 – Overview.
| Engine Compartment Fuse Block No. 1 Diagram | ||
|---|---|---|
|
||
| No. | Protected Component / Circuit | A |
| 1 | Cooling fan control system | 10 |
| 2 | Fuel system, exhaust system, multiport fuel injection system / sequential multiport fuel injection system, EVAP leak detection pump | 10 |
| 3 | Right headlight (Low beam) | 15 |
| 4 | Left headlight (Low beam) | 15 |
| 5 | Headlight cleaner | 30 |
| 6 | DC/DC converter | 30 |
| 7 | Air conditioning system | 7.5 |
| 8 | Windshield wiper de-icer | 25 |
| 9 | Front fog lights, clearance lights, windshield washer | 30 |
| 10 | Headlights (High beam), horn | 25 |
| 11 | Air-fuel ratio (A/F) sensor | 15 |
| 12 | Electronic Throttle Control System (ETCS) | 10 |
| 13 | Charging system | 7.5 |
| 14 | 1UR-FE (GS460) : Sequential Multiport Fuel Injection System | 25 |
| 15 | - | - |
| 16 | - | - |
| 17 | - | - |
| 18 | - | - |
| 19 | Headlights (High beam) | 15 |
| 20 | Horn | 10 |
| 21 | Windshield washer | 20 |
| 22 | Front clearance lights | 10 |
| 23 | Front fog lights | 15 |
| 24 | - | - |
| 25 | Fuel pump | 25 |
| 26 | 3UZ-FE (GS430), 1UR-FE (GS460): Multiport fuel injection system / sequential multiport fuel injection system | 20 |
| 3GR-FSE, 3GR-FE (GS300): Multiport fuel injection system / sequential multiport fuel injection system | 25 | |
| 27 | Multiport fuel injection system / sequential multiport fuel injection system | 20 |
| Relays | ||
| R1 | (A/C COMP) Air conditioning compressor clutch | |
| R2 | (IG2) Ignition system | |
| R3 | (A/F) Air-fuel ratio sensor | |
| R4 | - | |
| R5 | - | |
| R6 | (ST CUT) Starter cut | |
| R7 | (F/PMP) Fuel pump | |
| R8 | - | |
| R9 | - | |
| R10 | - | |
| Engine Compartment Fuse Block No. 2 Diagram | ||
|---|---|---|
Overview. |
||
Diagram. |
||
| No. | Protected Component / Circuit | A |
| 1 | Variable Gear Ratio Steering (VGRS), Electric Power Steering (EPS), driver's seat ECU, Lexus Link system | 10 |
| 2 | Electronically Controlled Brake (ECB) system | 10 |
| 3 | Hazard warning lights, turn signal lights | 15 |
| 4 | Fuses: “IG2”, “GAUGE”, “IGN” | 20 |
| 5 | Audio system | 30 |
| 6 | Fuses: “DOME”, “MPX-B” | 20 |
| 7 | Audio system | 30 |
| 8 | Multiplex communication system, body ECU, door control system (power door locks, power windows, power mirrors, mirror heaters), power seats, steering angle sensor, power tilt and telescopic steering column, headlight switch, combination meter | 10 |
| 9 | Interior lights, footwell lights, vanity mirror lights, combination meter, shift lever position indicator light, overhead spotlight | 10 |
| 10 | Noise filter | 10 |
| 11 | Electronically Controlled Brake (ECB) system | 10 |
| 12 | Anti-lock Brake System (ABS) | 30 |
| 13 | Anti-lock Brake System (ABS), noise filter condenser | 10 |
| 14 | - | - |
| 15 | Fuses: “FR CTRL BATT”, “ETCS”, “ALT-S” | 60 |
