This guide provides a detailed overview of the fuse box diagrams for the second-generation Chrysler Pacifica (RU platform), covering the 2016, 2017, 2018, 2019, and 2020 model years equipped with gasoline and hybrid powertrains.
Fuses #60 and #85 protect the cigar lighter and accessory power outlets.
Engine Compartment Fuse Box
The vehicle is equipped with a SINGLE fuse box, known as the Power Distribution Center (PDC), located on the left side of the engine compartment.
To access the fuses, remove the protective PDC cover.
PDC layout overview.
| Diagram | ||
|---|---|---|
|
||
| Cavity | Circuit Description | Rating (Amps) |
| Circuit Breakers | ||
| CB1 | 2018 and newer: Driver Power Seat Module | 25 A |
| CB2 | 2018 and newer: Passenger Power Seat Module | 25 A |
| CB3 | 2018 and newer (Gasoline only): Rear Power Window Lockout and Front Power Windows (Without Door Nodes) | 25 A |
| Cartridge Fuses | ||
| F15 | Power Door Locks | 40 A |
| F17 | Gasoline Engine: Starter Motor Hybrid: Not Used |
30 A |
| F18 | Exterior Lighting 1 | 40 A |
| F19 | Gasoline Engine: Left 2nd Row Folding Seat Solenoid Hybrid: Not Used |
25 A |
| F21 | Gasoline Engine: Right 2nd Row Folding Seat Solenoid (25 A) Hybrid: Power Inverter Module (PIM) - Park Pawl Motor (20 A) |
25 A / 20 A |
| F26 | HVAC - Front Blower Motor | 40 A |
| F27 | Right Rear Sliding Door Module | 25 A |
| F32 | Electronic Control Module (ECM) | 20 A |
| F33 | Power Liftgate Module | 30 A |
| F34 | Left Rear Door Control Module | 25 A |
| F35 | Sunroof / Moonroof Control Module | 25 A |
| F37 | Exterior Lighting 2 | 40 A |
| F38 | Gasoline Engine: Integrated Vacuum Cleaner (60 A) Hybrid: Not Used |
60 A |
| F39 | HVAC - Rear Blower Motor | 25 A |
| F40 | Gasoline Engine: Not Used Hybrid: Transmission Oil Pump (20 A) |
20 A |
| F42 | Gasoline Engine: Folding Seat Module (30 A) Hybrid: Not Used |
30 A |
| F44 | Interior Lighting | 30 A |
| F45 | Power Inverter Module | 30 A |
| F46 | Driver Power Door Module | 30 A |
| F47 | Passenger Power Door Module | 30 A |
| F48 | Gasoline Engine: Not Used Hybrid: Electronic Brake Control Module (EBCM) - Motor |
40 A |
| F49 | Left Rear Sliding Door Module | 25 A |
| F50 | Right Rear Door Control Module | 25 A |
| F51 | Front Wiper Motor | 30 A |
| F52 | Gasoline Engine: Brake Vacuum Pump (30 A) Hybrid: Not Used |
30 A |
| F54 | Electronic Stability Control (ESC) - ECU and Valves | 40 A |
| F59 | Gasoline Engine: Trailer Tow 7-Way Connector Receptacle (If Equipped) Hybrid: Not Used |
30 A |
| F73 | Rear Window Defroster / Electric Back Lite (EBL) | 30 A |
| F74 | Gasoline Engine: Trailer Tow Backup Lamps Hybrid: Not Used |
20 A |
| F83 | Gasoline Engine: Trailer Tow (TT) Parking Lamps (If Equipped) (20 A) Hybrid: Transmission Oil Pump 1 (30 A) |
20 A / 30 A |
| F84 | Gasoline Engine (up to 2017): Electronic Stability Control (ESC) - Motor Pump (40 A) Hybrid: Not Used |
40 A |
| F94 | Gasoline Engine (up to 2017): Not Used; (2018 and newer): Electronic Stability Control (ESC) - Motor Pump Hybrid: Electronic Stability Control (ESC) - Motor Pump |
40 A |
| F99 | Gasoline Engine (up to 2017): Electronic Brake Module, Trailer Tow; (2018 and newer): Trailer Tow Module Hybrid: Not Used |
30 A |
| Blade Fuses | ||
| F06 | Gasoline Engine: Not Used Hybrid: Low Temperature Active Pump (15 A) |
15 A |
| F07 | Ignition Coils / Fuel Injectors | 25 A |
| F08 | Gasoline Engine: Not Used Hybrid: Audio Amplifier / Active Noise Cancellation (ANC) |
25 A |
| F09 | Gasoline Engine: Audio Amplifier / Active Noise Cancellation (ANC) Hybrid: Not Used |
25 A |
| F10 | Gasoline Engine: Not Used Hybrid: High Temperature Auxiliary Pump & High Voltage (HV) Electric Coolant Heater Enable (15 A) |
15 A |
| F11 | Gasoline Engine: Not Used Hybrid: EVAP Leak Check Module, Fuel Tank Isolation Valve (5 A / 15 A) |
5 A / 15 A |
| F12 | Intelligent Battery Sensor (IBS) | 5 A |
| F13 | Hybrid: Not Used Gasoline Engine (2018 and newer): Engine Control Module (ECM) - ESS Only (10 A) |
* / 10 A |
| F14 | Gasoline Engine: Engine Control Module (ECM) Hybrid: Media Hubs 1, 2, 3 and Power Lumbar Switch |
10 A |
| F16 | Engine Control Module (ECM) | 20 A |
