In this article, we provide a detailed overview of the fuse box diagrams for the first-generation Chrysler 300M (LR platform): covering the 1998, 1999, 2000, 2001, 2002, 2003, and 2004 model years.
Fuse "Y" in the engine compartment and fuse #6 in the passenger compartment protect the cigarette lighter and 12V power outlets.
In the engine compartment
Located on the left side of the engine compartment, behind the plastic cover.
General view of the Power Distribution Center (fuse box).
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Amps |
| A | Rear Window Defogger Relay, Body Control Module (BCM), HVAC Manual Temperature Control Head | 50 A |
| B | A/C Compressor Clutch Relay, Radiator Fan Relay (High-Speed) | 30 A / 40 A |
| C | High Beam Headlamp Relay (Fuses #2 and #3), Fuses #15 and #16 in the passenger compartment | 30 A |
| D | Low Beam Headlamp Relay (Fuses #10, #11, and #12), Circuit Breaker 2 (CB2), Door Lock Relay, Door Unlock Relay, Driver Door Unlock Relay | 40 A |
| E | Radiator Fan Relay (Low-Speed) | 40 A |
| F | Fuses "Y" and "X", Reserve Relay | 20 A / 30 A |
| G | Starter Relay, Fuel Pump Relay, Ignition Switch (Fuses #1, #4, #5, #6, #13, #14, #21, and #22 in the passenger compartment, and Fuse "V") | 40 A |
| H | Anti-lock Braking System (ABS) | 30 A |
| I | Fuses #19 and #20 | 30 A |
| J | Ignition Switch (Fuses #8, #9, #17, #23, and CB1 in the passenger compartment) | 40 A |
| K | Anti-lock Braking System (ABS) | 40 A |
| L | Fuses #7 and #18 in the passenger compartment | 40 A |
| M | Windshield Wiper On/Off Relay, Windshield Wiper High/Low Relay, Body Control Module (BCM) | 40 A |
| N | Automatic Shutdown (ASD) Relay, Powertrain Control Module (PCM) | 30 A |
| O | Turn Signal/Hazard Flasher Module | 20 A |
| P | Headlamp Washer Relay, Body Control Module (Export Models) | 30 A |
| Q | Transmission Control Relay | 20 A |
| R | Rear Fog Lamp Relay (Export Models) | 20 A |
| S | Fuel Injectors, Ignition Coils, Capacitor, Short Runner Valve Solenoid (3.5L Engine), Manifold Tuning Valve | 20 A |
| T | Powertrain Control Module (PCM) | 20 A |
| U | Not Used (Empty) | 20 A |
| V | Starter Relay, Powertrain Control Module (PCM) | 10 A |
| W | Automatic Shutdown (ASD) Relay | 10 A |
| X | Spare Relay (Reserve) | 20 A |
| Y |
|
15 A |
| Relays | ||
| 1 | Automatic Shutdown (ASD) Relay | |
| 2 | High-Speed Radiator Fan | |
| 3 | Low-Speed Radiator Fan | |
| 4 | Headlamp Washer | |
| 5 | Windshield Wiper High/Low Relay | |
| 6 | A/C Compressor Clutch | |
| 7 | Rear Fog Lamp | |
| 8 | Engine Starter Motor | |
| 9 | Transmission Control Relay | |
| 10 | Windshield Wiper On/Off Relay | |
| 11 | Chrysler 300M Fuel Pump Relay | |
In the passenger compartment
Located on the driver’s side edge of the dashboard. To access the fuses, pull the plastic cover straight out from the dashboard.
General view of the interior fuse block.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Amps |
| 1 | Transmission Control Module (TCM), Instrument Cluster Gauges, AutoStick® | 10 A |
| 2 | Right High Beam Headlamp | 10 A |
| 3 | Left High Beam Headlamp | 10 A |
| 4 | Radio Head Unit, CD Player | 10 A |
| 5 | Windshield Washer Motor | 10 A |
| 6 |
|
15 A |
| 7 | Tail Lamps, License Plate Lamps, Parking Lamps, Interior Illumination, Instrument Cluster | 20 A |
| 8 | Airbag Control Module (ACM) | 10 A |
| 9 | Turn Signal Lamps, Turn Signal/Hazard Indicators | 10 A |
| 10 | Right Low Beam Headlamp | 15 A |
| 11 | High Beam Relay, Indicator, and Switch | 20 A |
| 12 | Left Low Beam Headlamp | 15 A |
| 13 | Fuel Pump Fuse, Powertrain Control Module (PCM) | 10 A |
| 14 | Instrument Cluster, Auto-Dimming Rearview Mirror, Sunroof, Overhead Console, Garage Door Opener, Body Control Module (BCM) | 10 A |
| 15 | Daytime Running Lamps (DRL) (Canada) | 10 A |
| 16 | Fog Lamp Indicator | 20 A |
| 17 | ABS Control Module, Reverse Lamps, Daytime Running Lamps (DRL), HVAC Control Head | 10 A |
| 18 | Audio Power Amplifier, Horn | 20 A |
| 19 | Overhead Console, Garage Door Opener, Trunk Lamp, Overhead/Rear Reading and Visor Vanity Lamps, Trunk Release Solenoid, Power Mirrors, Power Door Locks, Body Control Module (BCM), Cabin Temperature Aspirator Motor | 15 A |
| 20 | Stop Lamps | 20 A |
| 21 | Evaporative Leak Detection Pump (LDP), Low-Speed Radiator Fan Relay, High-Speed Radiator Fan Relay, A/C Compressor Clutch Relay | 10 A |
| 22 | Supplemental Restraint System (Airbags) | 10 A |
| 23 | HVAC Blower Motor, Automatic Temperature Control (ATC) Power Module | 30 A |
| CB1 | Power Window Motors (Circuit Breaker) | 20 A |
| CB2 | Power Door Lock Motors, Power Seats (Circuit Breaker) | 20 A |
| Relays | ||
| R1 | Horn Relay | |
| R2 | Spare (Reserve) | |
| R3 | Driver Door Unlock Relay | |
| R4 | Fog Lamp Relay | |
| R5 | Low Beam Headlamp Relay | |
| R6 | Door Lock Relay | |
| R7 | Door Unlock Relay | |
| R8 | High Beam Headlamp Relay | |
| R9 | Parking Lamp Relay | |
| R10 | Daytime Running Lamps (DRL) Relay | |