| 16 | - | - |
| 17 | Vehicle Stability Control (VSC); Fuses: “ABS MAIN1”, “ABS MAIN2”, “ABS MTR” | 50 |
| 18 | Fuses: “AM2”, “DOOR FR”, “DOOR RR” | 30 |
| 19 | Variable Gear Ratio Steering (VGRS) | 40 |
| 20 | Fuses: “H-LP R LWR”, “H-LP L LWR” | 30 |
| 21 | Starting system | 30 |
| 22 | Fuses: “FL DOOR”, “RL DOOR”, “RAD NO.3” | 30 |
| 23 | Multiport fuel injection system / sequential multiport fuel injection system | 60 |
| 24 | Electric Power Steering (EPS) | 80 |
| 25 | - | - |
| 26 | Fuses: “RH J/B-AM”, “LH J/B-AM”, “E/G-AM”, “RR JB”, “HEATER”, “DEFOG”, “FAN1”, “FAN2”, “ABS2”, “ABS MOTOR”, “ABS MAIN1”, “ABS MAIN2” | 150 |
| 27 | Fuses: “STOP LP R”, “STOP LP L”, “RR-B”, “RR TAIL”, “RR FOG”, “RR-IG1”, “PSB”, “RR S/SHADE” | 80 |
| 28 | Glow plug system (diesel variants) | 50 |
| 29 | Fuses: “AM1”, “OBD”, “STOP SW”, “TI&TE”, “PWR OUTLET”, “FR P/SEAT RH”, “STR LOCK”, “ECU-IG RH”, “RH-IG”, “ACC”, “CIG”, “SECURITY”, “FR S/HTR RH”, “AIR SUS” | 80 |
| 30 | Vehicle Stability Control (VSC), Anti-lock Brake System (ABS) | 30 |
| 31 | Rear window defogger, noise filter | 50 |
| 32 | Electric cooling fans | 40 |
| 33 | 40 | |
| 34 | Heater system | 50 |
| 35 | Glow plug system (diesel variants) | 50 |
| 36 | Fuses: “H-LMP CLN”, “FR CTRL-AM”, “A/C COMP” | 60 |
| 37 | Fuses: “S/ROOF”, “FR P/SEAT LH”, “TV”, “FR S/HTR LH”, “FR WIP”, “H-LP LVL”, “LH-IG”, “FUEL OPEN”, “A/C”, “PANEL”, “LH-B” | 80 |
| 38 | Electric cooling fans | 60 |
| Relays | ||
| R1 | Starter relay | |
| R2 | (FAN MAIN) Cooling fan main relay | |
| R3 | (HEAD LP) Headlight main relay | |
| R4 | (EPS) Electric power steering relay | |
| R5 | (DEFOG) Rear window defogger relay | |
| Relay Box No. 1 Diagram | |
|---|---|
|
|
| No. | Protected Circuit / Component |
| R1 | Unused |
| R2 | |
| R3 | (GLW RLY1) PTC heater No. 1 |
| R4 | (GLW RLY2) PTC heater No. 2 |
| Relay Box No. 2 Diagram | |
|---|---|
|
|
| No. | Protected Circuit / Component |
| R1 |
|
| R2 | 3UZ-FE: ABS MAIN2 |
| R3 | 3UZ-FE: ABS MOTOR1 |
| R4 | ABS MOTOR1 |
Passenger Compartment
Component Location: 1. Main Body ECU (LHD), 2. Passenger Compartment Fuse Block (LHD), 3. Distance Control ECU, 4. Turn Signal & Hazard Flasher Relay, 5. Tire Pressure Warning ECU, 6. Transponder Key ECU / Immobilizer, 7. Junction Block No. 1, 8. Junction Block No. 2, 9. Parking Assist Camera ECU, 10. Intuitive Parking Assist ECU, 11. Power Source Control ECU, 12. Gateway ECU, 13. Main Body ECU (RHD), 14. Passenger Compartment Fuse Block (RHD), 15. Active Stabilizer Suspension ECU, 16. Junction Connector, 17. Power Steering ECU, 18. Airbag Sensor Assembly / ECU, 19. Shift Lock Control ECU, 20. A/C Amplifier, 21. Steering Lock ECU, 22. Tilt & Telescopic Steering Column ECU, 23. Outer Mirror ECU, 24. Junction Connector, 25. Headlight Leveling ECU.
Component Location (LHD).
