Fuses and relays Chevrolet Spark (M300), 2009 - 2016

The Chevrolet Spark  is a subcompact car produced by Daewoo across several generations. The first generation was known as the Daewoo Matiz. The second generation was produced from 2005 to 2009. The third generation was produced from 2009 to 2016.


This manual covers the third-generation Spark (M300) fuse boxes, providing a detailed description of all electrical circuits.

Engine Compartment

Main Fuse Box


The fuse box is located on the left side of the engine compartment.


To access the fuses, remove the protective plastic cover.


General view (Type 1).

Type 1

US market.

Diagram
No. Amps Description
1 15 Rear heater relay, Instrument panel fuse box
2 15 Hazard warning flasher switch
3 30 Ignition switch
4 15 Engine control module (ECM), Ignition coils 1-4, Ignition coil module, LPG control module
5 40 Ignition switch
6 15 Heated oxygen sensors (HO2S) 1 and 2, EGR valve, EVAP purge solenoid valve, Camshaft position (CMP) sensor
7 50 Electronic brake control module (EBCM)
8 10 Engine control module (ECM), Transmission control module (TCM)
9 20 Heated seat relay
10 10 Spare fuse
11 30 Cooling fan relay - high speed
15 Engine control module (ECM), Ignition coils 1-4, Ignition coil module, LPG control module
12 40 Electronic brake control module (EBCM)
13 10 A/C compressor clutch
14 15 Spare fuse
15 20 Cooling fan relay - low speed
16 30 Starter relay
17 15 Fuel pump relay
18 10 License plate lamp, Left tail lamp, Left parking/turn signal lamp, Left headlamp leveling actuator
19 10 Right parking/turn signal lamp, Right headlamp leveling actuator, Right tail lamp, Interior lamp relay
20 20 High beam headlamps, Instrument cluster
21 10 Left low beam headlamp, Headlamp leveling switch
22 10 Right low beam headlamp
23 10 Horn relay, Hood ajar switch
24 10 Front fog lamp relay
25 20 Spare fuse
26 - Not used
27 - Not used
Relays
R1 A/C relay
R2 Parking lamp relay
R3 Low speed cooling fan relay
R4 High speed cooling fan relay
R5 Front fog lamp relay
R6 Fuel pump relay
R7 Main engine relay
R8 Low beam headlamp relay
R9 Horn relay
R10 Heated seat relay
R11 Starter relay
R12 High beam headlamp relay

Type 2

EU market.

Diagram
No. Description
1 Fuel pump
2 Parking lamp relay
3 Low speed cooling fan relay
4 Cooling fan - high speed
5 Air conditioning (A/C)
6 High speed cooling fan relay
7 A/C relay
8 ABS 2
9 Left parking lamp
10 Right parking lamp
11 Front fog lamps
12 Cooling fan - low speed
13 ABS 1
14 Front fog lamp relay
15 Fuel pump relay
16 Spare fuse
17 High beam headlamp relay
18 High beam headlamp
19 Left low beam headlamp
20 Right low beam headlamp
21 Spare fuse
22 Spare fuse
23 Ignition 2 / Starter
24 Ignition 1 / Accessory
25 Hazard warning flashers
26 Horn
27 Low beam headlamp relay
28 Horn relay
29 Main engine relay
30 Ignition
31 EMS
32
33 Instrument panel battery
34
35 Front power windows
36 Front power window relay
37 Engine control module (ECM)
38
39 Spare

Auxiliary Fuse Box


Located near the battery.

No. Description
EVP RELAY Electric vacuum pump (EVP) relay
EVP MTR Electric vacuum pump (EVP) motor

Passenger Compartment


The interior fuse box is located under the dashboard on the driver's side.


Example photo.

Type 1

US market.

