In 2007, a new crossover of the French company was presented, named C-Crosser, although initially it was to be called C7. The name is formed from "to cross". And really, the automobile is a crossing of Japanese and French automobile industry. After all, the base for it (and at the same time Peugeot 4007) was Mitsubishi Outlander. In this article we will understand in detail fuse box diagrams Citroen C-Crosser (1st generation; body EP; engines series 4B) 2007, 2008, 2009, 2010, 2011, 2012 years of manufacture.

Here you will find the locations and photos of the mounting blocks. Also, we will separately mark the fuses responsible for the cigarette lighter and the fuel pump.

In the engine compartment

Here there are three units responsible for the protection of the vehicle's electrical circuits.

Main fuse box

The main mounting block is located near the battery.

General view.

No. Assgment of relay modules
R1 Glow plugs (for diesel engines)
R2 Radiator fan
R3 Heater
R4 Engine management system
R5 Stability control system
R6 Air conditioner radiator fan
R7 Engine management system
R8 dipped headlights
R9 Engine management system
R10 Heated windshield wiper blades
R11 Daytime outdoor lighting system
R12 Engine management system
R13 Alarm (horn)
R14 Automatic transmission
R15 headlight washer
R16 High beam headlights
R17 Front fog lights
R18 Horn (beep)
R19 Air conditioning
No. Description of fuses A
1 Input-output device 30
2 Cooling fan motor 40
3 Condenser fan motor 30
4 ABS system 30
5 40
6 Spare
7 Starter 30
8 Front fog lights 15
9 Engine management 7.5
10 Automatic transmission 20
11 Horn / Beep 10
12 Alternator 7.5
13 headlight washer 20
14 Air conditioning 10
15 Throttle valve 15
16 Alarm system buzzer 20
17 Heated wiper blades 15
18 Spare
19 Electric trunk door actuator 30
20 Daytime running lights system 10
21 High beam headlamp (left) 10
22 High beam headlamp (right) 10
23 Audio amplifier 30
24 Diesel engine electrical equipment 30
25 Left dipped beam headlamp (with discharge lamps) 20
26 Right dipped beam headlamp (with discharge lamps) 20
27 Left dipped beam headlamp (with halogen bulbs) 10
28 Right dipped beam headlamp (with halogen bulbs) 10
29 Engine power supply circuit 10
30 Ignition coil 10
31 Engine power supply circuit 20
32 Fuel pump fuse 15

Additional relay box

Located near the main unit.

No. Appointment
R1 Low engine cooling fan speed
R2 Air conditioner fan relay
R3 High engine cooling fan speed

Power fuses

A board of high-power fusible links is placed on the plus terminal of the battery.

No. Decoding A
33 Feeding into the embedded systems interface 80
Interior fuse box
34 Underhood fuse box 120
36 Auxiliary heater relay 60
38 Feeding into the embedded systems interface 80
Passenger compartment fuse and relay box
Headlight relay
Rear fog lamp
39 Alternator 120

In the passenger compartment

Located on the driver's side at the bottom of the dashboard, behind the protective cover.

General view of the Citroen C-Crosser interior fuse box.

No. Description A
1 Heating system. 30
2 Stop lamp, third brake light, intelligent switching unit 15
3 Rear fog lights 10
4 Windshield wiper and washer 30
5 Diagnostic connector 10
6 Central locking, outside mirrors 20
7 Car radio, telematics, multifunction display, wireless headset. 15
8 Key board, A/C ECU, instrument panel, indicator lamp unit, paddle shifters 7.5
9 Multifunctional display, instrument panel 15
10 Intelligent breakout box 15
11 Rear window wiper 15
12 Instrument panel, four-wheel drive system ECU, air conditioning control panel, ABS ECU, multifunction display, automatic headlight correction, airbag ECU, steering angle sensor, sunroof, heated rear window, remote control keypad 7.5
13 Citroen C-Crosser cigarette lighter fuse , 12 V socket (depending on configuration) 15
14 Ignition lock. 10
15 Sunroof 20
16 Outside mirrors, car radio, telematics. 10
17 Four-wheel drive system ECU. 10
18 Reverse lights, parktronic ECU, rearview video camera, airbag ECU. 7.5
19 C-Crosser cigarette lighter fuse, socket for additional electrical appliances. 15
20 Power window control panel. 30
21 Rear window heater. 30
22 Heated side mirrors 7.5
23 Not used -
24 Driver's seat actuator, sill plates, rear sofa lock release mechanism chain. 25
25 Heated seats. 30
R16 Heater fan relay
R17 Door lock relay
R21 Seat heating
R22 Heated tailgate glass relay
