The CLA-Class Coupé debuted in January 2013. Visually, it resembles a scaled-down CLS, a similarity most noticeable in the rear bodywork and door profile. However, from the front, the styling of the two models diverges significantly. Their underlying platforms also differ: the larger CLS is based on the E-Class, whereas the compact CLA shares its platform with the A-Class hatchback. In this article, we take a detailed look at the fuse box diagrams for the Mercedes-Benz CLA-Class C117 / X117 (1st Generation: CLA180, CLA200, CLA220, CLA250, CLA45 AMG) covering model years 2013 through 2020.
Below you will find fuse box locations, photos, and assignment diagrams. Fuses for the “Cigarette Lighter” and “Fuel Pump” are highlighted in bold.
In the Engine Compartment
The fuse box is located on the right (passenger) side of the engine compartment.
To access the fuses, release the two retaining latches and remove the protective cover.
| Diagram | ||
|---|---|---|
|
||
| No. | A | Description |
| J | - | Horn relay |
| K | - | Wiper speed 1/2 relay |
| L | - | Wiper ON/OFF relay |
| M | - | Starter relay |
| N | - | Circuit 87M relay |
| O | - | ECO start/stop transmission coolant circulation pump relay |
| P | - | Auxiliary relay (F58kP) |
| Q | - | Circuit 15 relay (non-latching) |
| R | - | Circuit 15 relay |
| S | - | Circuit 87 relay |
| T | - | Heated windshield relay |
| 201 | 5 | Alarm siren |
| 202 | 20 | Auxiliary / stationary heater module |
| 203 | 15 | LED headlight: Right front lamp unit |
| 204 | 25 | Electronic Stability Program (ESP) control unit |
| 205 | 15 | Left horn |
| Right horn | ||
| 206 | 5 | Engine 651: CDI control unit |
| Engine 607: Transmission control unit | ||
| 207 | 5 | Diesel engines: Circuit 87M relay |
| 208 | 7.5 | Engine 133, 607: Circuit 87 relay |
| 209 | 15 | LED headlight: Left front lamp unit |
| 210 | 5 | Heated windshield relay |
| 211 | - | Not assigned |
| 212 | 15 | Engine 133, 270: Connecting hose heater, circuit 87M3 |
| Engine 651: Coolant lines bleed heater / EGR heater thermostat | ||
| Engine 607 (Euro 5 emissions): Oxygen sensor upstream of catalytic converter | ||
| Engine 607 (Euro 6 emissions): Oxygen sensor upstream of catalytic converter | ||
| Engine 607: CDI control unit | ||
| 213 | 15 | Engine 133, 270, 651: Connector sleeve, circuit 87M2e |
| Engine 607 (Euro 5 emissions): CDI control unit / Hall sensor | ||
| 214 | 10 | Engine 133, 270, 651: Connector sleeve, circuit 87M4e |
| 215 | 20 | Gasoline engines: Ignition coils |
| Engine 651: Quantity control valve | ||
| Engine 607: CDI control unit / Charge pressure actuator | ||
| 216 | 5 | Gasoline engines: ME-SFI control unit |
| Engine 607: Transmission control unit | ||
| 217 | 25 | Transmission 724: Dual-clutch transmission fully integrated control unit |
| 218 | 5 | Electronic Stability Program (ESP) control unit |
| 219 | - | Not assigned |
| 220 | 10 | Transmission coolant circulation pump |
| 221 | - | Not assigned |
| 222 | - | Not assigned |
| 223 | - | Not assigned |
| 224 | 7.5 | DISTRONIC control unit |
| COLLISION PREVENTION ASSIST control unit | ||
| 225 | - | Not assigned |
| 226 | - | Not assigned |
| 227 | - | Not assigned |
| 228 | - | Not assigned |
| 229 | 5 | Left front headlight |
| 230 | 5 | Stability control system module |
| 231 | 5 | Right front headlight |
| 232 | 15 | Headlights |
| 233 | - | Not assigned |
| 234 | 5 | Engine 607: Transmission control unit |
| 235 | 7.5 | Engine 607: Radiator fan motor / Radiator shutter actuator |
| 235 | 7.5 | Engine 133: Charge air cooler circulation pump |
| 236 | 40 | Signal Acquisition and Actuation Module (SAM) |
| 237 | 40 | Electronic Stability Program (ESP) control unit |
| 238 | 50 | Heated windshield |
| 239 | 30 | Wiper speed 1/2 relay |
| 240A | 25 | Starter circuit 50 relay |
| 240B | 25 | Circuit 15 relay (momentary) |
| 241 | 7.5 | Not assigned |
In the Passenger Compartment
Located in the front passenger footwell, under the dashboard.
