The second-generation Volkswagen Touran was unveiled at the 2015 Geneva Motor Show. It is built on the VW MQB platform. This article provides a comprehensive overview of the fuse box diagrams for the Volkswagen Touran (second generation; chassis code 5T; MQB platform), covering model years 2015 through 2025.
Below are the locations and photographs of the power distribution boxes. Particular attention is drawn to the fuses responsible for the 12-volt power outlet (cigarette lighter) and the fuel pump.
Engine Compartment
The engine compartment fuse box is located on the right-hand side.
General layout.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Amperage |
| R1 | Starter relay 1 -J906- | |
| R2 | Starter relay 2 -J907- | |
| R3 | Horn relay -J413- | |
| R4 | High heating power relay -J360- | |
| R5 | Main relay -J271- (gasoline) / Terminal 30 power supply relay -J317- (diesel) | |
| R6 | Automatic glow period control module -J179- (diesel) | |
| R7 | Low heating power relay -J359- (diesel) | |
| R8 | Engine component power supply relay -J757- (2.0L gasoline) | |
| R9 | Heated windshield relay -J47- | |
| R10 | Heated windshield relay 2 -J611- | |
| F1 | ABS control module -J104- | 25A |
| F2 | ABS hydraulic pump -V64-, ABS control module -J104- | 40A / 60A |
| F3 | Engine control module (ECM) -J623- | 15A / 30A |
| F4 | Piston cooling jet control valve -N522-, Oil level and temperature sensor -G266-, Turbocharger bypass valve -N529-, Engine component power supply relay -J757-, Radiator cooling fan -VX57-, High heating power relay -J360-, Low heating power relay -J359-, Oil pressure control valve -N428-, Turbocharger air recirculation valve -N249-, Intake manifold flap valve -N316- | 5A / 7.5A / 10A |
| F5 | Fuel pressure regulating valve -N276-, Fuel metering valve -N290-, Engine component power supply relay -J757-, Turbocharger bypass valve -N529- | 10A |
| F6 | Brake light switch -F- | 5A / 7.5A |
| F7 | Oil pressure control valve -N428-, Evaporative emission (EVAP) leak detection module -J909-, Transmission coolant valve -N488-, Coolant shut-off valve -N82-, Charge air cooling pump -V188-, Auxiliary heater coolant pump -V488-, Cylinder head coolant valve -N489- | 7.5A / 10A / 15A |
| F8 | Lambda sensor 1 (upstream of catalytic converter) -GX10-, Lambda sensor 1 (downstream of catalytic converter) -GX7-, NOx sensor control module -GX30-, NOx sensor 2 control module -J881- | 15A |
| F9 | Auxiliary heater coolant pump -V488-, EVAP canister purge regulator valve 1 -N80-, Camshaft adjustment valve 1 (exhaust) -N318-, Camshaft adjustment valve 1 (intake) -N205-, Exhaust flap control module -J883-, Exhaust flap control module 2 -J945-, Automatic glow period control module -J179-, Crankcase ventilation heater element -N79-, Mass air flow (MAF) sensor -G70- | 5A / 10A |
| F10 | Fuel pump control module -J538- | 15A / 20A |
| F11 | PTC auxiliary air heater element -Z35- | 40A / 50A |
| F12 | PTC auxiliary air heater element -Z35- | 40A |
| F13 | Auxiliary transmission fluid pump 1 -V475- | 30A |
| F14 | Heated windshield relay -J47- | 40A |
| F15 | Horn relay -J413- | 15A |
| F16 | Engine component power supply relay -J757- | 20A |
| F17 | Engine control module (ECM) -J623-, ABS control module -J104-, Heated windshield relay -J47- | 7.5A |
| F18 | Battery monitoring control module -J367-, Data bus diagnostic interface -J533- | 5A / 7.5A |
| F19 | Windshield wiper motor control module -J400- | 30A |
| F20 | Alarm horn -H12- | 10A |
| F21 | Heated windshield relay 2 -J611- | 30A |
| F22 | Engine control module (ECM) -J623- | 5A / 7.5A |
| F23 | Starter motor -B- | 30A |
| F24 | PTC auxiliary air heater element -Z35- | 40A |
| F31 | Not used | — |
| F32 | Not used | — |
| F33 | Heated windshield relay 2 -J611- | 30A |
| F34 | Heated windshield relay 2 -J611- | 30A |
| F35 | Windshield wiper motor control module -J400- | 30A |
| F36 | Not used | — |
| F37 | Auxiliary heater control module -J364- | 30A |
| F38 | Not used | — |
| High-current fuses (side panel) | ||
|
||
| No. | Description | Amperage |
| 1 | Terminal 30 power supply 1 | 125A |
| 2 | Alternator with voltage regulator | 400A |
| 3 | Power steering control module | 80A |
| 4 | Terminal 30 power supply 2 | 80A |
| 5 | Radiator cooling fan control module | 50A / 80A |
| 6 | Heated windshield, auxiliary heater | 50A |
Passenger Compartment
The interior fuse box is located under the dashboard, behind the glove box.
