The Dodge Journey is a crossover SUV produced by FCA US LLC since 2008. Introduced in 2007 at the Frankfurt Motor Show, it was originally intended for the US market. In this guide, we provide a detailed analysis of the fuse box diagrams for the first-generation Dodge Journey (factory index JC), covering the 2007, 2008, 2009, and 2010 model years.
Below, you will find the locations and photographs of the power distribution centers. The fuses protecting the "Cigarette Lighter" and "Fuel Pump" circuits are highlighted in bold.
Engine Compartment
The fuse box is located on the right side of the engine bay, beneath a protective cover.
General overview of the fuse panel.
| Diagram | ||
|---|---|---|
|
||
| No. | Circuit Description | Amperage (A) |
| J1 | Power Folding Seat | 40 |
| J2 | Transfer Case Module (If Equipped) | 30 |
| J3 | Rear Door Module | 30 |
| J4 | Driver Door Module | 25 |
| J5 | Passenger Door Module | 25 |
| J6 | Anti-Lock Braking System (ABS) / Electronic Stability Program (ESP) | 40 |
| J7 | Anti-Lock Braking System (ABS) Valve / Electronic Stability Program (ESP) | 30 |
| J8 | Power Seat Memory Module (If Equipped) | 40 |
| J9 | Partial Zero Emissions Vehicle (PZEV) System (If Equipped) | 40 |
| J10 | Headlight Washer Relay (BUX) / Manifold Tuning Valve (If Equipped) | 30 |
| J11 | Sway Bar / Thatcham Security (BUX) / Power Sliding Door (If Equipped) | 30 |
| J13 | Ignition-Off Draw (IOD) - Main | 60 |
| J14 | Electric Backlight (EBL) / Rear Defroster | 40 |
| J15 | Rear Blower Motor (If Equipped) | 30 |
| J17 | Starter Motor | 40 |
| J18 | Next Generation Controller (NGC) Powertrain Control Module (PCM) / Transmission | 20 |
| J19 | Radiator Cooling Fan | 60 |
| J20 | Front Wiper Motor (High/Low Speed) | 30 |
| J21 | Front / Rear Washer Pump | 20 |
| J22 | Sunroof Module (If Equipped) | 25 |
| M1 | Center High-Mounted Stop Lamp (CHMSL) | 15 |
| M2 | Trailer Lighting (If Equipped) | 20 |
| M3 | Front / Rear Axle All-Wheel Drive (AWD) Module | 20 |
| M4 | Trailer Tow (If Equipped) | 10 |
| M5 | Power Inverter (If Equipped) | 25 |
| M6 | Power Outlet #1 (Accessory), Rain Sensor, Cigarette Lighter | 20 |
| M7 | Power Outlet #2 (Selectable: Battery or Accessory) | 20 |
| M8 | Heated Front Seats (If Equipped) | 20 |
| M9 | Heated Rear Seats (If Equipped) | 20 |
| M10 | Interior Lighting / Hands-Free Communication Module (HFM) / Remote Display / Satellite Digital Audio Receiver System (SDARS) / Universal Garage Door Opener (UGDO) / Video Entertainment System (VES™) (If Equipped) | 15 |
| M11 | Automatic Temperature Control (ATC) (If Equipped) / Underhood Lighting | 10 |
| M12 | Radio / Audio Amplifier | 30 |
| M13 | Cabin Compartment Node (CCN) / Multifunction Switch / Intrusion Transceiver Module (ITM) / Siren | 20 |
| M14 | Trailer Tow (BUX) (If Equipped) | 20 |
| M15 | Auto-Dimming Rearview Mirror / Infrared (IR) Sensor / Multifunction Switch / Tire Pressure Monitoring System (TPMS) / Transfer Case Module (If Equipped) | 20 |
| M16 | Occupant Restraint Controller (ORC) / Occupant Classification Module (OCM) | 10 |
| M17 | Left Turn Signal / Side Marker / Tail Lights / License Plate Lights | 15 |
| M18 | Right Turn Signal / Side Marker / Tail Lights | 15 |
| M19 | Auto Shutdown (ASD) Relay #1 & #2 | 25 |
| M20 | Electronic Vehicle Information Center (EVIC) / Interior Lighting / Steering Wheel Switches / Switch Bank (If Equipped) | 15 |
| M21 | Auto Shutdown (ASD) Relay #3 | 20 |
| M22 | Right Horn | 10 |
| M23 | Left Horn | 10 |
| M24 | Rear Wiper Motor | 25 |
| M25 |
|
20 |
| M26 | Power Window Switches | 10 |
| M27 | Electronic Steering Column Lock / Wireless Ignition Node (WIN) / Passive Entry Module (PEM) | 10 |
| M28 | Next Generation Controller (NGC) Powertrain Control Module (PCM) / Transmission Feed (Battery) | 10 |
| M29 | Occupant Classification Module (OCM) | 10 |
| M30 | Wiper Motor / Power Mirror Module / J1962 Diagnostic Feed | 15 |
| M31 | Backup Lights | 20 |
| M32 | Occupant Restraint Controller (ORC) | 10 |
| M33 | Next Generation Controller (NGC) Powertrain Control Module (PCM) / Transmission Control Module (TCM) (Battery) | 10 |
| M34 | Park Assist / Heating, Ventilation, and Air Conditioning (HVAC) Module / Headlight Washers / Compass / Flashlight / Radiator Fan (Diesel) (If Equipped) | 10 |
| M35 | Heated Mirrors (If Equipped) | 10 |
| M36 | Power Outlet #3 (Battery) | 20 |
| M37 | Anti-Lock Braking System (ABS) / Electronic Stability Program (ESP) / Stop Lamp Switch | 10 |
| M38 | Door Lock/Unlock Motors | 25 |
| K1 | Ignition Run/Off Relay | — |
| K2 | Ignition Run Relay | — |
| K3 | Starter Relay | — |
| K4 | Ignition Run/Start Relay | — |
| K5 | Powertrain Control Module (PCM) Relay | — |
| K6 | Electric Backlight (EBL) / Rear Defroster Relay | — |
| K7 | — | — |
| K8 | — | — |
| K9 | Rear Blower Motor Relay | — |
| K10 | Auto Shutdown (ASD) Relay | — |
| K11 | Radiator Cooling Fan Relay (Low Speed) | — |