Diagram
No. Amps Description
F1da 10 Dome lamp, Luggage compartment lamp, Sensing and diagnostic module (SDM)
F2DA 15 Cellular telephone control module, Audio system, Instrument cluster, Remote control door lock receiver (RCDLR), Theft deterrent module (TDM), HVAC control module
F3DA 10 Instrument cluster, Starter, Park/neutral position (PNP) switch, Remote control door lock receiver (RCDLR), Ignition switch
F4DA 15 Stop lamp switch, Engine control module (ECM), Transmission control module (TCM), Electronic brake control module (EBCM), Left tail lamp, Right tail lamp, Center high-mounted stop lamp (CHMSL)
F5DA 20 Cigarette lighter receptacle
F6DA 25 Passenger power window switch, Driver power window switch, Master power window switch
F7DA 15 Fuel pump relay, Engine control module (ECM), Automatic transmission input/turbine speed sensor, Fuel rail pressure (FRP) sensor, Vehicle speed sensor (VSS), LPG control module, Automatic transmission output speed sensor, Immobilizer control module
F8DA 10 Instrument cluster, Audio system, Remote control door lock receiver (RCDLR), Theft deterrent module (TDM)
F9DA - Not used
F10DA 25 Driver power window switch
F11DA 10 Stop lamp switch, Transmission control module (TCM), Transmission range (TR) switch
F12DA 10 Data link connector (DLC) 1, Data link connector (DLC) 2, Immobilizer control module
F13DA 10 Sensing and diagnostic module (SDM)
F14DA 25 Blower motor control module
F15DA 10 Information display module, Instrument cluster, Cellular telephone control module
F16DA 10 Rear fog lamp relay, Left tail lamp, Right tail lamp, Instrument cluster
F17DA 20 Rear window defogger grid
F18DA 10 Hazard warning flasher switch
F19DA 15 Park/neutral position (PNP) switch, Backup lamp switch
F20DA 25 Not used
F21DA 20 Windshield wiper motor, Windshield wiper/washer switch
F22DA 15 Door lock relay, Door unlock relay
F23DA 15 HVAC control panel switch block, Heated windshield grid, Left outside rearview mirror (OSRVM), Right outside rearview mirror (OSRVM)
F24DA 10 Theft deterrent module (TDM), Engine compartment fuse box, Low beam relay, High beam relay, Starter relay, Heated seat relay
F25DA 10 Instrument cluster, HVAC control, Outside rearview mirror switch
F26DA 10 Windshield wiper/washer switch, Rear window wiper motor

Type 2

EU market.

Diagram
No. Circuit
1 Rear wiper
2 Outside rearview mirrors (OSRVM)
3 Headlamps
4 Power OSRVM
5 Door locks
6 Front wipers
7
8 Backup lamps
9 Turn signal indicators
10 Rear defogger
11 Rear fog lamps
12 Instrument cluster
13 Blower motor control module
14 Airbags (SDM)
15 Theft deterrent module (TDM) / Data link connector (DLC)
16 Transmission control module (TCM)
17 Rear power windows
18 Radio / Remote keyless entry (RKE)
19 Engine control module (ECM) / Theft deterrent
20 Heated seats
21 Cigarette lighter
22 Stop lamps
23 Starter
24 Radio / Clock / Remote keyless entry (RKE)
25 Airbags (SDM)
26 Interior lamps

General Arrangement

Electronic component locations.

No. Component
1 ABS control module
2 A/C and heater blower motor control module (automatic temperature control)
3 A/C relay (connected to engine compartment fuse/relay box 1)
4 Theft deterrent module (TDM)
5 Battery
6 Central locking control module
7 Data link connector (DLC)
8 Engine control module (ECM) - behind battery
9 Cooling fan relay 1 (connected to engine compartment fuse/relay box 1)
10 Engine compartment fuse/relay box 1
11 Engine compartment fuse/relay box 2 - LPG models
12 Passenger compartment fuse box
13 LPG control module - under the left front seat
14 High beam headlamp relay (connected to engine compartment fuse/relay box 1)
15 Low beam headlamp relay (connected to engine compartment fuse/relay box 1)
16 Heater blower motor resistor
17 Horn relay (connected to engine compartment fuse/relay box 1)
18 Horn 1
19 Horn 2
20 Horn (only) - behind left front wheel arch trim
21 Immobilizer control module
22 Turn signal control module / Flasher
23 Cellular telephone control module
24 Ambient air temperature sensor - behind the grille
25 Park assist control module - left side of luggage compartment
26 Parking lamp relay (wired to engine compartment fuse/relay box 1)
27 Sensing and diagnostic module (SDM) / Airbag control module
28 Transmission control module (TCM) - behind left bezel
29 Vehicle speed sensor (VSS) - on the transmission
