Fuses and relays Dodge Stratus (JR; 2001-2006)

This article provides a detailed overview of the fuse diagrams for the second-generation Dodge Stratus sedan (JR chassis code) covering the 2001, 2002, 2003, 2004, 2005, and 2006 model years.

Fuse #2 in the engine compartment fuse block protects the cigarette lighter circuit.

Engine Compartment Fuse Block

Located near the air cleaner assembly, beneath the protective cover.

Representative image.

Diagram
No.	Description	Amperage
R1	Transmission Control Relay
R2	Starter Relay
R3	Fuel Pump Relay
R4	Front Wiper Relay (High/Low Speed)
R5	Front Wiper Relay (On/Off)
R6	Export Models: Rear Fog Lamp Relay
R7	A/C Compressor Clutch Relay
R8	Heated Seat Relay
R9	Radiator Cooling Fan Relay (Low Speed)
R10	Radiator Cooling Fan Relay (High Speed)
R11	Automatic Shutdown (ASD) Relay
R12	Headlamp Washer Relay
1	Ignition Switch - Fuses #1, #4, #16, and #19 (Interior Fuse Block)	40 A
2	Power Receptacle / Cigarette Lighter	20 A
3	Export Models: Headlamp Washer	30 A
4	Multi-Function Switch, Headlamp Delay Relay, Fuses #9, #10, and #18 (Interior Fuse Block)	40 A
5	Empty	-
6	Rear Window Defogger Relay	40 A
7	2.4L PZEV: Secondary Air Injection Pump Relay	40 A
8	Fuel Pump Relay, Starter Relay, Ignition Switch - Transmission Control Module (TCM), Clutch Interlock/Upstop Switch (M/T), Fuses #14, #15, and #17 (Interior Fuse Block), Body Control Module (BCM), Fuse #23	20 A
9	Transmission Solenoid/Pressure Switch Assembly, Transmission Control Module (TCM) and Relay	20 A
10	Sentry Key Immobilizer Module (SKIM), Ignition Switch - Fuse #11 (Interior Fuse Block)	10 A
11	Fuse #5 (Interior Fuse Block), Stop Lamp Switch, Rear Fog Lamp Relay	20 A
12	A/C Compressor Clutch Relay, Radiator Cooling Fan Relays (Low and High Speed)	40 A
13	Heated Seat Relay	20 A
14	Powertrain Control Module (PCM), ASD Relay: Fuses #24 and #25	30 A
15	Anti-lock Braking System (ABS) Module	40 A
16	Fuses #7 and #8 (Interior Fuse Block)	40 A
17	Empty	-
18	Front Wiper Relays (On/Off and High/Low Speed)	40 A
19	Empty	-
20	Multi-Function Switch	20 A
21	Empty	-
22	Anti-lock Braking System (ABS) Module	20 A
23	Powertrain Control Module (PCM), Fuel Pump Relay, Sentry Key Immobilizer Module (SKIM), Leak Detection Pump (LDP) (US Models), A/C Compressor Clutch Relay, Radiator Cooling Fan Relays (Low and High Speed)	10 A
	Leak Detection Pump (LDP) (US Models), Sentry Key Immobilizer Module (SKIM), Fuel Pump Relay, Powertrain Control Module (PCM), A/C Compressor Clutch Relay, Radiator Cooling Fan Relays (Low and High Speed)	20 A
24	2.7L Models: Manifold Tuning Valve (MTV), Ignition Coils, Fuel Injectors, Radio Noise Suppressor	20 A
25	2.7L Models: PCV Heater, Alternator, Oxygen (O2) Sensors,  Exhaust Gas Recirculation (EGR) Solenoid	20 A

Interior Passenger Compartment Fuse Block

The interior fuse block is located on the left side of the dashboard, concealed behind a removable trim panel.

General layout.

Diagram
No.	Description	Amperage
R1	Headlamp Delay Relay	-
R2	Horn Relay	-
R3	Rear Window Defogger Relay	-
1	Blower Motor Power Module (ATC), Blower Motor (MTC)	30 A
2	US Models: Daytime Running Lamp (DRL) Module, Right High Beam Headlamp Export Models: Right Headlamp Leveling Module	10 A
3	US Models: Left High Beam Headlamp Export Models: Left Headlamp Leveling Module	10 A
4	Anti-lock Braking System (ABS) Module, Transmission Range Sensor (A/T), Back-Up Lamp Switch (M/T), Door Lock Switches, Daytime Running Lamp (DRL) Module, Brake Transmission Shift Interlock (BTSI) Solenoid, Power Mirror Switch, Automatic Temperature Control (ATC) Head, Compass/Mini-Trip Computer	15 A
5	Dome Lamp, Data Link Connector (DLC), Door Lock Switches, Power Mirror Switch, Driver/Passenger Door Cylinder Lock Switches (Vehicle Theft Security System), Glove Box Lamp, Body Control Module (BCM), Automatic Temperature Control (ATC) Head, Radio, Cargo/Trunk Lamp, Compass/Mini-Trip Computer, Power Antenna (Export Models), Overhead Map/Courtesy Lamps, Rear Floor Courtesy Lamps, Vanity Mirror Lamps	10 A
6	HVAC Control Head, Heated Mirrors	10 A
7	Instrument Cluster Multi-Function Switch: Body Control Module (BCM), Headlamp Switch (Headlamp Leveling Switch - Export Models), US Models: Parking and Turn Signal Lamps, Headlamp Leveling Module (Export Models), Tail Lamps, Stop Lamps, Side Marker/Turn Signal Lamps, License Plate Lamps	20 A
8	Audio Amplifier, Horn Relay	20 A
9	Body Control Module (BCM): Power Door Lock Actuators	15 A
10	Multi-Function Switch (Export Models), Daytime Running Lamp (DRL) Module	20 A
11	Body Control Module (BCM), Transmission Control Module (TCM), Heated Seat Switches (Export Models), AutoStick Switch, HVAC Control Head, Instrument Cluster, Data Link Connector (DLC)	10 A
12	Low Beam Headlamp, Daytime Running Lamp (DRL) Module Export Models: Left Headlamp Leveling Module US Models: Left Headlamp	10 A
13	Low Beam Headlamp, Multi-Function Switch: Instrument Cluster, Fog Lamps Export Models: Right Headlamp Leveling Module US Models: Right Headlamp	20 A
14	Radio / Audio System	10 A
15	Body Control Module (BCM), Multi-Function Switch, Rear Window Defogger, Front Wiper Relays (High/Low Speed)	10 A
16	Occupant Restraint Controller (Airbag Module)	10 A
17	Side Impact Airbag Control Module, Occupant Restraint Controller (Airbag Module)	10 A
18	Circuit Breaker: Power Seat Switches	20 A
19	Circuit Breaker: Power Sunroof/Moonroof, Power Window Switches	30 A