| Passenger Compartment Fuse Block Allocation – LHD | ||
|---|---|---|
|
||
| No. | Protected Component / Circuit | A |
| 1 | Power seat (Front L) | 30 |
| 2 | Air conditioning system | 7.5 |
| 3 | - | - |
| 4 | Audio system, air conditioning system, rear-view camera | 7.5 |
| 5 | - | - |
| 6 | Trunk lid opener / lock actuator | 10 |
| 7 | Theft deterrent system | 10 |
| 8 | - | - |
| 9 | Electric moonroof | 25 |
| 10 | - | - |
| 11 | - | - |
| 12 | Illumination (steering wheel switches, audio system, glove box, shift lever indicator, center console box, cigarette lighter, AVS switch, A/C controls, VSC OFF switch, seat heater/cooler switches) | 7.5 |
| 13 | Fuel filler door opener, trunk lid opener | 10 |
| 14 | VSC, ECB, cruise control, radar cruise control, deceleration sensor, yaw rate sensor, EPS, VGRS, rear-view camera, AWD system, moonroof, rain sensor, multiplex network control module | 10 |
| 15 | - | - |
| 16 | Seat heater/cooler (Front L) | 15 |
| 17 | Rear door ECU LH (power locks, courtesy lights, power window) | 20 |
| 18 | Front door ECU LH (power locks, power mirrors, door courtesy lights, mirror heaters, power window) | 20 |
| 19 | Audio system | 10 |
| 20 | - | - |
| 21 | Adaptive Front-lighting System (AFS), automatic headlight leveling | 7.5 |
| 22 | Charging system, headlight cleaner, rear window defogger, oxygen sensor, cooling fans, rear door ECU LH, front door ECU LH, hazard/turn signal flasher, automatic transmission, seat belt pretensioners, intuitive parking assist | 10 |
| 23 | - | - |
| 24 | Windshield wipers and washer | 30 |
| Passenger Compartment Fuse Block Allocation – RHD | ||
|---|---|---|
|
||
| No. | Protected Component / Circuit | A |
| 1 | Power seat (Front R) | 30 |
| 2 | - | - |
| 3 | Data Link Connector 3 (DLC3 / OBD-II) | 7.5 |
| 4 | Stop lights, multiport fuel injection system / sequential multiport fuel injection system, starting system, ECB, VSC, shift lock system | 7.5 |
| 5 | 7.5 | |
| 6 | Power tilt and telescopic steering column, multiplex communication system | 20 |
| 7 | - | - |
| 8 | Smart Access system with push-button start | 7.5 |
| 9 | Electric steering lock | 25 |
| 10 | Combination meter | 7.5 |
| 11 | Multiport fuel injection system / sequential multiport fuel injection system, SRS airbag system, stop/tail lights, electric steering lock, ECB, Lexus Link system, occupant detection system | 10 |
| 12 | Multiplex communication system, Smart Access system with push-button start, rear-view camera, audio system, air conditioning system, Lexus Link system | 7.5 |
| 13 | - | - |
| 14 | Cigarette lighter | 15 |
| 15 | Auxiliary power outlet | 15 |
| 16 | Electronically Modulated Air Suspension (AVS) | 20 |
| 17 | Rear door ECU RH (power locks, courtesy lights, power window) | 20 |
| 18 | Front door ECU RH (power locks, power mirrors, door courtesy lights, mirror heaters, power window), multiplex communication system | 20 |
| 19 | Starting system | 15 |
| 20 | Seat heaters, rear door ECU RH, front door ECU RH, seat belt pretensioners, intuitive parking assist, noise filter, headlight switch | 7.5 |
| 21 | Seat heater/cooler (Front R) | 15 |
| 22 | Power tilt and telescopic steering column, multiplex communication system, Smart Access system, audio system, air conditioning system, shift lock system, tire pressure warning system, headlight switch, active front stabilizer, active rear stabilizer, DC/DC converter | 10 |
| 23 | - | - |
| 24 | - | - |
Luggage Compartment & Body Components
Component Location: 1. Moonroof Control ECU, 2. Luggage Compartment Junction Block, 3. Front Door ECU RH, 4. Rear Door ECU RH, 5. Automatic Light Control Sensor, 6. Smart Key ECU, 7. Door Control Receiver (Wireless Remote Entry), 8. Stereo Component Amplifier, 9. Power Rear Sunshade Relay, 10. Pre-Collision Seat Belt ECU, 11. Luggage Compartment Fuse Block, 12. Rear Door ECU LH, 13. Front Door ECU LH.
| Luggage Compartment Fuse Block Diagram (#11) | ||
|---|---|---|
|
||
| No. | Protected Component / Circuit | A |
| 1 | Tail lights, license plate lights | 10 |
| 2 | High-mounted stop light | 10 |
| 3 | Stop lights, back-up lights | 7.5 |
| 10 | ||
| 4 | Rear fog lights | 10 |
| 5 | Luggage compartment light | 10 |
| 6 | Pre-collision seat belts, seat belt pretensioners, Air Suspension ECU, power rear sunshade | 10 |
| 7 | 10 | |
| 8 | - | - |
| 9 | Pre-collision seat belts | 30 |
| 10 | Power rear sunshade | 7.5 |
| 11 | - | - |
| Fuse Block No. 2 (Vehicles with Active Stabilizer Suspension System) | ||
|
||
| 1 | Active front stabilizer | 50 |
| 2 | Active rear stabilizer | 30 |
| 3 | DC/DC converter | 30 |
