This article provides detailed fuse box diagrams and relay assignments for the Lincoln MKT (First generation (facelift); Ford D4 platform). Model years 2013, 2014, 2015, 2016, 2017, 2018, and 2019.
Fuses 9, 17, 20, 21, and 27 in the engine compartment fuse box power the cigarette lighter and auxiliary power outlets.
Engine Compartment Fuse Box
Located on the left side of the engine compartment, under the cover.
General view.
| Diagram | |
|---|---|
|
|
| No. | Description |
| 10 | 3rd-row power seats relay |
| 11 | Heated rear window relay |
| 12 | Trailer tow battery charge relay |
| 13 | Starter relay |
| 14 | Cooling fan #2 relay |
| 15 | Fuel pump relay |
| 25 | Not used |
| 32 | Auxiliary blower relay |
| 33 | Cooling fan #1 relay |
| 34 | Front blower relay |
| 35 | Cooling fan (series) relay |
| 36 | Not used |
| 37 | Trailer tow right-hand stop/turn lamp relay |
| 38 | Trailer tow backup lamp relay |
| 44 | Windshield washer relay |
| 52 | Not used |
| 53 | Trailer tow left-hand stop/turn lamp relay |
| 54 | Not used |
| 55 | Windshield wiper relay |
| 66 | Powertrain Control Module (PCM) relay - vehicle power |
| 77 | Trailer tow park lamp relay |
| 88 | Run/Start relay |
| 98 | A/C clutch relay |
| 1 | Cooling fan relay 2 (40 A) |
| 2 | Cooling fan relay 1 (40 A) |
| 3 | Trailer brake control module (30 A) |
| 4 | Windshield washer pump and wipers (30 A) |
| 5 | ABS pump (50 A) |
| 6 | Limousine/Livery: B+ #1 access circuit (50 A) |
| 7 | Power liftgate (30 A) |
| 8 | Moonroof (20 A) |
| 9 | 2nd-row console 12V power outlet (20 A) |
| 16 | Limousine/Livery: B+ #2 access circuit (40 A) |
| 17 | 110V AC power outlet (30 A) |
| 18 | Front blower motor (40 A) |
| 19 | Starter solenoid (30 A) |
| 20 | Console bin power outlet (20 A) |
| 21 | Instrument panel 12V power outlet / Cigarette lighter (20 A) |
| 22 | 3rd-row power seat module (30 A) |
| 23 | Memory seat module (30 A) |
| 24 | Non-Limousine/Livery: Trailer tow battery charge (30 A) |
| Limousine: Vacuum pump relay (40 A) | |
| 26 | Heated exterior mirrors, Rear window defroster (40 A) |
| 27 | Cargo area power outlet (20 A) |
| 28 | Climate-controlled seats - Front (30 A) |
| 29 | Climate-controlled seats - Rear (30 A) |
| 30 | Rear heated seats (20 A) |
| 31 | Cooling fan relay 3 (25 A) |
| 39 | Auxiliary blower motor (30 A) |
| 40 | Driver front power window (30 A) |
| 41 | Driver rear power window (30 A) |
| 42 | Front passenger power seat (30 A) |
| 43 | ABS module valves (20 A) |
| 45 | Rain sensor (5 A) |
| 46 | EcoBoost: EVAP canister vent solenoid (5 A) |
| 47 | Windshield washer pump (15 A) |
| 48 | Front park lamps (10 A) |
| 49 | Not used |
| 50 | Heated exterior mirrors (10 A) |
| 51 | 3.7L engine: PCM, injector power monitor (5 A) |
| 56 | Fuel pump, Fuel injectors (30 A) |
| 57 | Left HID headlamp (20 A) |
| 58 | Alternator sensor (10 A) |
| 59 | Brake pedal position (BPP) switch (10 A) |
| 60 | Trailer tow backup lamps (10 A) |
| 61 | Limousine/Livery: B+ #6 access circuit (20 A) |
| 62 | A/C clutch (10 A) |
| 63 | Trailer tow stop/turn lamps (15 A) |
| 64 | Rear wiper motor (15 A) |
| 65 | Limousine/Livery: B+ #7 access circuit (20 A) |
| 67 | Vehicle power #2 - Mass airflow sensor (MAF), Heated oxygen sensor (HO2S) heaters, EVAP canister vent solenoid, Variable camshaft timing (VCT) solenoid, EVAP canister purge solenoid (20 A) |
| 68 | Vehicle power #4 - Ignition coils (20 A) |
| 69 | Vehicle power #1 - PCM (20 A) |
| 70 | Vehicle power #3 (coils) - Cooling fan control relays, A/C clutch relay, Auxiliary transmission warm-up, Variable displacement A/C compressor, Turbocharger electronic compressor bypass valve, Turbocharger wastegate control, All-wheel drive (AWD) module, Positive crankcase ventilation (PCV) heater (15 A) |
| 71 | Not used |
| 72 | Limousine/Livery Run/Accessory (5 A) |
| 73 | Limousine/Livery battery saver (5 A) |
| 74 | Not used |
| 75 | Not used |
| 76 | Not used |
| 78 | Right HID headlamp (20 A) |
| 79 | Adaptive Cruise Control (ACC) module (10 A) |
| 80 | Limousine/Livery: B+ #3 access circuit (30 A) |
| 81 | Limousine/Livery: B+ #4 access circuit (15 A) |
| 82 | Rear window washer pump (15 A) |
| 83 | Not used |
| 84 | Trailer tow park lamps (20 A) |
| 85 | Limousine/Livery: B+ #5 access circuit (15 A) |
| 86 | Powertrain Control Module (PCM) relay, PCM keep-alive power, EVAP canister vent solenoid (3.7L engine) (5 A) |
| 87 | Run/Start feed (5 A) |
| 89 | ABS module, Adaptive headlamp module (10 A) |
| 90 | PCM run/start feed (10 A) |
| 91 | Adaptive Cruise Control (ACC) module (10 A) |
| 92 | Electronic Power Steering (EPAS) module / Front blower relay coil (5 A) |
| 93 | Rear window defroster, Auxiliary blower, Battery charge / vacuum pump relay coils (5 A) |
| 94 | Body Control Module (BCM) run/start feed (30 A) |
| 95 | Not used |
| 96 | Not used |
| 97 | Not used |
Passenger Compartment Fuse Box
Located under the instrument panel to the left of the steering column.
