Fuses and relays Renault Kangoo 2 (KW / ZE), 2007–2020

The second-generation Renault Kangoo was produced in 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, and 2020.

This guide provides fuse and relay box diagrams, component locations, and circuit assignment descriptions for the second-generation Kangoo (chassis codes KW, ZE; Renault C platform), including the cigarette lighter fuse location.

Engine Compartment

The main power distribution box (fuse box) is located on the left side of the engine compartment.

To access the fuses, remove the battery, unbolt the cover of the unit, and turn it over.

Diagram
No.	Circuit / Component Description	Rating (A)
1	Right parking light (172-226)	7.5
2	Left parking light (173-227), right tail light (172), center license plate light (1324), cigarette lighter (101), 1st-row 12V auxiliary power sockets (506), door lock and hazard warning switch (1391), headlight leveling switch (562), climate control panel (319-419), audio system (261), multifunction display	7.5
3	Right headlight (low beam) (226) Headlight leveling switch (562) Right headlight leveling motor (538)	10
4	Left headlight (low beam) (227), left headlight leveling motor (537)	10
5	Right and left front fog lights (176-177)	20
6	Left headlight (high beam) (227)	10
7	Right headlight (high beam) (226)	10
8	Anti-lock Braking System (ABS) ECU (118) or ESP ECU (1094)	25
9	Windshield wiper motor (212)	30
10	Switched ignition (+12V) supply to Electric Power Steering ECU (1232)	5
11	Not used	-
12	Automatic Transmission ECU (119)	20
13	Not used
14	Gasoline engine: Fuel injectors 1-2-3-4 (193-194-195-196), EVAP canister purge solenoid (371), downstream oxygen sensor (242), upstream oxygen sensor (887) Diesel engine: Fuel pressure regulator (1105), cylinder sensor solenoid valve (746)	15
15	Not used	-
16	Automatic Transmission ECU (119)	5
17	Auxiliary heater relay 1 (1067), auxiliary heater relay 2 (1068), diagnostic link connector (DLC) (225), airbag/pretensioner ECU (756), parking assist ECU (1222)	7.5
18	Switched ignition (+12V) supply for fuel-in-water sensor (414) Engine compartment relay box 2 (1683) Engine Control Unit (ECU) (120)	5
19	Switched ignition (+12V) supply for reverse light switch (155) or reverse light switch with top dead center (TDC) sensor (1109)	10
20	Engine Control Unit (ECU) (120)	20
21	Not used
22	A/C compressor electromagnetic clutch (171)	10
23	Heated rear window (200), exterior mirror defrosters (239-240)	30

High-current fusible links located on the battery cover/terminal.

Battery Fuse Block / Power Unit Assignment
F1	Alternator (103) Main power distribution supply (777)	175
F2	Starter motor (200A - gasoline, 500A - diesel)	200 500
F3	Engine management system	40
F4	Direct battery (+12V) feed to: Engine cooling fan motor (1014-188) Protection and Switching Unit (USM) (1337) - starter solenoid (163) Protection and Switching Unit (USM) (1337)	40
F5	Direct battery (+12V) feed to Electric Power Steering (EPS) (1232)	70
F6	Passenger compartment fuse box	40

Auxiliary Power Relay Panel Diagram
No.	Circuit / Component Description	Rating (A)
1	Coolant heater interface module	60
2	Diesel glow plug control unit (980) Coolant heater interface module	70
3	Engine compartment relay box 2 (1683) Fuel heater element	30
4	Power windows	40
5	Passenger compartment fuse box	70
6	ABS/ESP ECU (1094)	30
7	Auxiliary heater module 1	40
8	Passenger compartment fuse box	70
9	Auxiliary heater relay 2	70

Passenger Compartment

The fuse box is located at the bottom of the dashboard on the driver's side.

Panel layout overview.

Diagram
No.	Rating & Description
1	Not used
2	10A Cigarette lighter (101) or front 12V auxiliary power socket (506)
3	15A Audio system (261), multifunction display (653), power seat relay (1399), brake light relay (1524), auxiliary power relay 2 (1389)
4	10A 2nd-row 12V auxiliary power socket (1382)
5	5A Instrument cluster power supply (247)
6	30A Central locking system or interior door deadlocking system
7	20A Body Control Module (UCH) (645) (hazard warning lights and fog lights)
8	10A Heated exterior mirrors, driver and passenger sides (239-240)
9	10A Auxiliary power relay 2 (1389) and engine-running ignition feed relay (+) (1615)
10	15A Audio system (261), multifunction display (653), multiplex network interface module (CAN bus) (1714), video display (1127)
11	10A Air conditioning ECU (419), auxiliary power relay 1 (1155), interior courtesy lamps, luggage compartment lamp, brake light switch
12	5A Body Control Module (UCH) (645)
13	5A Front interior courtesy lamp (213), center ceiling lamp (529), rain and light sensor (1415)
14	5A Power window control relay (471), child safety lock relay (750), power window main relay (703), air conditioning ECU (419)
15	10A Body Control Module (UCH) (645), ABS ECU (118)
16	15A Body Control Module (UCH) (645), brake light switch (160), ABS ECU and automatic transmission ECU (119), rear tail lights, center high-mounted stop lamp (CHMSL) (639)
17	20A Steering column switch module (1519), dual-direction windshield/rear window washer pump (677)
18	5A Body Control Module (UCH) (645), transponder antenna coil (1618)
19	30A Power window relay (471)
20	15A Power seat relay (1399), driver and passenger seat heaters (385-386), heated seat switches (1513-1514)
21	15A Steering column switch module (1519), horn (105), diagnostic link connector (DLC) (225)
22	15A Body Control Module (UCH) (645), rear window wiper motor (211), tailgate wiper motor (1881)
23	20A (with A/C) or 30A (standard heater) Blower motor power supply (164)
24	20A Blower motor power supply (164)
25	Not used
26	Not used
27	40A Body Control Module (UCH) (645), driver and passenger front power window motors
28	Not used
29	Not used
1155	70A Auxiliary power relay 1
1067	40A Auxiliary heater relay 1
1068	70A Auxiliary heater relay 2
471	40A Power window control relay
703	40A Power window relay
1615	20A Switched power relay ("+" with engine running)
1389	20A Auxiliary power relay 2
