Fuses and relays Toyota Avensis (T270; 2008-2019)

Toyota officially unveiled the third generation of the Avensis at the 2008 Paris Motor Show. The novelty was developed by the French style center Toyota, and the car is manufactured at the company's plant in the UK. The car is offered in two body styles: sedan and station wagon. The exterior design has moved away from smooth contours - now there are more sharp, dynamic lines in the exterior, even the new large headlights, elongated at the corners, are not devoid of dynamism, and the Cd coefficient of aerodynamic drag of the sedan is 0.28. While maintaining the wheelbase (2700 mm), the new Avensis is 50 mm longer than the previous generation. The engine range includes new units: three gasoline and three diesel, all with improved environmental performance. Some models have a variator as an alternative to "mechanics".


Considered fuse digrams Toyota Avensis T270: 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019 release.

In the engine compartment


Location of components: 1. Skid Control ECU; 2. Main fuse box; 3. Engine control unit; 4. Glow plug control unit; 5. Glow plug relay; 6. Transmission control unit; 7. Relay for headlight cleaners; 8. Injector control unit; 9. Left hand drive: Relay box; 10. Right hand drive: Relay box.

Fuse box


Photo location.


General view.

Diagram
No. Description A
1 Trunk / cargo area lamps, vanity mirror illumination, engine switch illumination, front door lamps, personal / interior lamps, personal lamps, footwell lamps 10
2 02.2014 - 05.2015: Audio system 20
From 05.2015: Audio system
Before 02.2014: Audio system 15
3 Instruments and indicators, main body ECU. steering sensor, warning signal, double locking system, remote control, intelligent entry and start system, steering wheel tilt and reach adjustment 10
4 Empty -
5 Intelligent Entry & Start System, Air Conditioning System, ID Code Module, Power Windows, Power Seat Adjustment 10
6 Multiport fuel injection system / sequential multiport fuel injection system 7.5
7 Before 05.2015: Door lock system 25
From 05.2015: Body ECU 7.5
8 Audio system 30
9 Empty -
10 Steering lock system 20
11 Before 05.2015: Exhaust system 20
From 05.2015: Empty
12 Launch system 30
13 Electronic throttle control system 10
14 Direction indicators, hazard warning lights 10
15 Before 05.2015: Charging system 7.5
From 05.2015: Empty
16 Launch system 7.5
17 Before 05.2015: Air conditioning system 50
From 05.2015: -
18 ABS, VSC 50
19 Cooling fan 30
20 40
21 Headlamp cleaners 30
22 From May 2015: Fuses: "ECU-IG NO.2", "HTR-IG", "WIPER", "RR WIPER", "WASHER", "ECU-IG NO.1", "ECU-IG NO.3 "," SEAT HTR "," AM1 "," DOOR "," STOP "," FR DOOR "," POWER "," RR DOOR "," RL DOOR "," OBD "," ACC-B "," RR FOG "," FR FOG "," DEF "," TAIL "," SUNROOF "," DRL " 120
23 Empty -
24 Empty -
25 Empty -
26 Fuses: "H-LP LH LO", "H-LP RH LO", "H-LP LH HI", "H-LP RH HI" 50
27 Fuses: "EFI MAIN", "HORN", "IG2", "EDU" 50
28 Until 05.2015: Multiport fuel injection system / sequential multiport fuel injection system, fuses: "EFI NO.1", "EFI NO.2" 50
From 05.2015: Fuel heating 50
29 Before 05.2015: VALVEMATIC system 30
From 05.2015: Electric parking brake 50
30 Before 05.2015: Engine glow system 80
From 05.2015: Electric power steering 80
31 Before 05.2015: Electric power steering 80
From 05.2015: Engine glow system 80
32 Before 05.2015: Fuses: "RDI FAN", "CDS FAN", "H-LP CLN", "PWR SEAT LH", "FUEL OPN", "ABS NO.1", "ABS NO.2", "FR DEICER "," PSB "," HTR "," STV HTR "," PWR OUTLET "," HTR SUB NO.1 "," HTR SUB NO.2 "," HTR SUB NO.3 "," ECU-IG NO. 2 "," HTR-IG "," WIPER "," RR WIPER "," WASHER "," ECU-IG NO.1 "," ECU-IG NO.3 "," SEAT HTR "," AM1 "," DOOR "," STOP "," P FR DOOR "," POWER "," RR DOOR "," RL DOOR "," OBD "," ACC-B "," RR FOG "," FR FOG "," TI & TE "," SHADE "," PWR SEAT RH "," DEF "," TAIL ","DRL" 140
120
From 05.2015: Empty -
33 Before 05.2015: Fuses: "IGN", "METER" 15
From 05.2015: Fuel pump 30
34 Sound signal 15
