In this article, we provide a detailed overview of the fuse box diagrams for the first-generation Chery Beat and Indis (chassis code S18D), covering model years 2009 through 2015.
Fuse No. 14 in the interior fuse box protects the cigarette lighter circuit.
Engine Compartment
The engine compartment fuse box is located on the left side, adjacent to the battery. Remove the protective cover to access the relays and fuses.
General overview.
| Diagram | |
|---|---|
|
|
| No. | Circuit Protected |
| R1 | Main relay |
| R2 | Starter motor relay |
| R3 | Front fog lamp relay |
| R4 | Headlamp relay |
| R5 | Headlamp relay |
| R6 | Radiator cooling fan relay (High speed) |
| R7 | Radiator cooling fan relay (Low speed) |
| R8 | Fuel pump relay |
| 1 | Front fog lamps |
| 2 | Anti-lock Braking System (ABS) |
| 3 | |
| 4 | Fuel pump |
| 5 | Main relay |
| 6 | A/C compressor |
| 7 | Engine sensors |
| 8 | Radiator cooling fan, A/C system, and fuel pump |
| 9 | Spare |
| 10 | Horn |
| 11 | Engine Control Module (ECM) |
| 12 | Trunk cargo lamp, interior dome lamp, and ignition switch illumination |
| 13 | Left headlamp (Low beam) |
| 14 | Right headlamp (Low beam) |
| 15 | Left headlamp (High beam) |
| 16 | Right headlamp (High beam) |
| 17 | Headlamps |
| 18 | Instrument cluster and audio system |
| 19 | Position lamps |
| 20 | Radiator cooling fan |
| 21 | Body Control Module (BCM) |
| 22 | Radiator cooling fan (Low speed) |
| 23 | Starter motor |
Passenger Compartment
The interior fuse box is located on the driver's side, behind the side dashboard panel.
Reference image for location.
| Diagram | |
|---|---|
|
|
| No. | Circuit Protected |
| R1 | Horn relay |
| R2 | A/C compressor relay |
| R3 | Position lamp relay |
| R4 | Heater blower motor relay |
| R5 | Windshield wiper relay |
| R6 | Blower motor relay |
| R7 | Rear fog lamp relay |
| 1 | Power mirror adjustment switch |
| 2 | Starter motor relay |
| 3 | Audio system |
| 4 | Instrument cluster |
| 5 | Rear fog lamps |
| 6 | Spare |
| 7 | Heater relay |
| 8 | Power sunroof |
| 9 | Brake lamp switch |
| 10 | On-Board Diagnostics (OBD) port |
| 11 | Right position lamp / Reverse lamps |
| 12 | Left position lamp / License plate lamp / Instrument cluster |
| 13 | Audio system |
| 14 | Cigarette lighter |
| 15 | Windshield wipers |
| 16 | Blower motor relay coil |
| 17 | Windshield washer / Rear wiper / Power sunroof |
| 18 | Anti-lock Braking System (ABS) / Brake lamp switch |
| 19 | Supplemental Restraint System (SRS) airbags / Passenger airbag deactivation switch |
| 20 | Body Control Module (BCM) / Immobilizer / Instrument cluster |
| 21 | Electronic Control Unit (ECU) |
| 22 | Alternator / Vehicle Speed Sensor (VSS) / Diagnostics |
