Most electrical circuits in this American hatchback and sedan are protected by fuses. High-current components are connected via relays. The majority of these protective elements are housed in power distribution boxes located in the passenger compartment and under the hood.
The diagram information provided applies to second-generation Chevrolet Cruze (J400 family code / D2XX platform) models from 2016, 2017, 2018, and 2019.
Engine Compartment
Main Fuse Box
Located on the right side of the engine compartment, beneath the plastic cover.
General view of the power distribution box.
| Diagram | |
|---|---|
|
|
| No. | Fuse Description |
| F01 | Starter |
| F02 | |
| F03 | Oxygen (O2) sensor |
| F04 | Engine Control Module (ECM) |
| F05 | 2016-2018: Engine functions. 2019: Active Grille Shutters / Flex Fuel |
| F06 | Transmission Control Module (TCM) |
| F07 | Not used |
| F08 | Engine Control Module (ECM) |
| F09 | Air conditioning (A/C) |
| F10 | EVAP canister vent solenoid |
| F11 | Heated seats |
| F12 | Central Gateway Module (CGM) |
| F13 | 2016-2018: Auxiliary coolant pump / Heated steering wheel. 2019: Active Grille Shutters / Flex Fuel |
| F14 | Diesel NOx sensor / CVT8 transmission |
| F15 | Oxygen (O2) sensor |
| F16 | Fuel injection system |
| F17 | |
| F18 | Diesel NOx sensor |
| F19 | 2016-2018: Diesel NOx sensor. 2019: Diesel NOx sensor / Engine coolant |
| F20 | Not used |
| F21 | 2016-2018: Electric parking brake. 2019: DC/AC inverter |
| F22 | Anti-lock Braking System (ABS) |
| F23 | Windshield washer / Rear windows |
| F24 | Not used |
| F25 | 2016-2018: Diesel fuel heater / Secondary air injection. 2019: Diesel fuel heater |
| F26 | Transmission |
| F27 | Not used |
| F28 | Not used |
| F29 | Heated rear window |
| F30 | Heated mirrors |
| F31 | Not used |
| F32 | LED Display / DC-DC Converter / FPPM / Electric Heater / A/C Control Module |
| F33 | Security siren |
| F34 | Horn |
| F35 | Cargo area power outlet |
| F36 | Right high beam headlamp |
| F37 | Left high beam headlamp |
| F38 | Not used |
| F39 | Front fog lamps |
| F40 | Secondary Air Injection (AIR) solenoid |
| F41 | Switchable coolant pump / Water-in-fuel sensor |
| F42 | Manual headlamp leveling |
| F43 | Fuel pump module |
| F44 | Interior rearview mirror / Rearview camera / Trailer |
| F45 | Steering wheel controls |
| F46 | Instrument cluster |
| F47 | Electronic steering column lock |
| F48 | Rear window wiper |
| F49 | Not used |
| F50 | Not used |
| F51 | Not used |
| F52 | Engine Control Module (ECM) / Transmission Control Module (TCM) |
| F53 | Not used |
| F54 | Windshield wipers |
| F55 | 2016-2018: Diesel NOx sensor. 2019: Not used |
| F56 | 2016-2018: Active Grille Shutters. 2019: Not used |
| F57 | Not used |
| No. | Relay Modules |
| K01 | Starter |
| K02 | A/C control |
| K03 | Engine functions |
| K04 | 2016-2017: CVT8 transmission. 2018-2019: Not used |
| K05 | Starter |
| K06 | Diesel fuel heater / Secondary air injection |
| K07 | Right low beam headlamp / Right daytime running lamp (DRL) |
| K08 | Transmission |
| K09 | Diesel NOx sensor |
| K10 | Fuel pump relay |
| K11 | - |
| K12 | High beam headlamps |
| K13 | Left daytime running lamp (DRL) / Left low beam headlamp |
| K14 | Start Relay (Run / Crank) |
| K15 | Heated mirrors / Heated rear window / Anti-theft sensor |
| K16 | Horn |
| K17 | Diesel NOx sensor |
| K18 | Front fog lamps |
| K19 | Auxiliary coolant pump / Heated steering wheel |
| K20 | Security siren |
| K21 | Rear window washer |
| K22 | Windshield washer |
| K23 | Rear window wiper |
Auxiliary Fuse Box
Located adjacent to the battery.
| Diagram | |
|---|---|
|
|
| 1 | 2018: Transmission Control Module (Automatic Transmission only). 2019: Engine Control Module (ECM) |
| 2 | Fuel pump |
| 3 | 2018: Engine Control Module (ECM). 2019: Transmission Control Module (TCM) |
| 4 | Power supply |
Passenger Compartment
Located in the center console beneath the HVAC controls. It is concealed by a plastic cover.
To access:
1) Pull up to release the cover;
2) Detach the bottom edge of the cover;
3) Remove the cover completely.
General view of the power distribution box.
| Passenger Compartment Fuse Assignment for Chevrolet Cruze (J400) | |
|---|---|
|
|
| No. | Fuse Description |
| F1 | 2016, 2018: Not used 2017: Right rear power window |
| F2 | HVAC blower motor |
| F3 | Power driver's seat |
| F4 | Front Power Outlet (Cigarette Lighter) / Cruise Control |
| F5 | 2016, 2018, 2019: Not used 2017: Front right power window |
| F6 | 2016, 2018, 2019: Front power windows 2017: Front left power window |
| F7 | ABS valves |
| F8 | Central Gateway Module (CGM) |
| F9 | Body Control Module (BCM) 8 |
| F10 | 2016, 2018, 2019: Rear power windows. 2017: Left rear power window |
| F11 | Sunroof |
| F12 | Body Control Module (BCM) 4 |
| F13 | Heated front seats |
| F14 | Exterior mirrors / Lane Keeping Assist / Automatic High Beam Assist |
| F15 | Body Control Module (BCM) 1 |
| F16 | Body Control Module (BCM) 7 |
| F17 | Body Control Module (BCM) 6 |
| F18 | Body Control Module (BCM) 3 |
| F19 | Data Link Connector (DLC) |
| F20 | Airbag system |
| F21 | Air conditioning (A/C) |
| F22 | Trunk release |
| F23 | Passive Entry / Passive Start |
| F24 | 2016-2017: Front passenger child presence detection. 2018: Passenger Occupant Detection System. 2019: Automatic Occupant Sensing (AOS) system |
| F25 | Illuminated steering wheel controls |
| F26 | Ignition switch |
| F27 | Body Control Module (BCM) 2 |
| F28 | Audio amplifier |
| F29 | 2016-2017: Not used 2018-2019: USB charging ports |
| F30 | Gear selector illumination |
| F31 | Rear window wiper |
| F32 | 2016-2018: Transmission Control Module (with Auto Stop/Start). 2019: Virtual Key System |
| F33 | Wireless mobile phone charging / DC to AC inverter |
| F34 | Parking Assist / Side Blind Zone Alert / Infotainment / USB |
| F35 | OnStar |
| F36 | Display / Instrument cluster |
| F37 | Radio |
