Chevrolet Lanos - a sedan designed on a common basis with Daewoo Lanos. Produced in 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017. Further known under the brand name Chance.
We assume information about Lanos fuses and relay boxes with a detailed description of the circuits and their locations. The fuse responsible for the “Cigarette lighter” is highlighted in bold.
In the engine compartment
Fuse box is located near the battery and is covered by a protective cover, which is held by two side latches.
For access, remove the steam hose from the holder..
And pressing two latches remove the protective cover of the block.
| Diagram | |
|---|---|
|
|
| No. | Amps / Description |
| EF1 | 80A Fuse circuits EF15 - EF20 and F1 - F7 |
| EF2 | 30A Ignition switch (instrument cluster and fuel pump power supply) |
| EF3 | 30A Ignition switch (starter, heater fan, electric windows) |
| EF4 | 30A Electric motors of the main and additional fans |
| EF5 | 30A Window regulator motors |
| EF6 | 50A Not used |
| EF7 | 30A Heated rear window |
| EF8 | 30A Heater fan motor (4th speed) |
| D9 | A / C Compressor Electromagnetic Clutch (diode) |
| EF10 | 20A Headlight unit lamps (high beam) |
| EF11 | 10A Lamp of the left headlamp unit (low beam), gear motor of the regulator of the direction of the beam of the left headlamp unit |
| EF12 | 10A Lamp of the right headlamp (low beam), gear motor of the regulator of the direction of the beam of the right headlamp |
| EF13 | 10A Brake / side light bulb in the left rear light (side light), instrument cluster illumination, melodic signal, side light bulb in the left headlamp, headlight beam direction control switch, fog light switch in the rear light, clock, switch alarm, ashtray light, audio system, air conditioning switch chevrolet lanos |
| EF14 | 10A Brake light / side light lamp in the right rear light (side light), side light lamp in the right headlamp, license plate lights |
| EF15 | 15A Chevrolet Lanos Fog Lamp Bulbs |
| EF16 | 15AThe fuel pump |
| EF17 | 10A Sound signal |
| EF18 | 10A A / C Compressor Electromagnetic Clutch |
| EF19 | 25A Contact "30" headlight relay |
| EF20 | 20A Contact "30" of the side light and interior lighting relay |
| Relay | Name |
| K1 | Sound signal |
| K2 | Headlight bulbs |
| KZ | A / C Compressor Electromagnetic Clutch |
| K4 | Additional cooling fan motor |
| K5 | Fog lamps |
| K6 | Side light bulbs in headlamps, brake / side light bulbs in rear lights (side light), instrument cluster illumination lamps, interior lamp |
| K7 | Window regulator motors |
| K8 | Main cooling fan motor |
| K9 | Fuel pump motor |
| K10 | Heated rear window |
| K11 | Relays of electric motors of the main and additional fans of the cooling system |
In the passenger compartment
Fuse box
Located on the left pillar, near the door.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Amps |
| F1 | Luggage compartment lamp, interior lamp, left rear fog lamp, aerial motor | 10 |
| Light switch in the left steering column switch, lamp switch | ||
| F2 | fog light in the left tail lamp, headlight beam direction control, open door warning lamp | 10 |
| F3 | Alarm | 15 |
| F4 | central locking | 15 |
| F5 | Power supply circuits of the engine control unit from the storage battery | 10 |
| F6 | Power supply circuit of the audio system from the storage battery | 10 |
| F7 | Brake light / side light lamps in the rear lights (brake lights) | 15 |
| D8 (diode) | Open door warning switch (driver's door) | |
| F9 | Audio power supply circuit from ignition switch | 10 |
| F10 | Cigarette lighter fuse Lanos | 15 |
| F11 | Instruments and signaling devices in the instrument cluster (except for fog lights, direction indicators and an open door) clock, glove box lighting lamp | 10 |
| F12 | Reversing lamp in the right rear light | 10 |
| F13 | Safety bag | 15 |
| F14 | Excitation of the generator, injectors, vehicle speed sensor, canister purge valve, EGR valve, phase sensor | 15 |
| F15 | Lanos ignition coil | 15 |
| F16 | Direction indicator lamps in the headlights, direction indicator lamps in the rear lamps, electric drive of the right outside rear-view mirror | 15 |
| F17 | Power supply circuits of the engine control unit and the fuel pump relay from the ignition switch | 15 |
| F18 | Windshield wiper motor, windshield washer pump motor | 20 |
| Relay coils for rear window defroster, A / C compressor relay, | ||
| F19 | power window relays, relays (K4, K8, K11) of electric motors of cooling fans | 10 |
| F20 | Heater fan motor (1st, 2nd and 3rd speed) | 20 |
Relay box
The passenger compartment contains a relay box consisting of four elements. It is located behind the headlight dimmer cover.
1 - Fog lamp;
2 - Heater fan speed relay 4;
3 - Relay for intermittent operation of the windshield wiper;
4 - Alarm.
