Nissan March refers to urban subcompact front-engined cars. This model is the Japanese brother - the twin of the European version of the Nissan Micra . Produced since 1982. Currently in production 7th generation. The first has a body marking K10, the second - K11, the third - K12, etc. In our material you can find a description of the Nissan March fuse blocks and relays for the 3 (k12) generation, produced in 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009 and 2010, as well as their schemes and description of the purpose of the elements.
General arrangement
Location of electonic modules
|
|
| № | Description |
| 1 | Air conditioning control unit - behind the heater control panel |
| 2 | Sunlight sensor (air conditioning system) |
| 3 | Intake air temperature sensor (air conditioner / heater) |
| 4 | Shock sensor (SRS) |
| 5 | Impact sensor, driver's side - under the seat |
| 6 | Crash sensor, passenger side - under the seat |
| 7 | Anti-theft control unit oh - if installed |
| 8 | Accumulator battery |
| 9 | Central locking relay - "keyless entry", if any |
| 10 | Diagnostic connector (DLC) |
| 11 | Coolant Heater Relay - Diesel |
| 12 | Fuse and relay box, engine compartment 1 |
| 13 | Fuse and relay box, engine compartment 2 |
| 14 | Fuse and relay box, engine compartment Z |
| 15 | Fuse and relay box, engine compartment 4 - diesel engine |
| 16 | Fuse and relay box dashboard |
| 17 | Additional fuse (Main250A) - battery |
| 18 | Heater fan motor resistor - in the heater fan motor |
| 19 | Sound signal - behind the grille |
| 21 | Immobilizer transponder - ignition lock |
| 24 | Multifunctional control unit 2 - functions: central locking, power windows, alarm, rear window defogger, immobilizer control unit, direction indicators, interior lamps, fog light, rear window cleaner, windshield washer cleaner |
| 25 | Navigation control unit - in the audio unit (if any) |
| 26 | Ambient temperature sensor |
| 27 | Start inhibit switch - at checkpoint |
| 28 | Power steering control unit |
| 29 | SRS electronic control unit |
| 30 | Electronic gearbox control unit |
| 31 | Trip computer |
In the passenger compartment
Fuse box located in the dashboard, behind the protective cover.
| Diagram | |
|---|---|
|
|
| № | Description |
| 1 | Relay accessories |
| 2 | Heater blower motor relay |
| F1 | (15A) Windshield wiper |
| F2 | (10A) Instrument cluster indicators |
| F3 | (10A) SRS system |
| F4 | (10A) Multifunction control module 1, diagnostic socket |
| F5 | (10A) Brake light switch (brake pedal position sensor), ABS, brake lights |
| F6 | (10A) Central locking, anti-theft system, air conditioning system |
| F7 | (10A) Multifunction control module 1 |
| F8 | (10A) Indicators in instrument cluster, diagnostic connector (DLC) |
| F9 | (15A) Heater air conditioner |
| F10 | (15A) Heater air conditioner |
| F11 | (15A) nissan march cigarette lighter fuse |
| F12 | (10A) Audio system, navigation system, anti-theft system, electric door mirrors, trip computer |
| F13 | (10A) Heated rear window |
| F14 | (10A) Daytime running lamps |
| F15 | (10A) Heated seats |
| F16 | (10A) Air conditioner |
| F17 | (10A) Anti-theft system, central locking, interior lamps |
The fuse number 11 at 15A is responsible for the cigarette lighter.
In the engine compartment
Primary fuse box
Block with relay behind the headlight.
| Diagram | |
|---|---|
|
|
| № | Description |
| F31 | Spare |
| F32 | Spare |
| F33 | (10A) RH headlamp - high beam, daytime running light system - if equipped |
| F34 | (10A) High beam - left headlamp, daytime lighting system - if equipped |
| F35 | (10A) Right tailgate |
| F36 | (10A) Rear left side marker |
| F37 | Spare |
| F38 | (20A) Windshield wiper |
| F39 | (15A) Low beam - left headlamp, daytime lighting system - if equipped |
| F40 | (15A) Dipped beam - right headlamp, daytime lighting system - if equipped, headlight range control |
| F41 | (10A) A / C relay |
| F42 | Spare |
| F43 | Spare |
| F44 | Spare |
| F45 | (15A) Heated rear window relay |
| F46 | (15A) Heated rear window relay |
| F47 | (15A) Fuel pump relay |
| F48 | (10A) Transmission control module (ECM) |
| F49 | (10A) Anti lock brake system (ABS) |
| F50 | (10A) Start inhibit switch |
| F51 | (20A) Throttle control module relay |
| F52 | (20A) Engine management |
| F53 | (10A) Heated oxygen sensors |
| F54 | (10A) Injectors |
| F55 | (20A) Fog lights |
| 1 | Heated rear window relay |
| 2 | Engine control relay |
| 3 | Headlamp low beam relay |
| 4 | Front fog lamp relay |
| 5 | Starter relay |
| 6 | Spare |
| 7 | Cooling Fan Motor Relay - High Speed |
| 8 | Cooling fan motor relay - low speed |
| 9 | Relay for main ignition circuits |
Additional fuse box
General view.
| diagram | |
|---|---|
|
|
| № | Legend |
| 1 | Horn relay |
| F21 | Spare |
| F22 | Spare |
| F23 | Spare |
| F24 | (15A) Audio system, navigation system |
| F25 | (10A) Horn |
| F26 | (10A) Generator |
| F27 | (10A) Daytime lighting system - if equipped |
| F28 | (10A) - |
| F29 | (40A) ABS control module |
| F30 | (40A) Cooling fan motor relay |
| F31 | (40A) Ignition switch |
| F32 | (40A) Coolant heater |
| F33 | (40A) Multifunction control module 1 |
| F34 | (30A) ABS electronic board |
| F35 | (30A) Headlight washer pump relay |
| F36 | (60A) ABS electronic control module |
Power fuse panel
- A - 250A Main fuse
- B - 80A ABS electronic board
- C - 80A Multifunctional control unit 1
- D - 60A Fuse / Relay Box - Engine Compartment 1 (F45-F46), (F51-F52), Main Ignition Circuit Relay
- E - 80A Fuse / Relay Box - Instrument Panel (F5-F8), (F14), (F17), Auxiliary Relay, Heater Blower Motor Relay
