Fuses and relays Renault / Dacia Logan 1, 2004 - 2016

The 1st generation Logan was produced in 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012 and 2013 with 1.4 and 1.6 petrol engines and 1.5 liter diesel engines.

In this in this publication you will find a description of Renault / Dacia Logan 1 fuses and relays with block diagrams and their locations. Note the cigarette lighter fuse.

The number of fuses and relays in the blocks, as well as their purpose, may differ from the one presented and depends on the year of manufacture and the level of equipment of your Logan 1.

In the passenger compartment

The main fuse box is located in the left end of the dashboard under a plastic cover. On the back of which there will be the current fuse designation for your Renault Logan 1.

Example.

Assignment of the fuses in the passenger compartment
No.	Description	A
F01	Chains: windshield wiper; rear window heating relay coil	20
F02	power supply of the instrument cluster; coil of relay K5 of the fuel pump and ignition coil; power supply to the ECU of the engine control system from the ignition lock	5
F03	Circuits: brake lights; reversing light bulbs; windshield washer	20
F04	Chains: airbag control unit; direction indicator lamps; diagnostic connector of the engine management system; immobilizer coils	10
F05-F08	Stock
F09	headlight lamps of the left headlight unit (low beam); headlight dipped beam indicator in the instrument cluster; headlight washer pump	10
F10	headlight lamps of the right headlamp (low beam)	10
F11	headlight lamps of the left headlight unit (high beam); headlight high beam indicator in the instrument cluster	10
F12	Circuit of a headlight lamp of the right headlight unit (high beam)	10
F13- F14	power windows for rear and front doors	30
F15	ABS ECU	10
F16	Driver and passenger seat heating switch	15
F17	Sound signal	15
F18	side light lamps of the left headlight unit; side light lamps for the left rear light; license plate lighting lamps; illumination of the instrument cluster and controls on the instrument panel, console and floor tunnel lining; switching unit buzzer	10
F19	side light bulbs of the right headlamp; side light lamps for the right rear light; glove compartment lamps	7.5
F20	lamps and warning lamp for turning on the rear fog lamp	7.5
F21	heated exterior mirrors	5
F22 - F23	Reserve
F24	Power steering pump	5
F25	Injection system PGBN	5
F26	Electronic control unit for airbags and seat belt pretensioners	5
F27	Rear wiper motor, wiper-washer switch, headlight washer pump, reversing light switch	20
F28	interior lampshade; luggage compartment lamp; constant power supply of the head unit of sound reproduction	15
F29	alarm switch; direction indicators; intermittent operation of the windshield wiper; central lock control; diagnostic connector of the engine management system	15
F30	Central locking power circuit	20
F31	Fog lamp relay coil K8	15
F32	Rear window defogger relay power circuit	30
F36	Power circuit of relay K1 heater fan	30
F37	Chains of electric drives of external rear-view mirrors	5
F38	Renault Logan cigarette lighter fuse; power supply of the head unit of sound reproduction from the ignition switch	10
F39	coil relay K1 heater fan	30

In the engine compartment

In the engine compartment of the 1st generation Logan, two different options for the arrangement of the elements are possible. In both of them, the main blocks are on the left side, next to the battery.

Type 1

Location.

Diagram
No.	Description	A
F01	Chains: power supply of the ignition lock and all consumers supplied from the lock; outdoor light switch	60
F02	Power circuit of the relay of the short circuit of the cooling fan (on a car without an air conditioner)	30
F03	Power circuits: relay K5 of the fuel pump and ignition coil; main relay KB engine management system	25
F04	Chains: constant power supply to ECU of the engine control system winding of the main relay KB of the engine management system	5
F05	Not	15
F06	Passenger compartment fuse box power supply	60
No.	Relay Appointment
K1	Heater blower motor
K2	Cooling fan motor
KZ	Cooling fan motor (for vehicles with air conditioning - through a resistor)
K4	A / C Compressor Electromagnetic Clutch
K5	Fuel pump relay and ignition coil
K6	Oxygen concentration sensor (heating circuit); speed sensor; fuel injectors; an adsorber purge solenoid valve; relay windings K2, KZ, K4
K7	Headlight washer pump (option)
K8	Fog lamps

Type 2

Left and right of the battery. Marked with red dots.

Diagram
No.	Relay / fuse assignment	A
Panel 597A
F1	Burglar alarm, outdoor light switch, daytime running light relay (block 1034)	60
F2	Ambient light switch, passenger compartment fuse box	60
Panel 597B
F1	Relay board power supply	30
F2	Injection relay supply circuit	25
F3	Power supply circuit of the injection system relay, engine ECU	5
Panel 597C
F1	ABS ECU	50
F2		25
Panel 597D
F1	High speed fan relay (relay 236), relay board	40
Panel 299
231	Fog lights	20
753	Headlight washer pump	20
Panel 784
474	A / C Compressor Relay	20
700	Low speed fan relay	20
Panel 1034
288	Daytime running light relay	20
289		20
290		20
Panel 1047
236	Fuel pump relay	20
238 (20 A)	Injection blocking relay	20
Separate relays
233	heater fan	40
236	high speed of rotation of the electric fan	40
