Most of the electrical circuits in the Japanese sedan's are protected by fuses. Powerful current consumers are connected via relays. Protective elements are installed in distribution boxes, which are located under the hood and in the passenger compartment.
The information provided in the diagrams refers to Toyota Camry (XV50) 2011, 2012, 2013, 2014, 2015, 2016, 2017 years release.
In the passenger compartment
Fuse box located on the driver's side, below the dashboard behind the protective cover.
Photo is an example of a block.
| Assigment of fuses in the passenger compartment | ||
|---|---|---|
|
||
| No. | Decoding | A |
| 1 | Headlight washer, Toyota safe parking sensor, gear lock system, front seat heaters, rear audio switch, rear air conditioning, rear seat heaters, electric rear seat adjustment, tilt and height steering column, multiplex communication system, audio system, system navigation, rearview mirror in the passenger compartment, windshield wipers and washer, rear sunblind | 10 |
| 2 | Electronic Stability System, Electric Cooling Fans, Rear Window Defogger, Outside Rearview Mirror Defoggers, Steering Wheel Sensor, Multiport Fuel Injection System / Sequential Multiport Fuel Injection System, Headlamps (Low Beam), Battery Charging System, Blind Spot Monitor | 10 |
| 3 | Switch illumination, air conditioning system, Camry No. 1 cigarette lighter fuse, glove box lamp, gear lever illumination, reading lamps, interior lamps, audio system, navigation system | 10 |
| 4 | Front parking lamps, rear parking lamps, license plate lamps, front fog lamps, rear fog lamps | 15 |
| 5 | Electric steering | 7.5 |
| Rear right power window | 20 | |
| 6 | Blind Spot Monitor | 7.5 |
| Front left power window | 20 | |
| 7 | Heated seats | 10 |
| Rear left power window | 20 | |
| 8 | Headllamps (low beam) | 7.5 |
| 9 | Windshield wipers and washer | 10 |
| 10 | Air conditioning system | 7.5 |
| 11 | Windshield wipers and washer | 25 |
| 12 | Reversing lights, multiport fuel injection system / sequential multiport fuel injection system, electronically controlled transmission, audio system, navigation system | 7.5 |
| 13 | Power windows | 30 |
| 14 | Spare | 5 |
| Electric steering | 7.5 | |
| 15 | Rear electrical 12V power outlet | 20 |
| 16 | Gear locking system | 5 |
| 17 | Rear right power window | 20 |
| Front right seat heaters | 10 | |
| 18 | Rear left power window | 20 |
| Front left seat heaters | 10 | |
| 19 | On-board diagnostic system | 10 |
| 20 | Power windows, rear audio switch, rear air conditioning, rear seat heaters, power rear seat adjustment, rear sunblind | 10 |
| 21 | Power windows | 20 |
| 22 | Starter system, multiport fuel injection system / sequential multiport fuel injection system | 7.5 |
| 23 | Tail lights, multiport fuel injection system / sequential multiport fuel injection system, stability control system , anti-lock braking system ABS , electronically controlled transmission, high brake stop lamp, intelligent keyless entry system, gear locking system | 7.5 |
| 24 | Electric drive for rear seat adjustment | 30 |
| 25 | Air conditioning system | 7.5 |
| 26 | Sunroof | 10 |
| 27 | Electric drive for front seat adjustment | 30 |
| 28 | Spare | 30 |
| 29 | Multiplex communication system, button for locking all doors, button for opening the trunk | 20 |
| 30 | Steering column tilt and height adjustment system | 20 |
| 31 | SRS airbag system, front passenger classification system | 10 |
| 32 | Multiport fuel injection system / sequential multiport fuel injection system | 7.5 |
| 33 | Intelligent Keyless Access System, Blind Spot Monitor | 7.5 |
| 34 | Cigarette lighter Camry | 15 |
| 35 | Clock, rear audio switch, rear air conditioning, rear seat heaters, electric rear seat adjustment, rear sun shade, exterior mirrors, multiplex communication system, audio system, navigation system | 7.5 |
| 36 | Heated seats | 10 |
| 37 | Rear seat heaters | 20 |
| 38 | Front right power window | 20 |
| 39 | Spare | 7.5 |
In the engine compartment
Located on the left, near the battery.