35 Before 11.2011: Multiport fuel injection system / sequential multiport fuel injection system, fuses: "EFI NO.1", "EFI NO.2 30
From 11.2011: Fuel filler flap 10
36 Until 05.2015: Multiport fuel injection system / sequential multiport fuel injection system 20
Until 05.2015: Multiport fuel injection system / sequential multiport fuel injection system, ignition system 15
From 05.2015: Fuses: "IGN", "METER" 15
37 Until 05.2015: Empty -
From 05.2015: Fuses: "EFI NO.1", "EFI NO.2", "EFI NO.4" 50
38 Before 05.2015: Electric parking brake 30
From 05.2015: Start-stop system 40
39 Before 05.2015: Auxiliary heater 30
40 Empty -
41 Before 05.2015: Auxiliary heater 30
42 From 05.2015: Air conditioning system 50
43 Before 05.2015: Auxiliary heater 30
From 05.2015: Auxiliary heater 50
44 Electric power seat, lumbar support 30
45 Auxiliary heater 25
46 ABS, VSC 30
47 Heated wiper area windshield wipers 20
48 Before 05.2015: Fuel filler flap 10
From 05.2015: Empty
49 Before 05.2015: Seat belt with pre-crash system 30
From 05.2015: Empty
50 Power Outlet 15
51 Before 05.2015: Left headlamp (low beam) 10
From 05.2015: Left headlamp (low beam)
Before 05.2015: HID: Left headlamp (low beam) 15
15
52 Before 05.2015: Right headlamp (low beamt) 10
From 05.2015: Right headlamp (low beam)
Before 05.2015: HID: Right headlamp (low beam) 15
53 Left headlamp (high beam) 10
54 Right headlamp (high beam) 10
55 Before 05.2015: Multiport fuel injection system / sequential multiport fuel injection system, air flow meter, exhaust system 10
From 05.2015: Multiport fuel injection system / sequential multiport fuel injection system, air flow meter, exhaust system 7.5
56 Before 05.2015: Air intake system, air flow meter, exhaust system 10
From 05.2015: Air intake system, air flow meter, exhaust system 15
57 Before 05.2015: Start system 7.5
From 05.2015: -
58 Up to 11.2011: Multiport fuel injection system / sequential multiport fuel injection system 7.5
From 11.2011: Multiport fuel injection system / sequential multiport fuel injection system, fuses: "EFI NO.1", "EFI NO.2" 30
From 05.2015: Multiport fuel injection system / sequential multiport fuel injection system, fuses: "EFI NO.1", "EFI NO.2" 20
59 From 05.2015: Cooling fan 5
60 From 11.2011: Multiport fuel injection system / sequential multiport fuel injection system 7.5
From 05.2015: Cooling fan 5
Relay
R1 Until 11.2013: Heated wiper blades / Brake lamps (FR DEICER / BRAKE LP)
From 11.2013: Cooling fan (FAN NO.2)
R2 Cooling fan (FAN NO.3)
R3 Before 05.2015: Air-to-fuel ratio sensor (A / F)
From 05.2015: Fog lamp (FR FOG LH)
R4 Until 05.2015: Interior lamps (DOME CUT)
From 05.2015: Fog lamp (FR FOG RH)
R5 Engine control module (EFI MAIN)
R6 Headlamps (H-LP)
R7 Before 11.2013: Cooling fan (FAN NO.2)
11.2013 - 10.2016: Heated wiper area for windscreen wipers (FR DEICER)
From 10.2016: Dimmer
R8 Cooling fan (FAN NO.1)
R9 05.2015 - October 2016: Interior lighting (DOME CUT)
From 10.2016: (TSS C HTR)
R10 Before 11.2011: Fuel filler flap (FUEL OPN)
R11 Before 11.2011: Dimmer
From 11.2011: without AFS: Dimmer
From 1..2011: AFS: Empty
05.2015 - 10.2016:
  • with fuel heating (P / t): Fuel heating (FUEL HTR)
  • without fuel heating: Empty
R12 From 11.2011: AFS: Dimmer
05.2015 - 10.2016: Dimmer

Relay box

#9 or #10 on the picture.

Diagram
No. Description
R1 Empty
R2 Auxiliary heater (HTR SUB # 1, 2 and 3)
R3
R4

In the passenger comprtment


Component Locations: 1. Fuse Box / Body ECM; 2. Additional fuse box; 3. Active light control unit (AFS) and headlight range control unit (without AFS); 4. Distribution connector; 5. Steering wheel lock actuator; 6. Power steering control unit; 7. Key transponder amplifier; 8. Distribution block; 9. Distribution block; 10. Wiper relay; 11. Power control unit; 12. Control unit for the Start-Stop system; 13. Relay box No. 1; 14. Distribution connector; 15. Distribution connector; 16. Relay box No. 2; 17. Airbag control unit; 18. Air conditioner amplifier; 19.RHD: Double Door Lock Relay

Fuse box


Photo - location (LHD).