General layout.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Amperage |
| R1 | Reducing agent (AdBlue) metering system relay -J963- | |
| R2 | A/C magnetic clutch relay | |
| R3 | Not used | |
| R4 | Terminal 15 power supply relay -J329- | |
| R5 | Heated rear window relay -J9- | |
| R6 | 12V power outlet relay -J807- | |
| 1 | Reducing agent (AdBlue) heater control module -J891- | 30A |
| 2 | Steering column electronics control module -J527- | 10A |
| 3 | Not used | — |
| 4 | Alarm horn -H12- | 7.5A / 10A |
| 5 | Data bus diagnostic interface -J533- | 5A / 7.5A |
| 6 | Gear selector lever -E313- | 5A / 7.5A |
| 7 | Analog clock -Y-, Tire pressure monitoring system (TPMS) control module -J502-, Heater and A/C controls -EX21-, Rear A/C control and display panel -E265-, Auxiliary heater remote control receiver -R149-, Heated rear window relay -J9- | 10A |
| 8 | Anti-theft alarm system sensor -G578-, Cornering light and headlight range control module -J745-, Front left door ambient lighting -L251-, Rear left door ambient lighting -L253-, Front right door ambient lighting -L252-, Rear right door ambient lighting -L254-, Interior ambient lighting -WX1-, Left ambient lighting LED -L181-, Right ambient lighting LED -L182-, Rotary light switch -EX1-, Electromechanical parking brake switch -E538-, Rain and light sensor -G397-, Diagnostic connector (OBD) -U31- | 7.5A / 10A |
| 9 | Steering column electronics control module -J527- | 5A / 7.5A |
| 10 | Front information display and control head -J685-, Head-up display (HUD) control module -J898- | 7.5A / 10A |
| 11 | Vehicle electrical system control module (BCM) -J519- | 40A |
| 12 | Navigation system control module -J856-, Electronic information systems control module 1 -J794- | 20A |
| 13 | Front left seat belt tensioner -NX10- | 25A |
| 14 | Fresh air blower control module -J126- | 40A |
| 15 | Electronic steering column lock control module -J764- | 10A |
| 16 | Storage compartment with mobile phone interface -R265-, USB hub -R293-, Two-way signal amplifier for mobile/data services -J984-, USB charging port 1 -U37- | 7.5A |
| 17 | Emergency call module and communication unit -J949-, Instrument cluster -KX2- | 7.5A |
| 18 | Surround view camera control module -J928-, Tailgate handle -EX37-, Rearview camera -R246- | 7.5A |
| 19 | Keyless entry and start system interface -J965- | 7.5A |
| 20 | Reducing agent (AdBlue) metering system relay -J963-, Brake vacuum pump relay -J318- | 7.5A / 10A / 15A |
| 21 | All-wheel drive (AWD) control module -J492- | 15A |
| 22 | Trailer detector control module -J345- | 15A |
| 23 | Sunroof control module -J245- | 20A / 30A |
| 24 | Vehicle electrical system control module (BCM) -J519- | 40A |
| 25 | Driver door control module -J386-, Left rear door control module -J926- | 30A |
| 26 | Vehicle electrical system control module (BCM) -J519- | 30A |
| 27 | Vehicle electrical system control module (BCM) -J519- | 30A |
| 28 | Trailer detector control module -J345- | 25A |
| 29 | Remote start system relay -J471- | 5A |
| 30 | Remote start system relay -J471- | 10A |
| 31 | Power tailgate control module -J605- | 30A |
| 32 | Front camera for driver assistance systems -R242-, Adaptive cruise control (ACC) module -J428-, Parking aid control module -J446-, Lane change assist control module -J769-, Lane change assist control module 2 -J770- | 10A |
| 33 | Airbag control module -J234- | 5A / 7.5A |
| 34 | Center console switch module 1 -EX23-, Instrument panel center switch module -EX22-, Air quality sensor -G238-, Auto-dimming interior rearview mirror -EX5-, 12V power outlet relay -J807-, Backup light switch -F4-, A/C refrigerant pressure sensor -G805-, Structure-borne sound actuator control module -J869-, Electromechanical parking brake switch -E538- | 7.5A |
| 35 | Diagnostic connector (OBD) -U31- | 7.5A / 10A |
| 36 | Right headlamp assembly -MX2- | 5A / 7.5A |
| 37 | Left headlamp assembly -MX1- | 5A / 7.5A |
| 38 | Trailer detector control module -J345- | 25A |
| 39 | Front passenger door control module -J387-, Right rear door control module -J927- | 30A |
| 40 | 12V power outlet -U5-, 12V power outlet 2 -U18-, 12V power outlet 3 -U19- (cigarette lighter fuse) | 20A |
| 41 | Front right seat belt tensioner -NX11- | 25A |
| 42 | Vehicle electrical system control module (BCM) -J519- | 40A |
| 43 | Digital sound system control module -J525- | 40A |
| 44 | Trailer detector control module -J345- | 15A |
| 45 | Driver seat adjustment control module -J810-, Front left seat cushion ventilation fan 1 -V514-, Front left seat backrest ventilation fan 1 -V512- | 15A |
| 46 | DC/AC inverter with 12V/230V outlet -U13- | 30A |
| 47 | Rear window wiper motor -V12- | 7.5A / 15A |
| 48 | Not used | — |
| 49 | Clutch position sensor -G476-, Starter relay 1 -J906-, Starter relay 2 -J907- | 5A / 7.5A |
| 50 | Power tailgate control module -J605- | 40A |
| 51 | Rear A/C control and display panel -E265- | 25A |
| 52 | Electronic suspension damping control module -J250- | 15A |
| 53 | Heated rear window relay -J9- | 30A |
| Additional fuses in the block | ||
| A | Front passenger seat position control module -EX34-, Front right seat cushion ventilation fan 1 -V518-, Front right seat backrest ventilation fan 1 -V516- | 15A |
| B | Remote start system relay -J471- | 5A |
| C | USB charging port 1 -U37- | 7.5A |
| R1 | Remote start system relay -J471- | — |
