The Chevrolet Aveo - produced by General Motors since 2002. The first and second generations of the Aveo were designated as the T200 and were produced from 2003 through 2005. Following a facelift, the subsequent generations were designated as the T250 and T200, spanning model years 2006 to 2011. This guide provides a detailed overview of the electrical circuits and fuse boxes for all the aforementioned generations of the Chevrolet Aveo, with specific attention given to the cigarette lighter fuses.
Regardless of the model year, this vehicle features two primary fuse boxes. The interior fuse box is located in the passenger compartment, on the driver's side of the instrument panel. The under-hood fuse box is situated in the engine compartment adjacent to the battery, protected by a clipped cover.
Passenger Compartment
The interior fuse box is located on the driver's side of the instrument panel and is concealed behind a plastic cover.
| Diagram (T250, 2005-2011) | |
|---|---|
|
|
| No. | Description |
| F1 | SDM (Sensing and Diagnostic Module - Airbags) |
| F2 | EMS 1 (Engine Management System) |
| F3 | OBD (On-Board Diagnostics) |
| F4 | Sunroof |
| F5 | Horn |
| F6 | Windshield Wipers |
| F7 | Brake Lights |
| F8 | Rear Fog Lights |
| F9 | Power Mirrors |
| F10 | Instrument Cluster |
| F11 | Audio System / RKE (Remote Keyless Entry) |
| F12 | Turn Signals |
| F13 | Cigarette Lighter |
| F14 | Interior Lighting |
| F15 | Door Courtesy Lights |
| F16 | EMS 2 (Engine Management System) |
| F17 | Audio System / Clock |
| F18 | HVAC Blower Motor |
| F19 | Reverse / Backup Lights |
| F20 | Heated Mirrors |
| Diagram (T200, 2002-2008) | ||
|---|---|---|
|
||
| No. | Description | Amps |
| F1 | 12V Accessory Power Outlet, Cigarette Lighter | 15 |
| F2 | Cigarette Lighter | 15 |
| F3 | Audio System, Clock | 10 |
| F4 | Daytime Running Lights (DRL), Clock, Instrument Cluster, Chime / Buzzer, Immobilizer | 15 |
| F5 | Instrument Cluster | 10 |
| F6 | Reverse Light Switch, Park / Neutral Position (PNP) Switch | 10 |
| F7 | ECM (Engine Control Module), TCM (Transmission Control Module) | 10 |
| F8 | Main Power Supply | 15 |
| F9 | SRS (Airbags) | 10 |
| F10 | ABS Warning Light | 10 |
| F11 | Spare | |
| F12 | Horn, Rear Window Defogger | 10 |
| F13 | Brake Light Switch | 15 |
| F14 | Instrument Cluster, Hazard Light Switch | 15 |
| F15 | Anti-Theft Alarm Control Module | 15 |
| F16 | ECM (Engine Control Module), TCM (Transmission Control Module) | 10 |
| F17 | Windshield Wipers and Washers | 20 |
| F18 | Ignition System | 10 |
| F19 | HVAC Blower Motor Switch, A/C Switch | 20 |
| F20 | Spare | |
| F21 | Spare | |
| F22 | Spare | |
| F23 | Clock, Audio System | 10 |
| No. | Relay Modules | |
| R1 | Turn Signal / Hazard Flasher Relay | |
| R2 | Rear Fog Light Relay | |
| R3 | Windshield Washer Relay | |
| R4 | Intermittent Wiper Relay | |
| R5 | A/C Condenser Fan Relay | |
| R6 | Wiper Relay | |
Engine Compartment
The under-hood fuse box is located adjacent to the battery.
| Diagram (T250, 2005-2011) | |
|---|---|
|
|
| No. | Description |
| F1 | Battery (Main) |
| F2 | Left Parking Light |
| F3 | Right Parking Light |
| F4 | Starter / Ignition 1 |
| F5 | A/C Control Module / Ignition 1 |
| F6 | Hazard Lights |
| F7 | Right Low Beam Headlight |
| F8 | Left Low Beam Headlight |
| F9 | Front Fog Lights |
| F10 | High Beam Headlights |
| F11 | Cooling Fan (High Speed) |
| F12 | Cooling Fan (Low Speed) |
| F13 | A/C Control Module |
| F14 | Power Windows 2 |
| F15 | Power Windows 1 |
| F16 | Fuel Pump |
| F17 | ECM (Engine Control Module) |
| F18 | EMS 1 (Engine Management System) |
| F19 | EMS 2 (Engine Management System) |
| F20 | Spare |
| F21 | Spare |
| F22 | Spare |
| F23 | ABS (Anti-lock Braking System) |
| R1 | Fuel Pump Relay |
| R2 | Power Window Relay |
| R3 | Parking Light Relay |
| R4 | Front Fog Light Relay |
| R5 | High Beam Relay |
| R6 | Low Beam Relay |
| R7 | Cooling Fan Relay (High Speed) |
| R8 | Cooling Fan Relay (Low Speed) |
| R9 | A/C Compressor Relay |
| R10 | Main Relay |
| FP | Fuse Puller |
| Diagram (T200, 2002-2008) | ||
|---|---|---|
|
||
| No. | Description | Amps |
| 11 | Spare | |
| 12 | Right High Beam Headlight | 10 |
| 13 | Left High Beam Headlight | 10 |
| 14 | Sunroof | 20 |
| 15 | Horn | 10 |
| 16 | Fuel Pump | 15 |
| 17 | Front Fog Lights | 15 |
| 18 | Right High Beam Headlight | 10 |
| 19 | Left High Beam Headlight | 10 |
| 20 | Right Low Beam Headlight | 10 |
| 21 | Left Low Beam Headlight | 10 |
| 22 | Dome Light / Interior Lighting | 10 |
| 23 | Rear Window Defogger | 30 |
| 24 | Headlights | 20 |
| 25 | Spare | 25 |
| 26 | A/C Compressor Clutch | 10 |
| 27 | ABS (Anti-lock Braking System) | 60 |
| 28 | Radiator Cooling Fan | 30 |
| 29 | Main Relay | 20 |
| 30 | Power Windows | 30 |
| 31 | HVAC Blower Motor | 30 |
| 32 | Interior Fuse Box (Main Power) | 30 |
| 33 | Ignition System | 30 |
| 34 | Spare | 30 |
| R1 | Cooling Fan Relay (Low Speed) | |
| R2 | Low Beam Relay | |
| R3 | Fog Light Relay | |
| R4 | Fuel Pump Relay | |
| R5 | A/C Compressor Relay | |
| R6 | Headlight Relay | |
| R7 | High Beam Relay | |
| R8 | Power Window Relay | |
| R9 | Blower Motor / Main Relay | |
| R10 | Cooling Fan Relay (High Speed) | |