Photo - location (RHD).


General view of the block.
To access:
LHD: Remove the lid.
RHD: Remove the cover, and remove the lid.

Diagram
No. Decoding A
1 Starting system, fuses: "ACC", "CIG", "ECU-IG NO.2", "HTR-IG", "WIPER", "RR WIPER", "WASHER", "ECU-IG NO.1", "ECU-IG NO.3", "SEAT HTR" 7.5
2 Before 02.2013, from 05.2015: Fog Lamps 15
02.2013 - 05.2015: Fog Lamps 7.5
3 Daytime Running Lamps 7.5
4 Fuses: "CIG", "ACC" 25
5 Door locking system, double locking system 25
6 Empty -
7 Stop lights, high stop light, anti-lock braking system, VSC +, multiport fuel injection system / sequential multiport fuel injection system, automatic transmission, shift lock system, starting system 10
8 Diagnostic connector 7.5
9 Reversing lights, charging system, hazard warning lights, rear window defroster, front passenger seat belt not fastened indicator, PASSENGER AIRBAG indicator, air conditioning system, AFS, rear view display system, Toyota parking aid sensor 10
10 ECU main body, intelligent entry and start system, electric cooling fans, shift lock system, panoramic sunroof, interior rearview mirror with automatic anti-glare, anti-lock braking system, steering sensor, yaw rate and overload sensor, VSC +. headlight cleaner. emergency preparation system. LKA. driver support system 10
11 Windshield washer, rear window washer 15
12 Rear wiper 15
13 Windshield wipers, rain sensor 30
14 Air conditioning system 10
15 Until 05.2015: Seat heaters 15
From 05.2015: Seat heaters 20
16 Instrument cluster 7.5
17 Steering lock system, SRS airbag system, multiport fuel injection system / sequential multiport fuel injection system, automatic transmission, starting system 7.5
18 Rear fog lamp 7.5
19 Empty -
20 Adjusting the tilt and reach of the steering wheel 30
21 Heated exterior mirrors 10
22 Empty -
23 Exterior mirrors, shift lock system, audio system, ECU main body, electrical power outlet 7.5
24 Cigarette lighter fuse 15
25 Panoramic roof curtain 20
26 Rear right power window 20
27 Rear left power window 20
28 Front passenger side power window 20
29 Toyota Parking Aid Sensor, AFS, Heated Windshield Wiper Zone, Electric Parking Brake, Pre-Crash Seat Belt, Steering Wheel Gear Shift, Tilt & Reach Steering Wheel Adjustment, Electric Power Steering 10
30 Air conditioning switch, audio system, multidrive or automatic transmission shift lever illumination, glove box illumination, manual airbag on / off system, hazard warning lights, cigarette lighter, headlight cleaner switch, "AFS OFF" switch, speed limiter remover, headlamp adjuster headlights, headlight height control switch, "VSC OFF" switch, Toyota parking aid switch, "LKA" switch, seat heating switch, "SPORT" switch, exterior mirror switches, fuel filler flap open button 7.5
31 Front side lamps, rear lamps, license plate lamps, rear fog lamps, front fog lamps, manual headlamp leveling adjuster, instrument panel illumination 10

Body electrical control unit


LHD: Remove the coin box.
RHD: Open the glove box, slide off the damper, push in each side of the glove box to disconnect the claws.


General view.

Diagram
No. Protected chain A
1 Driver's side power window 30
2 Heated rear window, fuse: "MIR HTR" 40
3 Electric power seat, lumbar support 30
Relay
R1 Ignition (IG1)
R2 Empty
R3 Left hand drive (up to 05.2015): Direction indicators (hazard warning lamps / turn signal / flasher)

Additional fuse box

#2 on the picture.

No. Protected chain A
1 Charging system, ECU for driver assistance system 7.5
2 Empty -

Relay blocks

Diagrams.

No. Name
Relay box #1 (#13 on the picture)
R1
  • Up to 06.2010: Front fog lamps (FR FOG)
  • From 10.2016: Interior lamps (DOME CUT)
R2
R3
  • Before 11.2011: Instrument panel
  • From 11.2011: Daytime running lamps (DRL)
R4 Socket
Relay box #2 (#16 on the picture)
R1 Starter (ST)
R2 Rear fog lamps (RR FOG)
R3 Auxiliary relay (ACC)
R4
  • 06.2010 - 05.2015: Front fog lamps (FR FOG)
  • From 10.2016: Heated area for windscreen wiper blades (FR DEICER)

Car body


Location of components:

  1. Pre-crash safety system sensor;
  2. Control unit for tire pressure monitoring system;
  3. Receiver for central locking;
  4. Parking brake control unit;
  5. Distribution connector;
  6. Sunroof control unit
