This article provides a detailed overview of the fuse box diagrams for the first-generation Chery Bonus 3 (chassis code A19), covering model years 2014 through 2018.
Fuse RF17 in the passenger compartment fuse box protects the cigarette lighter circuit.
Passenger Compartment
The passenger compartment fuse box is located on the driver's side of the instrument panel. To gain access, remove the side trim cover.
| Diagram |
|---|
|
| No. | Description |
| R1 | Blower motor relay |
| R2 | Rear window defogger relay |
| R3 | Rear fog light relay |
| RF01 | Instrument cluster |
| RF02 | Airbag module (SRS) |
| RF03 | HVAC control module / On-Board Diagnostics (OBD) / BCM |
| RF04 | Electronic Control Unit (ECU) |
| RF05 | Anti-lock Braking System (ABS) |
| RF06 | Spare |
| RF07 | Windshield wiper |
| RF08 | Windshield wiper |
| RF09 | Power side view mirrors |
| RF16 | Audio system / Blower motor relay coil / BCM |
| RF17 | Cigarette lighter |
| RF19 | Spare |
| RF20 | Spare |
| RF21 | Brake light switch / Ignition switch |
| RF22 | Rear fog light |
| RF23 | Rear window defogger |
| RF24 | Spare |
| RF25 | HVAC control module |
| RF26 | Spare |
Engine Compartment
The primary fuse box is located on the left side of the engine compartment.
General layout.
| Diagram | |
|---|---|
|
|
| No. | Description |
| EF01 | Left high beam headlight |
| EF02 | Right high beam headlight |
| EF03 | Left low beam headlight |
| EF04 | Right low beam headlight |
| EF05 | Passenger compartment fuse and relay box |
| EF06 | ABS hydraulic pump |
| EF07 | Radiator cooling fan |
| EF08 | Spare |
| EF09 | Ignition switch |
| EF10 | Spare |
| EF12 | Body Control Module (BCM) |
| EF13 | Starter motor |
| EF14 | Spare |
| EF15 | Upstream and downstream oxygen (O2) sensors |
| EF16 | Ignition coils |
| EF17 | Electronic Control Unit (ECU) |
| EF18 |
|
| EF20 | Fuel injectors |
| EF21 | Fuel pump |
| EF22 | Cooling fan (high speed) |
| EF23 | Cooling fan (low speed) |
| EF24 | A/C condenser |
| EF25 | Spare |
| EF26 | Spare |
| EF28 | Spare |
| EF31 | Front fog lights |
| EF32 | Spare |
| EF33 | Instrument cluster / Audio system |
| EF34 | Spare |
| EF35 | Electronic Control Unit (ECU) |
| R1 | Low beam headlight relay |
| R2 | High beam headlight relay |
| R3 | Fuel pump relay |
| R4 | Spare |
| R5 | Main relay |
| R6 | Starter motor relay |
| R7 | A/C compressor clutch relay |
| R8 | Cooling fan relay (low speed) |
| R9 | Front fog light relay |
| R10 | Spare |
| R11 | Cooling fan relay (high speed) |