General view of the fuse box.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Amps |
| 1 | Right rear power window | 30 A |
| 2 | 2nd-row power seats / Memory seat module | 15 A |
| 3 | Right front power window | 30 A |
| 4 | Limousine battery saver / Battery saver relay (interior demand lamps and power seats) | 10 A |
| 5 |
|
20 A |
| 6 | Rear seat entertainment module (Livery only), Rear climate control module, USB charging port | 5 A |
| 7 | Driver seat module, Driver door module, Keyless entry keypad | 7.5 A |
| 8 | Power liftgate module | 10 A |
| 9 | Electronic finish panel (EFP), SYNC® module, GPS module | 10 A |
| 10 | Front wiper motor relay, Run/accessory relay, Limousine run/accessory relay | 10 A |
| 11 | Head-Up Display (HUD) / Intelligent Access (IA) module | 10 A |
| 12 | Puddle lamps, Interior illumination, Switch backlighting | 15 A |
| 13 | Right rear stop/turn lamp, Right turn signal, Right exterior mirror turn signal | 15 A |
| 14 | Left rear stop/turn lamp, Left turn signal, Left exterior mirror turn signal | 15 A |
| 15 | Center high-mounted stop lamp (CHMSL), Back-up lamps | 15 A |
| 16 | Right low-beam headlamp | 10 A |
| 17 | Left low-beam headlamp | 10 A |
| 18 | 3rd-row power seats, Keypad illumination, Push-button start run indicator, Powertrain Control Module (PCM) wake-up, Brake-shift interlock | 10 A |
| 19 | Subwoofer amplifier / Smart amplifier | 20 A |
| 20 | Not used | 20 A |
| 21 | 2017–2019: Extended Power Module | 10 A |
| 22 | Horn relay | 20 A |
| 23 | Instrument cluster, Steering wheel control module | 15 A |
| 24 | Data Link Connector (DLC / OBD-II), Steering wheel control module | 15 A |
| 25 | Not used | 15 A |
| 26 | Push-button start switch | 5 A |
| 27 | Intelligent Access (IA) module | 20 A |
| 28 | Not used | 15 A |
| 29 | Radio, Global Positioning System (GPS) module (2013–2016) | 20 A |
| 30 | Trailer tow park lamp relay, Front park lamps, Front side marker lamps | 15 A |
| 31 | Trailer brake controller module | 5 A |
| 32 | Power window switches and motors, Power door lock switches, Moonroof, 110V AC power inverter, Driver door/mirror switch, Rear seat switch (Livery) | 15 A |
| 33 | Suspension control module | 10 A |
| 34 | Rear heated seat module, Blind Spot Information System (BLIS®), Rearview camera, Reverse sensing system, Auto high-beam / Lane departure warning / Lane keeping system module, Auto-dimming interior mirror | 10 A |
| 35 | Climate control humidity sensor, Head-Up Display (HUD), Overdrive cancel switch (Limousine/Livery) | 5 A |
| 36 | Heated steering wheel module | 10 A |
| 37 | Rear console refrigerator | 10 A |
| 38 | Not used | 10 A |
| 39 | High-beam headlamps | 15 A |
| 40 | License plate lamps, Rear park lamps, Rear light bar appliqué | 10 A |
| 41 | 2013–2016: Restraints Control Module (RCM) / Occupant Classification System (OCS) | 7.5 A |
| 2017–2019: Extended Power Module | ||
| 42 | Not used | 5 A |
| 43 | Not used | 10 A |
| 44 | Not used | 10 A |
| 45 | Not used | 5 A |
| 46 | Climate control module | 10 A |
| 47 | Front fog lamps, Fog lamp indicator | 15 A |
| 48 | Circuit Breaker: Not used | 30 A |
| 49 | Delayed accessory relay, BCM relay | |