| F20 | Gasoline Engine: A/C Compressor Clutch Hybrid: Low Temperature Passive Pump |
10 A |
| F22 | Not Used | - |
| F23 | Not Used | - |
| F24 | Rear Wiper Motor | 20 A |
| F25 | Gasoline Engine: Hands-Free Liftgate, Left/Right Rear Door Release Modules, Active Grille Shutter, Power Mirrors Hybrid: Hands-Free System, Left/Right Rear Door Release Modules, Active Grille Shutter |
10 A |
| F28 | Diagnostic Port (OBD-II), AUX Port, USB Ports, Video USB Port | 10 A |
| F29 | Not Used | - |
| F30 | Gasoline Engine: Media Hubs 1 and 2, Power Lumbar Hybrid: Electronic Control Module (ECM), Power Inverter Module (PIM) |
15 A |
| F31 | Gasoline Engine: Not Used Hybrid: 3-Way / 4-Way Coolant Valves (10 A) |
* / 10 A |
| F36 | Not Used | - |
| F41 | Not Used | - |
| F43 | Fuel Pump Motor | 20 A |
| F53 | Not Used | - |
| F55 | Keyless Ignition System, DVD Player, Voice Recognition Module, Radio Frequency (RF) Hub, Electronic Steering Column Lock (BUX Only) | 15 A |
| F56 | Gasoline Engine: Front and Rear HVAC Control Module, Electronic Stability Program (ESP), Electronic Steering Column Lock (ESL); (2018 and newer): Occupant Classification Module (OCM) Hybrid: Occupant Classification Module (OCM), Electronic Steering Column Lock (ESL), Electronic Stability Program (ESP) / Electronic Stability Control (ESC), Electronic Brake Control Module (EBCM) |
10 A |
| F57 | Gasoline Engine: Not Used Hybrid: Power Inverter Module (PIM) - Main Power Supply |
20 A |
| F58 | Not Used | - |
| F60 | Rear Cargo Accessory Power Outlets | 20 A |
| F61 | Gasoline Engine: Trailer Tow - Right Stop and Turn Signal (If Equipped) Hybrid: Not Used |
20 A |
| F62 | Gasoline Engine: Not Used Hybrid: Power Inverter Module (PIM) - Redundant Main Power Supply |
20 A |
| F63 | Gasoline Engine: Trailer Tow - Left Stop and Turn Signal (If Equipped) (20 A) Hybrid (up to 2017): Not Used; (2018 and newer): High Voltage (HV) Electric Coolant Heater Enable (5 A) |
20 A / 5 A |
| F64 | Gasoline Engine: Right High-Intensity Discharge (HID) Headlamp Hybrid: Not Used |
15 A |
| F65 | Not Used | - |
| F66 | Instrument Panel Cluster (IPC) | 15 A |
| F67 | ParkSense Assist System, In-Cabin Temperature Sensor, Humidity Sensor, Driver Assist System Module (DASM), Haptic Lane Feedback Module | 10 A |
| F68 | Not Used | - |
| F69 | Gasoline Engine: Not Used Hybrid: Battery Pack Control Module - Redundant (15 A) |
15 A |
| F70 | Gasoline Engine: Not Used Hybrid: Electric A/C Compressor (EAC) (5 A) |
5 A |
| F71 | Dual Horns | 20 A |
| F72 | Gasoline Engine: Heated Mirrors (If Equipped) (10 A) Hybrid: Not Used |
10 A |
| F75 | Rear Integrated Center Console, Overhead Console | 5 A |
| F76 | Uconnect System, Comfort Module, Telematics | 20 A |
| F77 | Cabin Rearview Mirror Module (CRVMM), Rear Entertainment Screen, Media Hub, 2nd and 3rd Row USB Charge Outlets, Sunroof / Moonroof, Rain Sensor | 10 A |
| F78 | Electronic Shifter, Transmission Control Module (TCM), Instrument Panel Cluster (IPC) | 15 A |
| F79 | Front and Rear HVAC, Steering Column Control Module (SCCM), Integrated Center Stack (ICS), Electric Parking Brake (EPB) | 10 A |
| F80 | Gasoline Engine: Not Used Hybrid: On-Board Charging Module (OBCM) |
5 A |
| F81 | Gasoline Engine: Not Used Hybrid: Audio Amplifier |
5 A |
| F82 | Not Used | - |
| F85 | Cigar Lighter / Power Outlet | 20 A |
| F86 | Not Used | - |
| F87 | Not Used | - |
| F88 | Front Heated Seats | 20 A |
| F89 | Rear Heated Seats | 20 A |
| F90 | Gasoline Engine: Not Used Hybrid: Electronic Brake Control Module (EBCM) - ECU (5 A) |
5 A |
| F91 | Heated Steering Wheel, Front Ventilated Seats | 20 A |
| F92 | 2018 and newer: Security Gateway Module (SGW) (5 A) | 5 A |
| F93 | Not Used | - |
| F95 | USB Charge Socket | 10 A |
| F96 | Airbag Module - Occupant Restraint Controller (ORC) | 10 A |
| F97 | Airbag Module - Occupant Restraint Controller (ORC) | 10 A |
| F98 | Gasoline Engine: Left High-Intensity Discharge (HID) Headlamp Hybrid: Not Used |
15 A |
| F100 | In-Cabin Temperature Sensor, Auto Headlamp Leveling Module, Left Blind Spot Sensor (LBSS), Regenerative Braking System, Central Vision Processing Module (CVPM), Humidity Sensor, Rear View Camera | 10 A |