To access the passenger compartment fuse box:
1. Remove the floor mat.
2. Push cover trim (1) in the direction of the arrow.
3. Squeeze catch (2) and pull cover (3) upward in the direction of the arrow until it reaches the stop.
4. Pull cover (3) forward to remove it.
General view of the Mercedes-Benz CLA (C117) interior fuse box.
| Diagram | ||
|---|---|---|
|
||
| No. | Relay | |
| A | Circuit 15 relay | |
| B | Rear window wiper relay | |
| C | Circuit 15R2 relay | |
| D | Heated rear window relay | |
| E | Circuit 15R1 relay | |
| F | Circuit 30g relay | |
| G | Not assigned | |
| No. | Description | A |
| 21 | Diesel engines: PTC auxiliary heater booster | 150 |
| 22 | Auxiliary battery relay for ECO start/stop | 200 |
| 23 | Front left door control module | 30 |
| 24 | Front right door control module | 30 |
| 25 | Signal Acquisition and Actuation Module (SAM) | 30 |
| 26 | ECO start/stop auxiliary battery connector | 10 |
| 27 | Engine compartment fuse and relay module | 30 |
| 28 | Acoustic vehicle alerting system (AVAS) control module | 5 |
| 29 | Up to Nov 2, 2014: Trailer socket | 15 |
| From Nov 3, 2014: Trailer recognition control module | ||
| 30 | Trailer recognition control module | 5 |
| 31 | 4MATIC: All-wheel drive control module | 5 |
| 32 | Steering column module control unit | 5 |
| 33 | Audio control panel / COMAND | 5 |
| 34 | Automatic Climate Control (AAC) module | 7.5 |
| 35 | Heated rear window | 40 |
| 36 | Driver seat control module | 7.5 |
| Driver seat lumbar support control module | ||
| 37 | Audio / COMAND display | 7.5 |
| 38 | Supplemental Restraint System (SRS) control module | 7.5 |
| 39 | Overhead control panel module | 10 |
| 40 | Engine 651 (Euro 6 emissions): Transmission control unit | 15 |
| 41 | Panoramic sliding sunroof control module | 30 |
| 42 | Radio (Audio 5 USB, Audio 20 CD, Audio 20 CD with CD changer) | 5 |
| COMAND | ||
| 42 | Radio (Radio 20, Audio 20 USB) | 25 |
| 43 | PARKTRONIC control unit | 5 |
| 44 | Left front reversible emergency tensioning retractor | 40 |
| 45 | Right front reversible emergency tensioning retractor | 40 |
| 46 | Front passenger seat control module | 7.5 |
| Front passenger seat lumbar support adjustment | ||
| 47 | Navigation module | 7.5 |
| 47 | Adaptive Damping System (ADS) | 25 |
| 48 | Not assigned | - |
| 49 | Drive Kit Plus control unit for iPhone® | 7.5 |
| 49 | COMAND cooling fan motor | 5 |
| 50 | Reversing camera flap control unit | 5 |
| 51 | Not assigned | - |
| 52 | Not assigned | - |
| 53 | Not assigned | - |
| 54 | Not assigned | - |
| 55 | Telematics services communication module | 5 |
| KEYLESS-GO system control unit | ||
| 56 | Steering column module control unit | 10 |
| 57 | Lane keeping assistance / Special-purpose vehicle multifunction control unit | 30 |