General view of the distribution box.
| Camry 50 engine compartment fuse diagram | ||
|---|---|---|
|
||
| No. | Description | A |
| 1 | Cluster | 5 |
| 2 | 2GR-FE: Electric cooling fans | 50 |
| 3 | Headlight cleaner | 30 |
| 4 | Air conditioning system | 50 |
| 5 | without heated rear seat: Battery charging system | 120 |
| with heated rear seat: Battery charging system | 140 | |
| 6 | Vehicle stability control system | 30 |
| 7 | Starter system, fuses: ECU-IG2 NO.1, A / B, ECU-IG2 NO.2 | 30 |
| 8 | Fuses: H-LP LH-LO, H-LP RH-LO, MNL H-LP LVL, headlights (low beam) | 30 |
| 9 | Vehicle stability control system | 50 |
| 10 | Electric steering | 80 |
| 11 | Fuse: S-HORN | 7.5 |
| 12 | Sound signal (horn) | 10 |
| 13 | Multiport fuel injection system / sequential multiport fuel injection system, electronically controlled transmission | 15 |
| 14 | 2AR-FE: Multiport fuel injection system / sequential multiport fuel injection system, electronically controlled transmission | 7.5 |
| 2GR-FE: Multiport fuel injection system / sequential multiport fuel injection system, electronically controlled transmission | 10 | |
| 15 | Multiport fuel injection system / sequential multiport fuel injection system, electronically controlled transmission | 7.5 |
| 16 | Multiport fuel injection system / sequential multiport fuel injection system, electronically controlled transmission, steering column lock system, electronically controlled transmission | 7.5 |
| 17 | Starter system | 15 |
| 18 | Locking system for all doors | 20 |
| 19 | Fuses: IGN, INJ, METER-IG2, ECU-IG2 NO.3, A / B, ECU-IG2 NO.2, ECU-IG2 NO.1 | 25 |
| 20 | Battery charging system | 7.5 |
| 21 | Spare | 5 |
| 22 | Direction indicators, alarms, measuring instruments | 15 |
| 23 | Steering column lock system | 10 |
| 24 | Audio system | 15 |
| 25 | Cars with halogen headlamps: LH headlamp (low beam), manual headlamp range control | 15 |
| Cars with gas discharge headlamps: Left headlamp (low beam) | 20 | |
| 26 | Cars with halogen headlamps: Right headlamp (low beam) | 15 |
| Cars with gas discharge headlamps: Right headlamp (low beam) | 20 | |
| 27 | Vehicles with discharge headlamps: Manual headlamp range control | 7.5 |
| 28 | Multiport fuel injection system / sequential multiport fuel injection system, electronically controlled transmission, fuses: EFI NO.2, EFI NO.3, A / F sensor | 30 |
| 29 | Intelligent Keyless Access System | 5 |
| 30 | Electronic throttle control | 10 |
| 31 | Spare | 20 |
| 32 | Multiport fuel injection system / sequential multiport fuel injection system, electronically controlled transmission, electronically controlled transmission | 7.5 |
| 33 | 2AR-FE: Multiport fuel injection system / sequential multiport fuel injection system, electronically controlled transmission | 20 |
| 2GR-FE: Multiport fuel injection system / sequential multiport fuel injection system, electronically controlled transmission | ||
| 34 | Intelligent Keyless Access System | 7.5 |
| 35 | Audio system, navigation system | 20 |
| 36 | Clocks, mirror lamps, interior lamps, reading lamps, trunk lamps, door step lamps | 7.5 |
| 37 | Multiplex communication system, intelligent keyless access system, gauges, steering column tilt and height adjustment system, steering wheel sensor, remote control | 10 |
| Relay modules | ||
|
||
| R1 | Starter | |
| R2 | Horn | |
| R3 | Headlamps | |