| 57 | Special-purpose vehicle multifunction control module | 7.5 |
| 58 | Reserve / Unassigned | 30 |
| 59 | Front passenger seat control module | 30 |
| 60 | Driver seat control module | 30 |
| 61 | Audio system amplifier | 40 |
| 62 | Transmission 711: Electric steering lock control unit | 20 |
| 63 | Fuel system (Fuel pump fuse) | 25 |
| 64 | Electronic Toll Collection (ETC) control unit | 1 |
| Dedicated Short-Range Communications (DSRC) control unit | ||
| 65 | Glove compartment lamp | 5 |
| 66 | Reserve / Unassigned | 15 |
| 67 | Not assigned | - |
| 68 | Not assigned | - |
| 69 | Not assigned | - |
| 70 | Rear center console 12V socket | 25 |
| 71 | Luggage compartment 12V socket | 25 |
| 72 | Mercedes-Benz CLA C117 front cigarette lighter fuse | 25 |
| Passenger compartment 12V socket | ||
| 73 | Electric parking brake control unit | 30 |
| 74 | 30 | |
| 75 | Trailer recognition system | 20 |
| 76 | 25 | |
| 77 | 25 | |
| 78 | Tailgate / trunk lid control unit | 40 |
| Reserve / Unassigned | ||
| 79 | Signal Acquisition and Actuation Module (SAM) | 40 |
| 80 | 40 | |
| 81 | Climate control blower regulator | 40 |
| 82 | Overhead control panel module | 10 |
| 83 | Electronic Ignition Switch (EIS) control unit | 7.5 |
| 86 | FM, AM, and CL antenna amplifier | 5 |
| From Jun 1, 2016: Antenna amplifier / cellular network compensator | ||
| 87 | Diagnostic connector (OBD-II) | 10 |
| 88 | Instrument cluster | 10 |
| 89 | Exterior light switch | 5 |
| 90 |
|
5 |
| 91 | Pedal switch | 5 |
| Footwell light switch | ||
| 92 | Fuel system control unit | 5 |
| 93 | Electric parking brake module | 5 |
| 94 | Supplemental Restraint System (SRS) control module | 7.5 |
| 95 | Front passenger seat occupancy detection and Automatic Child Seat Recognition (ACSR) | 7.5 |
| 96 | Rear wiper motor | 15 |
| 97 | Cellular phone electrical connector | 5 |
| 98 | Signal Acquisition and Actuation Module (SAM) | 5 |
| 99 | Tire Pressure Monitoring System (TPMS) control unit | 5 |
| 100 | Engine 133: DIRECT SELECT interface | 5 |
| 101 | 4MATIC: All-wheel drive control unit | 10 |
| 102 | Auxiliary heater radio remote control receiver | 5 |
| AMG models from Sep 1, 2015: Transmission mode switch / control unit | ||
| From Jun 1, 2016: Telephone and auxiliary heater antenna switch | ||
| 103 | Emergency call control unit | 5 |
| Telematics services communication module | ||
| HERMES control module | ||
| 104 | Multimedia interface module | 5 |
| 105 | Digital Audio Broadcasting (DAB) control unit | 5 |
| Satellite Digital Audio Radio system (SDAR) | ||
| 105 | Tuner module | 7.5 |
| 106 | Multifunction camera module | 5 |
| 107 | Digital TV tuner | 5 |
| 108 | Up to May 31, 2016: Rearview camera control unit | 5 |
| 108 | From Jun 1, 2016: Rearview camera control unit | 7.5 |
| 109 | Charger electrical connector | 20 |
| 110 | Radio unit | 30 |
